Specifications
Brand Name :
TISCO, BAOSTEEL
Model Number :
400 Uns N04400 K500 K400
Certification :
ISO, SGS, BV
Place of Origin :
China
MOQ :
1 ton
Price :
to be negotiated
Supply Ability :
5000 Ton/Month
Delivery Time :
Within 7-15 workdays after receiving deposit or L/C
Packaging Details :
Standard Packing, or Per customer requirements
Name :
Monel 400 500
Shape :
Plate Sheet
Surface Treatment :
Polished
Process Method :
Cold Drawn, Cold Rolled, Hot Rolled
Melting range :
2400-2460° F.
Width :
2-1500mm
Thickness :
1-2000mm
Application :
Auto, turbines, blades, powder and engines
Description

Monel 400® is a nickel-copper alloy that is hardened by cold working only. Monel 400® has low corrosion rate in flowing seawater, therefore it is widely used in marine applications. Monel 400® also has excellent resistance to stress corrosion cracking in most freshwaters. Monel 400® can be used in temperatures up to 1000 oF. The alloy has great mechanical properties at subzero temperatures.

Chemical Composition(K500)
Ni
Cu
Fe
C
Mn
Si
S
Al
Ti
(min)63
28
-
-
-
-
-
2.3
0.35
(max)66
34
25
0.3
2
0.5
0.024
3.15
0.85
Density
8.84 g/cm3
Melting range
1316-1400ºC
Chemical Composition(400)
Ni
Cu
Fe
C
Mn
Si
S
(min)63
28
-
-
-
-
-
(max)-
34
25
0.3
2
0.5
0.024
Product Name
Nickel Based Alloy Monel 400 6MM Precision Coils Outer Polished Tubes Micro Heat Exchanger Tubing Stainless Steel Capillary Tube
Standard
GB,AISI,ASTM,DIN,EN,JIS
Grade
Stainless steel 304 / 304L / 310S / 316L / 316Ti / 316LN / 317L / 904L / 2205 / 2507 / 32760 / 253MA / 254SMo / XM-19 / S31803 /
S32750 / S32205 / F50 / F60 / F55 / F60 / F61 / F65 etc
Monel 400 / Monel K-500
Inconel 600 / Inconel 601 / Inconel 625 / Inconel 617 / Inconel 690 / Inconel 718 / Inconel X-750
Incoloy A-286 / Incoloy 800 / Incoloy 800H / Incoloy 800HT
Incoloy 825 / Incoloy 901 / Incoloy 925 / Incoloy 926
Nimonic 75 / Nimonic 80A / Nimonic 90 / Nimonic 105 / Nimonic C263 / L-605
Hastelloy B / Hastelloy B-2 / Hastelloy B-3 / Hastelloy C / Hastelloy C-276 / Hastelloy C-22
Hastelloy C-4 / Hastelloy C-2000 / Hastelloy G-35 / Hastelloy X / Hastelloy N
PH stainless steel 15-5PH / 17-4PH / 17-7PH
Inspection
TUV,SGS,BV,ABS,LR and so on
Application
Chemical, Pharmaceutical & Bio-Medical, Petrochemical & Refinery, Environmental, Food Processing, Aviation, Chemical Fertilizer,
Sewage Disposal, Desalination, Waste Incineration etc.
Processing Service
Machining : Turning / Milling / Planing / Drilling / Boring / Grinding / Gear Cutting / CNC Machining
Deformation processing : Bending / Cutting / Rolling / Stamping
Welded
Forged
Sample
Free
