Thickness 0.3mm 12V 200W Clear Amber Flexible Polyimide Heater
Thickness 0.3mm 12V 200W Clear Amber Flexible Polyimide Heater
Thickness 0.3mm 12V 200W Clear Amber Flexible Polyimide Heater
Thickness 0.3mm 12V 200W Clear Amber Flexible Polyimide Heater
Thickness 0.3mm 12V 200W Clear Amber Flexible Polyimide Heater
Thickness 0.3mm 12V 200W Clear Amber Flexible Polyimide Heater
Thickness 0.3mm 12V 200W Clear Amber Flexible Polyimide Heater
Thickness 0.3mm 12V 200W Clear Amber Flexible Polyimide Heater
Thickness 0.3mm 12V 200W Clear Amber Flexible Polyimide Heater
Thickness 0.3mm 12V 200W Clear Amber Flexible Polyimide Heater
Specifications
Place of Origin :
JiangSu
Brand Name :
Hotlong
Certification :
CE,ISO9001
MOQ :
50-100
Price :
consultative
Delivery Time :
7-10
Warranty :
one year
Voltage :
12-480v
Type :
Air Heater
Dimension(l*w*h) :
customized
Description

Polyimide Thermofoil Heaters

Benefits

Flexible heating film is a clear amber colored polyimide film. The process for making flexible heating film is similar to that of Etched Foil Silicone heaters. It is a high-temperature flexible heating element with excellent dielectric properties capable of operating environments between -185 degree celsius to 200 degree Celsius Customize 12V,24V,36V 3D printer flexible heating film with CE certification,and we usually say it is polyimide heaters. This is is very thin,the thickness is about 0.3mm,it is very light,so it is widely used on 3D printer.the normal size for 3D printer are follow, 1,200x200mm,12v,200w 2,260x290mm,12v,145w 3,200x250mm,12v,90w and so on. any size,any shape can be customize. please contact with us. NOTE: we can custom according to your voltage, size, power and so on.

Features and Benefits
Excellent physical and electrical properties: results in thermal stability over a wide temperature range.
Transparent polyimide material: allows inspection of internal details.
Resistance of radiation and fungus: can be used in a wide range of applications.
Thickness 0.3mm 12V 200W Clear Amber Flexible Polyimide Heater

Specifications
Power Source: Electric
Voltage: 12-480V
Power : ≤ 3W/cm2
Maximum size: 500mm*1000mm
Thickness:0.15-0.5mm
Recommended working temperature:≤ 180℃
Color: Brown
Warranty: 1 Year
Material: PI/polyimide film with etching film
Insulation material: polyimide film
Insulation resistance: 1000V,≥100MΩ
Certification: ISO9001, CE, Rohs, UL
Application: as customer’s need

Standard type size(mm) voltage power power density
HL-00368(A)-E-O 50*200 220V 50W 0.5W/CM2
HL-00368(B)-E-O 50*300 220V 75W 0.5W/CM2
HL-00368(C)-E-O 100*100 220V 50W 0.5W/CM2
HL-00368(D-E-O 100*200 220V 100W 0.5W/CM2
HL-00368(E)-E-O 100*300 220V 150W 0.5W/CM2
HL-00368(F)-E-O 200*200 220V 200W 0.5W/CM2
HL-00368(G-E-O 200*300 220V 300W 0.5W/CM2



Accessories optional

Name Model Specifications
Leading line PTFE wire UL1332 300V,26AWG-10AWG
PTFE wire UL1330 600V,26AWG-10AWG
PI line 300V,30AWG-20AWG
Silicone rubber line 300V,0.5mm2-2.5mm2
Glass fiber line 300V,0.5mm2-4mm2
3M glue 468/467 working temperature ≤ 149℃
966/9079 working temperature ≤ 179℃
9888T working temperature ≤ 119℃
Controller OT1 0-200°C JPt 100Ω sensor
OT3 0-300°C PID controller
OT4. OT5 100ºC
EGO 0-40ºC 30-110ºC 60-200ºC
Thermo 50ºC 70ºC 100ºC 120ºC 150ºC



Application
Medical applications that require a clean, sterile environment
Laboratory research
Semiconductor processing equipment
Optical equipment
LCD displays
Computer equipment
Photographic equipment
