Red Color heat resistant silicone rubber fiberglass sleeving high temperature
Red Color heat resistant silicone rubber fiberglass sleeving high temperature
Red Color heat resistant silicone rubber fiberglass sleeving high temperature
Red Color heat resistant silicone rubber fiberglass sleeving high temperature
Red Color heat resistant silicone rubber fiberglass sleeving high temperature
Red Color heat resistant silicone rubber fiberglass sleeving high temperature
Red Color heat resistant silicone rubber fiberglass sleeving high temperature
Red Color heat resistant silicone rubber fiberglass sleeving high temperature
Specifications
Brand Name :
SUNBOW
Model Number :
SB-SGS-40
Certification :
UL, REACH, ROHS, ISO9001:2008, TS16949
Place of Origin :
Shenzhen China
MOQ :
3000 meters
Price :
USD
Payment Terms :
Western Union, L/C, T/T
Supply Ability :
9,000,000meters/month
Delivery Time :
10~15 working days
Packaging Details :
Sunbow standard packing
Product Name :
Red Color silicone rubber fiberglass sleeve Silicone Resin Coated Fiberglass Sleeving
Material :
Silicone resin, fiberglass yarn
Working Temperature :
200 C
Size Range :
0.5~30.0 mm
Certificates :
UL, REACH, ROHS, ISO9001:2008, TS16949
UL NO. :
E333178
Application :
AC motor, heater, wire hardness, bus bar, component leads, assemblies of electric components etc.
Color :
White, others could be customized
Description

Red Color heat resistant silicone rubber fiberglass sleeving high temperature

Fiberglass Sleeving treated at high temperature with special kind of silicone resin. Flexible silicone varnish fiberglass tubing possesses good qualities of dielectric, domestic electrical appliances heating electric equipment, TV set, and electric apparatus, and it's also suitable for the protection of collected strands of wire.

Working Temperature: 200C
Voltage:1200V,1500V,2500V,4000V,7000V
Size:0.5mm~30mm
standard colour: white, red, yellow, blue, brown, green etc
Approval : UL, RoHS, REACH, CUL

DIMENSION

INSIDE DIAMETER

WALL THICKNESS MINIMUM

(mm)

STANDARD PACKAGE

m/roll

NOMINAL(mm)

TOLERANCE(mm)

φ0.5

+0.2, -0.1

≥0.37

200

φ1.0

+0.2, -0.1

≥0.37

200

φ1.5

+0.2, -0.1

≥0.37

200

φ2.0

+0.2, -0.1

≥0.37

200

φ2.5

+0.3, -0.1

≥0.42

200

φ3.0

+0.3, -0.1

≥0.42

200

φ4.0

+0.3, -0.1

≥0.42

200

φ4.5

+0.3, -0.1

≥0.51

100

φ5.0

+0.3, -0.1

≥0.51

100

φ6.0

+0.3, -0.1

≥0.51

100

φ7.0

+0.3, -0.1

≥0.56

100

φ8.0

+0.3, -0.1

≥0.56

100

φ9.0

+0.3, -0.1

≥0.66

100

φ10.0

+0.3, -0.1

≥0.66

100

φ12.0

+1.0, -1.0

≥0.66

50

φ14.0

+1.0, -1.0

≥0.66

50

φ16.0

+1.0, -1.0

≥0.66

50

φ18.0

+1.0, -1.0

≥0.66

50

φ20.0

+1.0, -1.0

≥0.76

25

φ25.0

+1.0, -1.0

≥0.76

25

φ30.0

+1.0, -1.0

≥0.76

25

PACKAGE: Packing by rolls or cut upon request.

COLOR: Standard color is white, other color available upon request.

Red Color silicone rubber fiberglass sleeve Silicone Resin Coated Fiberglass Sleeving

Red Color heat resistant silicone rubber fiberglass sleeving high temperature
