Soft Excellent intensity High flexible Aromatic Polyamide Pater Tubing Special Tubes
Soft Excellent intensity High flexible Aromatic Polyamide Pater Tubing Special Tubes
Soft Excellent intensity High flexible Aromatic Polyamide Pater Tubing Special Tubes
Soft Excellent intensity High flexible Aromatic Polyamide Pater Tubing Special Tubes
Soft Excellent intensity High flexible Aromatic Polyamide Pater Tubing Special Tubes
Soft Excellent intensity High flexible Aromatic Polyamide Pater Tubing Special Tubes
Soft Excellent intensity High flexible Aromatic Polyamide Pater Tubing Special Tubes
Soft Excellent intensity High flexible Aromatic Polyamide Pater Tubing Special Tubes
Specifications
Brand Name :
Sunbow
Model Number :
SB-PFT
Certification :
ROHS, REACH
Place of Origin :
China
MOQ :
1000M per size per color
Price :
USD$0.05 to 2.0/M
Payment Terms :
T/T, Western Union
Supply Ability :
20,000 M/DAY
Delivery Time :
5~7 work days
Packaging Details :
Standard package
Material :
Polyimide
Working temperature :
-60 ~220 degree C
Color :
Light yellow
Melting point :
250 to 265 degree C
Tensile strength :
130MPA
Tenacity :
Excellent
Visual :
Smooth, no fleck
Anti corrosion :
Outstanding
Xylene extraction :
<2%
Application :
Insulation protection
Description

Soft Excellent intensity high flexible aromatic polyamide pater tubing special tubes

Model Number:SB-PFT

Operating temperature: -60ºC ~ +220ºC

Structure

PFT tubing is manufactured by twisted polyimide film then adhesives by special glue. The glue possesses similar chemical characteristics with polyester film.

Soft Excellent intensity High flexible Aromatic Polyamide Pater Tubing Special Tubes

Usage

Main application range: insulation and mechanical protection for soldering, connection, wire harness, transformer, motor, cable, heating element, capacitor, telephone, electrical appliance etc.

Characteristics

Dimension

Inside diameter 2.0-65(mm),Thickness 0.05-1(mm), Length10-1000(mm)

Color

light yellow

Melting point

250ºC - 265ºC

Service temperature

-269ºC ～ 260ºC

Density

1.42+/-0.02

Tensile strength

Longitudinal >=130mpa; Horizontal>=110mpa

Water absorption

75% max after 24 hr immersion

Corrosive on Copper

Negligible

Solubility in acid, oil, paint, industrial solvents tec.

Undissolved

Antibacterial, anti corrosive

Excellent

Tenacity

Excellent

Cuticle intensity

≥35%

Resistance pressure

50HZ 115MV/min Not perforative

Visual

Smooth, No fleck

Surface resistivity: (200ºC)

≥1.0x1013

Volume resistivity: (200ºC)

≥3.8x1010

Dielectric coefficient:(50HZ)

3.5

Dielectric loss:(50HZ)

≤4X10-3

Flammability

Slow to self-extinguishing

Burning resistance

Resistance characteristics

Resistance to abrasion, acids, immersion, mildew, industrial solvent, mechanical destroy, Freon and special liquids

Xylene extraction

<2%

Environment protection

No harmful to human and environment

Soft Excellent intensity High flexible Aromatic Polyamide Pater Tubing Special TubesSoft Excellent intensity High flexible Aromatic Polyamide Pater Tubing Special TubesSoft Excellent intensity High flexible Aromatic Polyamide Pater Tubing Special TubesSoft Excellent intensity High flexible Aromatic Polyamide Pater Tubing Special TubesSoft Excellent intensity High flexible Aromatic Polyamide Pater Tubing Special TubesSoft Excellent intensity High flexible Aromatic Polyamide Pater Tubing Special Tubes

Advantages

  1. Soft and flexible
  2. High working temperature and low temperature performance
  3. Excellent non-flammability
  4. Excelllent Mechanical tenacity
  5. Excellent dielectric strength
  6. Excellent Chemical compatibility
  7. Wide application
  8. Anti corrosion
  9. Free samples are avaible
  10. Fast delivery
  11. Sufficient storage
