Specifications
Brand Name :
SUNBOW
Model Number :
SB-RSFR-125H
Certification :
UL(UL No.: E360625), RoHS, Reach, ISO9001, TS16949
Place of Origin :
China
MOQ :
2000 meter
Price :
USD 0.04 ~ 16.67 per meter.
Payment Terms :
T/T, PayPal.
Supply Ability :
9,000,000 meters per month
Packaging Details :
0.5mm ~ 4.0mm, 400 meter/spool; 4.5mm ~ 6.0mm, 200 meter/spool; 7.0mm ~ 22.0mm, 100 meter/spool; 25.0mm ~ 40.0mm, 50 meter/spool; 60.0mm ~ 300.0mm, 25 meter/spool.
Delivery Time :
5 ~ 10 working days.
Product name :
UL passed 137pcs Hardware Assorted no adhesive Heat Shrink Tube
Working temperature :
-45ºC ~ 125ºC
Shrink temperature :
84ºC ~ 120ºC
Shrink ratio :
2:1
Property :
Insulation, flame retardant, flexible, zero halogen, low smoke
Diameter range :
0.5mm ~ 300.0mm
Color :
Black, white, red, yellow, green, blue...
Application :
for wiring harness
Description

UL passed 137pcs Hardware Assorted no adhesive Heat Shrink Tube

Advantage: Zero Halogen Flexible Polyolefin Heat Shrinkable Tubing Insulation

1. Great production ability as high as 9,000,000 meters/month

2. Competitive price with quality products

3. Whole color UL certificated with inner diameter 0.6-250mm

Characteristics: Zero Halogen Flexible Polyolefin Heat Shrinkable Tubing Insulation

1. Halogen free, non-smoke, non-toxic, flame-retardant, soft, quick shrink, stable performance

2. Shrink ratio: 2:1

3. Shrink temperature: 84ºC ~ 120ºC

4. Working temperature: -45ºC ~ 125ºC

5. RoHS compliant

Specification: Zero Halogen Flexible Polyolefin Heat Shrinkable Tubing Insulation

Property

Unit

Test Method

Standard

Tensile Strength

MPA

≥10.4(Before Aging)

GB/T 1040

≥7.3(After Aging)

158ºC*168hrs

Breakage Elongation (%)

%

≥200(Before Aging)

GB/T 1040

≥100(After Aging)

158ºC*168hrs

Heat Shock

-

No Sticking & No Cracking

250ºC*4hrs

Cold Blend

-

No Cracking

-30ºC*4hrs

Breakdown Strength

KV/mm

≥15

GB/T 1408

Dielectric Withstand

600V

-

Pass

No Breakdown for 2500V, 60s

300V

-

Pass

No Breakdown for 1500V,60s

Volume Resistivity

Ω. cm

≥1×1014

GB/T 1410

Corrosion Performance

-

pass

158ºC*168hrs

Copper Stability

-

pass

158ºC*168hrs

Flammability

-

pass

VW-1

Dimension: Zero Halogen Flexible Polyolefin Heat Shrinkable Tubing Insulation

  1. Halogen free flame-retardant heat shrinkable tube

Inner

Diameter

As Supplied(mm)

After Recovery(mm)

Standard Package

Application Range(mm)

Inner Diameter

Wall Thickness

Inner Diameter

Wall Thickness

(m/spool)

Φ0.6

0.9±0.2

0.20±0.05

≤0.40

0.33±0.10

400

0.4~0.7

Φ0.8

1.1±0.2

0.20±0.05

≤0.50

0.33±0.10

400

0.6~0.8

Φ1.0

1.5±0.2

0.20±0.05

≤0.65

0.36±0.10

400

0.75~0.9

Φ1.5

2.0±0.2

0.20±0.05

≤0.85

0.36±0.10

400

0.95~1.4

Φ2.0

2.5±0.2

0.23±0.05

≤1.00

0.45±0.10

400

1.1~1.8

Φ2.5

3.0±0.2

0.23±0.05

≤1.30

0.45±0.10

400

1.35~2.3

Φ3.0

3.5±0.2

0.23±0.05

≤1.50

0.45±0.10

400

1.6~2.7

Φ3.5

4.0±0.2

0.23±0.05

≤1.80

0.45±0.10

400

1.85~3.2

Φ4.0

4.5±0.2

0.25±0.05

≤2.00

0.45±0.10

400

2.1~3.6

Φ4.5

5.0±0.2

0.28±0.05

≤2.30

0.56±0.10

200

2.35~4.0

Φ5.0

5.5±0.2

0.28±0.05

≤2.50

0.56±0.10

200

2.6~4.5

Φ6.0

6.5±0.2

0.28±0.05

≤3.00

0.56±0.10

200

3.1~5.4

Φ7.0

7.5±0.3

0.28±0.05

≤3.50

0.56±0.10

100

3.7~6.3

Φ8.0

8.5±0.3

0.30±0.08

≤4.00

0.56±0.10

100

4.2~7.2

Φ9.0

9.5±0.3

0.30±0.08

≤4.50

0.56±0.10

100

4.7~8.0

Φ10

10.5±0.3

0.30±0.08

≤5.00

0.56±0.10

100

5.2~9.0

Φ11

11.5±0.3

0.30±0.08

≤5.50

0.56±0.10

100

5.7~10

Φ12

12.5±0.3

0.30±0.08

≤6.00

0.56±0.10

100

6.2~11

Φ13

13.5±0.3

0.30±0.08

≤6.50

0.56±0.10

100

6.7~12

Φ14

14.5±0.3

0.35±0.10

≤7.00

0.70±0.10

100

7.3~13

Φ15

15.5±0.4

0.35±0.10

≤7.50

0.70±0.10

100

7.8~14

Φ16

16.5±0.4

0.35±0.10

≤8.00

0.70±0.10

100

8.3~15

Φ17

17.5±0.4

0.35±0.10

≤8.50

0.70±0.10

100

8.8~16

Φ18

19.0±0.5

0.35±0.10

≤9.00

0.70±0.10

100

9.3~17

Φ20

22.0±0.5

0.35±0.10

≤10.00

0.83±0.15

100

10.4~19

Φ22

24.0±0.5

0.40±0.12

≤11.00

0.83±0.15

100

11.4~21

Φ25

26.0±0.5

0.40±0.12

≤12.50

0.90±0.15

50

12.8~24

Φ28

29.0±0.5

0.45±0.12

≤14.00

0.90±0.15

50

14.4~29

Φ30

31.5±1.0

0.45±0.12

≤15.00

1.00±0.15

50

16~29

Φ35

36.5±1.0

0.45±0.12

≤17.50

1.00±0.15

50

18~34

Φ40

41.5±1.0

0.45±0.12

≤20.00

1.00±0.15

50

21~39

Φ45

46.5±1.0

0.50±0.15

≤22.5

1.00±0.15

25

23.5~44

Φ50

≥50

0.50±0.15

≤25.0

1.10±0.15

25

26~49

Φ60

≥60

0.60±0.15

≤30.0

1.20±0.15

25

35~55

Φ70

≥70

0.65±0.15

≤35.0

1.30±0.20

25

40~65

Φ80

≥80

0.65±0.15

≤40.0

1.30±0.20

25

45~75

Φ90

≥90

0.65±0.15

≤45.0

1.30±0.20

25

50~85

Φ100

≥100

0.65±0.20

≤50.0

1.30±0.20

25

55~95

Φ120

≥120

0.65±0.20

≤60.0

1.30±0.20

25

65~115

Φ150

≥150

0.65±0.20

≤70.0

1.30±0.20

25

80~145

Φ180

≥180

0.65±0.30

≤90.0

1.30±0.30

25

95~175

Φ210

≥210

0.65±0.30

≤105.0

1.30±0.30

25

110~205

Φ230

≥230

0.65±0.30

≤115.0

1.30±0.30

25

120~225

Φ250

≥250

0.65±0.30

≤125.0

1.30±0.30

25

130~240

2. halogen free flame-retardant ultra thin heat shrinkable tube

Inner

Diameter

As Supplied(mm)

After Recovery(mm)

Package

Application Range (mm)

Inner Diameter

Wall Thickness

Inner Diameter

Wall Thickness

(m/spool)

Φ0.6CB

0.9±0.2

0.13±0.05

≤0.40

0.20±0.10

200

0.4~0.7

Φ0.8CB

1.0±0.2

0.13±0.05

≤0.50

0.20±0.10

200

0.6~0.8

Φ1.0CB

1.40±0.20

0.13±0.05

≤0.65

0.20±0.10

200

0.7~1.0

Φ1.5CB

1.90±0.20

0.13±0.05

≤0.85

0.20±0.10

200

0.9~1.4

Φ2.0CB

2.40±0.20

0.13±0.05

≤1.00

0.22±0.10

200

1.1~1.8

Φ2.5CB

2.90±0.20

0.13±0.05

≤1.30

0.25±0.10

200

1.4~2.3

Φ3.0CB

3.40±0.20

0.13±0.05

≤1.50

0.28±0.10

200

1.6~2.7

Φ3.5CB

3.90±0.20

0.13±0.05

≤1.80

0.28±0.10

200

1.9~2.3

Φ4.0CB

4.40±0.20

0.15±0.05

≤2.00

0.30±0.10

200

2.1~3.6

Φ4.5CB

4.90±0.20

0.15±0.05

≤2.30

0.30±0.10

100

2.4~4.0

Φ5.0CB

5.50±0.20

0.15±0.05

≤2.50

0.32±0.10

100

2.6~4.5

Φ6.0CB

6.50±0.20

0.15±0.05

≤3.00

0.32±0.10

100

3.1~5.4

Φ7.0CB

7.50±0.30

0.15±0.05

≤3.50

0.32±0.10

100

3.7~6.3

Φ8.0CB

8.50±0.30

0.15±0.05

≤4.00

0.32±0.10

100

4.2~7.2

Φ9.0CB

9.50±0.30

0.15±0.05

≤4.50

0.35±0.10

100

4.7~8.0

Φ10CB

10.50±0.30

0.15±0.05

≤5.00

0.35±0.10

100

5.2~9.0

Φ11CB

11.50±0.30

0.18±0.05

≤5.50

0.40±0.10

100

5.7~10.0

Φ12CB

12.50±0.30

0.20±0.05

≤6.00

0.40±0.10

100

6.2~11.0

13CB

13.50±0.30

0.20±0.05

≤6.50

0.40±0.10

100

6.7~12.0

Φ14CB

14.50±0.30

0.20±0.05

≤7.00

0.40±0.10

100

7.3~13.0

Φ15CB

15.50±0.40

0.20±0.05

≤7.50

0.40±0.10

100

7.8~14.0

Φ16CB

16.50±0.40

0.22±0.05

≤8.00

0.40±0.10

100

8.3~15.0

Φ17CB

17.50±0.40

0.22±0.05

≤8.50

0.40±0.10

100

8.8~16.0

Φ18CB

18.50±0.40

0.22±0.05

≤9.00

0.42±0.10

100

9.3~17.0

Φ20CB

20.50±0.50

0.25±0.05

≤10.0

0.45±0.10

100

10.5~19.0

Φ22CB

22.50±0.50

0.25±0.05

≤11.0

0.45±0.10

100

11.5~20.5

Color:Standard color is black,other color available upon request

Our Service: Zero Halogen Flexible Polyolefin Heat Shrinkable Tubing Insulation

UL passed 357pcs Hardware Assorted no adhesive Heat Shrink Tube

UL passed 357pcs Hardware Assorted no adhesive Heat Shrink TubeUL passed 357pcs Hardware Assorted no adhesive Heat Shrink TubeUL passed 357pcs Hardware Assorted no adhesive Heat Shrink Tube
UL passed 357pcs Hardware Assorted no adhesive Heat Shrink Tube

FAQ
1. Why choose us?
We are the No.1 fiberglass sleeve coated silicone resin in China.
2. What material do you use?
Fiberglass yarn and silicone resin,PVC,silicone,PE,PET. RoHS,Reach,UL certificated
3. How's the package?
Packed by roll then rolls by carton. Also can cut and pack as requested.
4. Where is your factory?
In Shenzhen. The loading port here is Yantian or Shekou.
5. How many employees are there in your company?
More than 50.
6. How many people are there in your R&D department?
More than 5 desingers,.
7. How do you control the quality?
We have 8 QC team.
Each process has one QC. We check carefully before shipment.
8. What's your sample lead time?
can ship right now if in stock.5 - 7 working days if the items are out of stock.
9.Is the sample free charge?
Yes,it is free but the express fee should be paid by buyer.
10.What's your mass production lead time?
7 - 15 working days.
11. What's your payment terms?
L/C at sight, T/T in advance,Western Union,Paypal.

Product tags

6063 thermal break extrusion

,

heat shrink termination kit

,

heat shrinkable termination kit
Send your message to this supplier
Send Now

UL passed 357pcs Hardware Assorted no adhesive Heat Shrink Tube

Ask Latest Price
Product Detail
Brand Name :
SUNBOW
Model Number :
SB-RSFR-125H
Certification :
UL(UL No.: E360625), RoHS, Reach, ISO9001, TS16949
Place of Origin :
China
MOQ :
2000 meter
Price :
USD 0.04 ~ 16.67 per meter.
Contact Supplier
UL passed 357pcs Hardware Assorted no adhesive Heat Shrink Tube
UL passed 357pcs Hardware Assorted no adhesive Heat Shrink Tube
UL passed 357pcs Hardware Assorted no adhesive Heat Shrink Tube
UL passed 357pcs Hardware Assorted no adhesive Heat Shrink Tube
UL passed 357pcs Hardware Assorted no adhesive Heat Shrink Tube
UL passed 357pcs Hardware Assorted no adhesive Heat Shrink Tube
UL passed 357pcs Hardware Assorted no adhesive Heat Shrink Tube
UL passed 357pcs Hardware Assorted no adhesive Heat Shrink Tube
UL passed 357pcs Hardware Assorted no adhesive Heat Shrink Tube

Shenzhen Sunbow Insulation Materials MFG. CO., LTD

Active Member
10 Years
guangdong, shenzhen
Since 2003
Business Type :
Manufacturer, Exporter, Seller
Main Products :
Silicone Fiberglass Sleeving, Acrylic Fiberglass Sleeving, Polyurethane Sleeving
Total Annual :
5,000,000-8,000,000
Employee Number :
100~200
Certification Level :
Active Member
Discover similar products
View More

Find Similar Products By Category:

Supplier Homepage Products Polyolefin Heat Shrink Tubing
MachineU China Products Tools & Hardware Power Tools Hot-Melt Glue Guns
Contact Supplier
Submit Requirement
