Silicone Rubber Coated Fiberglass Sleeving , White Fiberglass Braided Sleeving
Silicone Rubber Coated Fiberglass Sleeving , White Fiberglass Braided Sleeving
Silicone Rubber Coated Fiberglass Sleeving , White Fiberglass Braided Sleeving
Silicone Rubber Coated Fiberglass Sleeving , White Fiberglass Braided Sleeving
Silicone Rubber Coated Fiberglass Sleeving , White Fiberglass Braided Sleeving
Silicone Rubber Coated Fiberglass Sleeving , White Fiberglass Braided Sleeving
Silicone Rubber Coated Fiberglass Sleeving , White Fiberglass Braided Sleeving
Silicone Rubber Coated Fiberglass Sleeving , White Fiberglass Braided Sleeving
Specifications
Brand Name :
Sunbow
Model Number :
SB-SGS-70
Certification :
UL , RoHS , Reach , CSA
Place of Origin :
Shenzhen, Guangdong, China
MOQ :
1000 Meter
Price :
USD0.07-13.4 per meter
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
600000 Meters / Month
Delivery Time :
7~10 Working Days
Packaging Details :
0.5mm ~ 4.0mm, 200 meters/roll; 4.5mm ~ 10.0mm, 100 meters/roll; 12.0mm ~ 18.0mm, 50 meters/roll; 20.0mm ~ 30.0mm, 25 meters/roll. Carton Size 35*35*60cm
Working Temperature :
200 degree
Breakdown Voltage :
7000V
Material :
Fiberglass Yarn, silicone Rubber
Color :
White, Black, Green, Yellow, Brown, Rust Red etc
Size :
0.5mm ~ 45.0mm
Properties :
Flame Retardant, Flexible , Eco-friendly , Good Dielectric Strength
Flame Retardant Rating :
VW-1 UL 1441
Application :
Insulators, Electrical Appliance, Wires
Product Name :
Silicone Rubber Braided Fiberglass Sleeving Silicone Rubber Coated Fiberglass Sleeving
UL NO :
E333177
Description

Silicone Rubber Braided Fiberglass Sleeving Silicone Rubber Coated Fiberglass Sleeving

Silicone Coated Fiberglass Sleeving Features:

  • High flexible routing;
  • Extreme abrasion resistance;
  • Superior electrical properties;
  • Heat-set, cuts cleanly and will not fray;
  • Easy to "pushback" and form over components, connections and cables;
  • Non-corrosive and extremely fungus resistant

Silicone Coated Fiberglass Sleeving Applications:

Silicone Coated Fiberglass Sleeving may be used for the insulation of leads and connections in transformers.

Silicone Coated Fiberglass Sleeving Properties:

Operating Temperatures: 200°C

Voltage Rating: 600 Volt

Heat Aging: 168 hours at 265°C Without Dielectric Change

Flammability: Self-Extinguishing

Dielectric Strength: 7000 Volts

Item

Performance

Note

Dielectric Breakdown Voltage KV AC

Minimum Average

≥7.0

Before Aging

Minimum Single Point

≥5.0

Minimum Average

≥3.5

6 Hrs* 245±5ºC

245±5ºC 6Hrs Aging

Minimum Single Point

≥2.5

No Breakdown

/

1 KV in 2% Salt Water

Thermal Endurance

No Indication of Crack

OK

1440 Hrs* 235±5ºC

235±5ºC 1440Hrs Aging

Fire Resistance

VW-1

OK

UL 1441

Dimension

Inside Diameter

Wall Thickness (mm)

Standard Package (m/roll)

Nominal (mm)

Tolerance (mm)

φ0.5

+0.2, -0.1

≥0.37

200

φ1.0

+0.2, -0.1

≥0.37

200

φ1.5

+0.2, -0.1

≥0.37

200

φ2.0

+0.2, -0.1

≥0.37

200

φ2.5

+0.3, -0.1

≥0.42

200

φ3.0

+0.3, -0.1

≥0.42

200

φ4.0

+0.3, -0.1

≥0.42

200

φ4.5

+0.3, -0.1

≥0.51

100

φ5.0

+0.3, -0.1

≥0.51

100

φ6.0

+0.3, -0.1

≥0.51

100

φ7.0

+0.3, -0.1

≥0.56

100

φ8.0

+0.3, -0.1

≥0.56

100

φ9.0

+0.3, -0.1

≥0.66

100

φ10.0

+0.3, -0.1

≥0.66

100

φ12.0

+1.0, -1.0

≥0.66

50

φ14.0

+1.0, -1.0

≥0.66

50

φ16.0

+1.0, -1.0

≥0.66

50

φ18.0

+1.0, -1.0

≥0.66

50

φ20.0

+1.0, -1.0

≥0.76

25

φ25.0

+1.0, -1.0

≥0.76

25

φ30.0

+1.0, -1.0

≥0.76

25
