Hot Sale Flexible PVC Transparent PVC Pipe PVC Tube clear Plastic Pipe
Hot Sale Flexible PVC Transparent PVC Pipe PVC Tube clear Plastic Pipe
Hot Sale Flexible PVC Transparent PVC Pipe PVC Tube clear Plastic Pipe
Hot Sale Flexible PVC Transparent PVC Pipe PVC Tube clear Plastic Pipe
Hot Sale Flexible PVC Transparent PVC Pipe PVC Tube clear Plastic Pipe
Hot Sale Flexible PVC Transparent PVC Pipe PVC Tube clear Plastic Pipe
Hot Sale Flexible PVC Transparent PVC Pipe PVC Tube clear Plastic Pipe
Hot Sale Flexible PVC Transparent PVC Pipe PVC Tube clear Plastic Pipe
Specifications
Brand Name :
SUNBOW
Model Number :
SB-PVC
Certification :
ROHS, REACH, UL
Place of Origin :
China
MOQ :
2000 meters
Price :
USD 0.01-9.9usd/m
Payment Terms :
L/C, T/T, Western Union,Paypal
Supply Ability :
200000meters/month
Packaging Details :
by rolls, rolls by carton
Product name :
Hot Sale Flexible PVC Transparent PVC Pipe PVC Tube clear Plastic Pipe
Material :
PVC
Working temperature :
-30-105 degree
UL number :
E 360625
Resistance voltage :
300V or 600V
Size :
0.8-30mm
MOQ :
2000 meters
Application :
wire harness
Description

Hot Sale Flexible PVC Transparent PVC Pipe PVC Tube clear Plastic Pipe

USAGE

With the excellent flexibility, mechanical and dielectric capability, flame resistance performance, PVC tubing

is widely used in outside insulation protection of outgoing wires of electrical appliances, transformers, electrical

motors or lighting equipment, and electronic components, wire harness and etc.

SPECIFICATION

Item Unit Test Method Numerical Value
SB-300 SB-600
Voltage rating V 300 600
Temperature rating °C UL224 105
Voltage resistance Before aging UL224 23°C 2500V/60sec
After aging UL224 136°C 168hr 2500V/60sec
Volume resistivity Ωcm UL224 ≥1010
Tensile strength Before aging Mpa UL224 23°C ≥10.4
After aging Mpa UL224 136°C 168hr ≥7.3
Elongation Before aging % UL224 23°C ≥100%
After aging % UL224 136°C 168hr ≥100%
Flexibility UL224 136°C 168hr No cracking
Heat shock UL224 180°C 4hr No cracking
Cold bend UL224 -30°C 1hr No cracking
Copper stability UL224 136°C 168hr No corrosion
Flame resistance UL224 VW-1

USAGE

With the excellent flexibility, mechanical and dielectric capability, flame resistance performance, PVC tubing

is widely used in outside insulation protection of outgoing wires of electrical appliances, transformers, electrical

motors or lighting equipment, and electronic components, wire harness and etc.

SPECIFICATION

Item Unit Test Method Numerical Value
SB-300 SB-600
Voltage rating V 300 600
Temperature rating °C UL224 105
Voltage resistance Before aging UL224 23°C 2500V/60sec
After aging UL224 136°C 168hr 2500V/60sec
Volume resistivity Ωcm UL224 ≥1010
Tensile strength Before aging Mpa UL224 23°C ≥10.4
After aging Mpa UL224 136°C 168hr ≥7.3
Elongation Before aging % UL224 23°C ≥100%
After aging % UL224 136°C 168hr ≥100%
Flexibility UL224 136°C 168hr No cracking
Heat shock UL224 180°C 4hr No cracking
Cold bend UL224 -30°C 1hr No cracking
Copper stability UL224 136°C 168hr No corrosion
Flame resistance UL224 VW-1
Hot Sale Flexible PVC Transparent PVC Pipe PVC Tube clear Plastic PipeHot Sale Flexible PVC Transparent PVC Pipe PVC Tube clear Plastic PipeHot Sale Flexible PVC Transparent PVC Pipe PVC Tube clear Plastic Pipe
