Expandable Baided PET cable protective sleeving For wire protection
Expandable Baided PET cable protective sleeving For wire protection
Expandable Baided PET cable protective sleeving For wire protection
Expandable Baided PET cable protective sleeving For wire protection
Specifications
Brand Name :
SUNBOW
Model Number :
SB-ES
Certification :
UL ROHS REACH
Place of Origin :
China
MOQ :
2000 meters
Price :
0.009 USD -9.99 SUD/M
Payment Terms :
Western Union, L/C, Paypal, T/T
Delivery Time :
1-7 days after payment
Packaging Details :
by rolls, then rolls by carton.
Product name :
PET expandable sleeving
color :
black, others are available
Material :
PET, PA6, PA66, PPS
Size :
flat width 3-35mm
packing :
by rolls, then rolls by carton
Flame resistant grade :
UL VW-1
Gurantee :
2 years
Diameter of single yarn :
0.25mm or 0.20mm
Certificate :
ROHS, REACH, UL
MOQ :
2000 meters
Application :
cables, automobile and aviation
Description

Expandable Baided PET cable protective sleeving For wire protection

Model number: SB-ES

Working temperature:-50 - 150 degree

Melting point: 250 degree

Flame resistant grade: UL VW-1

Structure:

The PET expandable braided cable protection sleeving is braided environmental-friendly polyester monifil.(PET, PA6, PA66, PPS), It possesses good flexibility, fire resistance, abrasive resistance and thermal insulation performance. The sleeving owns smooth surface, bright color, various patterns.

Usage and main parameters,

Expandable sleeving is widely used in bounding and protecting of electrical cables, automobile and aviation, sectors.

The selection of this product refers to following four parameters, 1 25 048 006

A B C D

A-yarn number (one or three) 3 20 072 018 A B C D B-Diameter of single yarn(0.25mm or 0.20mm)

C-Strand number(48 spindles braiding machine or 72 spindles braiding machine).

D-Flat width(6mm or 18mm).

SPECIFICATION: Expandable Sleeves Braided PET Suitable for Computer Cables and Automotive Wire

Part No. Model No. Min Width (mm) Max Width(mm) Part No. Model No. Min Width(mm) Max Width (mm)
24# 120024 3 6 56# 120056 8 16
125024 3 6 125056 8 16
320024 4 8 320056 10 20
325024 4 8 325056 10 20
32# 120032 4 8 64# 120064 9 18
125032 4 8 125064 9 18
320032 5 10 320064 12 24
325032 5 10 325064 12 24
36# 120036 5 10 72# 120072 10 12
125036 5 10 125072 10 12
320036 6 12 320072 15 30
325036 6 12 325072 15 30
40# 120040 6 12 96# 120096 12 24
125040 6 12 125096 12 24
320040 7 14 320096 20 40
325040 7 14 325096 25 50
48# 120048 7 14 120# 120120 15 30
125048 7 14 125120 15 30
320048 8 16 320120 30 70
325048 8 16 325120 35 100

APPLICATION: Expandable Sleeves Braided PET Suitable for Computer Cables and Automotive Wire
FAQ

1. Why choose us?

We are the No.1 insulation materials supplier in China.

2. What's your best seller?

Our best seller is silicone fiberglass sleeving and the Heat shrink tube.

3. What material do you use?

Fiberglass yarn and silicone resin,PVC,silicone,PE,PET

4. Where is your factory?

In Shenzhen. The loading port here is Yantian or Shekou.

5. How do you control the quality?

We have 10 QC team.

Each process has one QC. We check carefully before shipment.

6. What’s your quality guarantee?

2 years.

7. What’s your sample lead time?

can ship right now if in the stock.5 working days if the items are in stock.

8. Is the sample free charge?

Yes,it is free but the express fee should be paid by buyer.

9.What’s your mass production lead time?

2-7 working days.

10. What’s your payment terms?

L/C at sight, T/T in advance,Western Union,Paypal.

11. What’s your trade term?

EXW, FOB SHEZNEHN, CIF, CFR.

12. What’s your Certificate?

ISO9001, TS16949, UL, ROHS, RACH

13. What’s your MOQ?

2000 meters each, can be discussed if in stock.
