Heat Resistant Custom Extrusion Silicone Rubber Tube 200C Black Clear White
Heat Resistant Custom Extrusion Silicone Rubber Tube 200C Black Clear White
Heat Resistant Custom Extrusion Silicone Rubber Tube 200C Black Clear White
Heat Resistant Custom Extrusion Silicone Rubber Tube 200C Black Clear White
Heat Resistant Custom Extrusion Silicone Rubber Tube 200C Black Clear White
Heat Resistant Custom Extrusion Silicone Rubber Tube 200C Black Clear White
Heat Resistant Custom Extrusion Silicone Rubber Tube 200C Black Clear White
Heat Resistant Custom Extrusion Silicone Rubber Tube 200C Black Clear White
Specifications
Brand Name :
SUNBOW
Model Number :
SB-SRT
Certification :
UL, ROHS, REACH
Place of Origin :
Shenzhen, China
MOQ :
2000meters
Price :
0.1-5
Supply Ability :
10000000meters per month
Delivery Time :
6-10 days
Packaging Details :
Sunbow standard packing
Raw material :
silicone rubber
Working temperature :
-40-200ºC
Size :
0.8-22mm standard, no mould required
Properties :
Heat Resistant, Flexible, Self-extinguishing, Elastic
Color :
clear, red, blue, yellow, green, brown
UL number :
E360625
Application :
Medical device, Wiring Insulation, Cable Bundles, H Grade AC Motors, Cooking Appliances...
Description

Custom Silicone Rubber Extrusion Silicone Rubber Tube 200C Black Clear White

Model Number: SB-SRT

Usage

Silicone rubber tubing with service temperature -30ºC to 250ºC. They are commonly used in contact with foods in accordance with provisions of FDA 21 CFR 177.2600 and in electric insulation.

It can be installed in coffee maker, water dispenser, electric water bottle, car wire hardness, or used in electric insulation for semiconductor etc.

Specification

Performance

Test method

Performance index

Dielectric strength (kv/mm)

GB/T 1048

≥18

Volume resistivity (Ω/cm)

GB/T 1410

≥1x1014

Tearing strength (MPa)

GB/T 1040

≥3.5 MPa

Elongation (%)

GB/T 1040

≥210

Fire resistance(flame retarded products)

GB/T 2408

FV-1

Dimension of 2.5kv 4kv 6kv 7kv breakout voltage 200ºC silicone rubber tube for dielectric strength

Size

Tolerance(mm)

Thickness and tolerance

2500V(mm)

4000V(mm)

6000V(mm)

7000V(mm)

φ0.8

0.8±0.10

0.50±0.10

1.00±0.15

1.50±0.20

2.00±0.25

φ1.0

1.0±0.10

0.50±0.10

1.00±0.15

1.50±0.20

2.00±0.25

φ1.5

1.5±0.10

0.50±0.10

1.00±0.15

1.50±0.20

2.00±0.25

φ2.0

2.0±0.10

0.50±0.10

1.00±0.15

1.50±0.20

2.00±0.25

φ2.5

2.5±0.10

0.50±0.10

1.00±0.15

1.50±0.20

2.00±0.25

φ3.0

3.0±0.10

0.50±0.10

1.00±0.15

1.50±0.20

2.00±0.25

φ3.5

3.5±0.10

0.50±0.10

1.00±0.15

1.50±0.20

2.00±0.25

φ4.0

4.0±0.10

0.50±0.10

1.00±0.15

1.50±0.20

2.00±0.25

φ4.5

4.5±0.10

0.50±0.10

1.00±0.15

1.50±0.20

2.00±0.25

φ5.0

5.0±0.20

0.50±0.10

1.00±0.15

1.50±0.20

2.00±0.25

φ5.5

5.5±0.20

0.50±0.10

1.00±0.15

1.50±0.20

2.00±0.25

φ6.0

6.0±0.20

0.50±0.10

1.00±0.15

1.50±0.20

2.00±0.25

φ6.5

6.5±0.20

0.50±0.10

1.00±0.15

1.50±0.20

2.00±0.25

φ7.0

7.0±0.20

—

1.00±0.15

1.50±0.20

2.00±0.25

φ7.5

7.5±0.20

—

1.00±0.15

1.50±0.20

2.00±0.25

φ8.0

8.0±0.25

—

1.00±0.15

1.50±0.20

2.00±0.25

φ9.0

9.0±0.25

—

1.00±0.15

1.50±0.20

2.00±0.25

φ10.0

10.0±0.25

—

1.00±0.15

1.50±0.20

2.00±0.25

φ11.0

11.0±0.30

—

1.00±0.15

1.50±0.20

2.00±0.25

φ12.0

12.0±0.30

—

1.00±0.15

1.50±0.20

2.00±0.25

φ13.0

13.0±0.30

—

1.00±0.15

1.50±0.20

2.00±0.25

φ14.0

14.0±0.30

—

—

1.50±0.20

2.00±0.25

φ15.0

15.0±0.30

—

—

1.50±0.20

2.00±0.25

φ20.0

20.0±0.30

—

—

—

2.50±0.3

Note: Default color is transparent, other color can be customized upon request.

Why choose Sunbow? Competitive point from SUNBOW,

1) ISO 9001 : 2008 factory manufacturer,

2) high-tech enterprise and TS 16949 standard in China,

3) 12-year manufacturing experience,

4) factory direct sales and stardard after-sales service procedure,

5) best price high quality product,

6) quick delivery time for sample or formal orders,

7) quick response for feedback in email or calls,

8) few complaints from customers,

9) more competitive price for VIP customers,

10) convenient situation near to Shenzhen seaport,

11) flame resistant feature is available.
