Food grade extruded soft silicone rubber tubing for home appliances
Food grade extruded soft silicone rubber tubing for home appliances
Food grade extruded soft silicone rubber tubing for home appliances
Food grade extruded soft silicone rubber tubing for home appliances
Food grade extruded soft silicone rubber tubing for home appliances
Food grade extruded soft silicone rubber tubing for home appliances
Food grade extruded soft silicone rubber tubing for home appliances
Food grade extruded soft silicone rubber tubing for home appliances
Specifications
Brand Name :
SUNBOW
Model Number :
SB-SRT
Certification :
Rohs,Reach,UL
Place of Origin :
China
MOQ :
1000m
Price :
USD 0.01-9.9 per meter
Supply Ability :
2000000m per week
Delivery Time :
5-10days
Packaging Details :
100m/roll
Material :
silicone
Working temperature :
-60 - 200 degree
Size :
ID 0.8-20MM
Color :
clear
Description

Food grade extruded soft silicone rubber tubing for home appliances

Model Number: SB-SRT

Working temperature: -60 -200 degree

Structure

It is extruded by silicone rubber

Usage

Widely used in accordance with provisions of FDA 21 CFR 177.2600 and in electric insulation.It can be installed in coffee maker,electric water bottle,or used in electric insulation etc.

Specification

Performance Test method Performance Index
Dielectric Strength(kv/mm) GB/T 1048 ≥18
Volume resistivity(Ω/CM) GB/T 1410 ≥1x1014
Tearing strength(Mpa) GB/T 1040 ≥3.5 Mpa
Elongation(%) GB/T 1040 ≥210
Fire resistance GB/T 2408 FV-1

Dimension

Size Tolerance(mm) Wall Thickness and tolerance (mm)

2500V(MM) 4000V(MM) 6000V(MM) 7000V(MM)
∅0.8 0.8±0.10 0.5±0.10 1.0±0.15 1.5±0.20 2.0±0.25
∅1.0 1.0±0.10 0.5±0.10 1.0±0.15 1.5±0.20 2.0±0.25
∅1.5 1.5±0.10 0.5±0.10 1.0±0.15 1.5±0.20 2.0±0.25
∅2.0 2.0±0.10 0.5±0.10 1.0±0.15 1.5±0.20 2.0±0.25
∅2.5 2.5±0.10 0.5±0.10 1.0±0.15 1.5±0.20 2.0±0.25
∅3.0 3.0±0.10 0.5±0.10 1.0±0.15 1.5±0.20 2.0±0.25
∅3.5 3.5±0.10 0.5±0.10 1.0±0.15 1.5±0.20 2.0±0.25
∅4.0 4.0±0.10 0.5±0.10 1.0±0.15 1.5±0.20 2.0±0.25
∅4.5 4.5±0.10 0.5±0.10 1.0±0.15 1.5±0.20 2.0±0.25
∅5.0 5.0±0.20 0.5±0.10 1.0±0.15 1.5±0.20 2.0±0.25
∅5.5 5.5±0.20 0.5±0.10 1.0±0.15 1.5±0.20 2.0±0.25
∅6.0 6.0±0.20 0.5±0.10 1.0±0.15 1.5±0.20 2.0±0.25
∅6.5 6.5±0.20 0.5±0.10 1.0±0.15 1.5±0.20 2.0±0.25
∅7.0 7.0±0.20 0.5±0.10 1.0±0.15 1.5±0.20 2.0±0.25
∅7.5 7.5±0.20 0.5±0.10 1.0±0.15 1.5±0.20 2.0±0.25
∅8.0 8.0±0.25 0.5±0.10 1.0±0.15 1.5±0.20 2.0±0.25
∅9.0 9.0±0.25 0.5±0.10 1.0±0.15 1.5±0.20 2.0±0.25
∅10.0 10.0±0.25 0.5±0.10 1.0±0.15 1.5±0.20 2.0±0.25
∅11.0 11.0±0.30 0.5±0.10 1.0±0.15 1.5±0.20 2.0±0.25
∅12.0 12.0±0.30 0.5±0.10 1.0±0.15 1.5±0.20 2.0±0.25
∅13.0 13.0±0.30 0.5±0.10 1.0±0.15 1.5±0.20 2.0±0.25
∅14.0 14.0±0.30 0.5±0.10 1.0±0.15 1.5±0.20 2.0±0.25
∅15.0 15.0±0.30 0.5±0.10 1.0±0.15 1.5±0.20 2.0±0.25
∅20.0 20.0±0.30 0.5±0.10 1.0±0.15 1.5±0.20 2.0±0.25

Food grade extruded soft silicone rubber tubing for home appliances

Food grade extruded soft silicone rubber tubing for home appliances

Competitive Advantages

1) ISO 9001 : 2008 TS 16949 standard factory manufacturer

2) high-tech enterprise in China

3) with 12-year manufacturing experience

4) factory direct sales

5) best price high quality product

6) quick delivery time

7) quick response for feedback

8) few complaints from customers

9) more competitive price for VIP customers

10) convenient situation near to seaport

11) UL , RoHS , Reach approval

12) the only factory in China for all sizes and full colors to pass UL, RoHS, Reach certifications

13) high quality non-alkali fiberglass yarn

14) cutting service and special customized service can be available

15) 3KV & 10KV tube of this type can be customized

Sunbow Progress

1) Established in Oct. 2003, Sunbow is mainly engaged in research & development, manufacture and sale of various kinds of insulation sleeving. Such as fiberglass sleeving, PTFE tube, silicone rubber tube, PE heat shrink tube and PVC tube etc;

2) Due to expansion in business, Sunbow factory moved to Sunbow Industrial Park, 2nd Industrial Zone, Xiacun Community, Gongming , Guangming New District, Shenzhen;

3) In Oct. 2008, Sunbow achieved success of general taxpayer qualification (Namely Sunbow can open 17% VAT invoices by ourselves;

4) In Oct. 2009, Sunbow achieved success in ISO 9001:2008 quality management system certification;

5) In Feb. 2010, Sunbow successfully obtained UZIQ2: E333178 safety certificate by UL lab for fiberglass sleeving coated silicone resin;

6) In June, 2010, Sunbow set a new branch office in Hong Kong. It named HONG KONG SUNBOW INDUSTRIES CO., LIMITED;

7) In Aug. 2010, Sunbow applied for import and export , Sunbow has independent rights for import and export;

8) In Nov. 2010, the registered trademark of Shenzhen Sunbow Insulation Materials MFG. CO., LTD was approved entry to force;

9) In Feb. 2011, Sunbow obtained American UZFT2: E333177 certificate and Canadian CSA UZFT8:333177 certificate for fiberglass sleeving coated silicone resin;

10) In Jan. 2013, Sunbow successfully obtained YDPU2: E360625 safety certificate by UL lab for PE shrinkable tubing, PTFE tubing and silicone rubber tubing;

11) In Apr. 2014, Sunbow successfully obtained YDQS2: E467953 safety certificate by UL alb for PVC tubing;

12) In May, 2015, Sunbow successfully gained TS16949 certificate for automobile industry.
