P2.6mm & P2.9mm COB Commercial Advertising Led Display Front Maintenance HD LED Display
P2.6mm & P2.9mm COB Commercial Advertising Led Display Front Maintenance HD LED Display
P2.6mm & P2.9mm COB Commercial Advertising Led Display Front Maintenance HD LED Display
P2.6mm & P2.9mm COB Commercial Advertising Led Display Front Maintenance HD LED Display
P2.6mm & P2.9mm COB Commercial Advertising Led Display Front Maintenance HD LED Display
P2.6mm & P2.9mm COB Commercial Advertising Led Display Front Maintenance HD LED Display
P2.6mm & P2.9mm COB Commercial Advertising Led Display Front Maintenance HD LED Display
P2.6mm & P2.9mm COB Commercial Advertising Led Display Front Maintenance HD LED Display
P2.6mm & P2.9mm COB Commercial Advertising Led Display Front Maintenance HD LED Display
P2.6mm & P2.9mm COB Commercial Advertising Led Display Front Maintenance HD LED Display
P2.6mm & P2.9mm COB Commercial Advertising Led Display Front Maintenance HD LED Display
P2.6mm & P2.9mm COB Commercial Advertising Led Display Front Maintenance HD LED Display
Specifications
Brand Name :
SILU
Model Number :
P2.6mm/P2.9mm
Certification :
CE, CCC, RoHS
Place of Origin :
China
MOQ :
1 pc
Payment Terms :
T/T
Supply Ability :
600 m² per Month
Delivery Time :
20 Days
Packaging Details :
Wooden case, flight case
Price :
USD1680.00-4260.00 per m²
Pixel Pitch :
2.6mm/2.9mm
Leds :
SMD2121/1921
ICs :
MBI5153/CH2153/2053
PCB :
SILU Class A 4 layers 1.6mm
Brightness :
1000~5000nits
Refresh Rate :
3840Hz
Lifetime :
100000 Hours
Warranty :
2-3 Years
Description

P2.6mm & P2.9mm COB Front Maintenance LED Display Indoor & outdoor HD LED Display

2.604mm & 2.976mm pixel pitch, 1,000nits+ brightness (3,500 nits), indoor & outdoor rental or fixed applications

  • Silu`s front maintenance LED screen series
  • SMD2121/1921 LED lamps
  • MBI5153 or CH2153/2053 driving ICs
  • 2 Layers 1.6mm Thickness PCB
  • 250mmx250mm Size LED module
  • 500mmx500mm or 500mmx1000mm Size LED cabinet
  • Slim and lightweight support easy and quick seamless assembling
  • 2.6m~100m better viewing distance (according to the video wall size)
  • 160° Horizontal and 140° Vertical wide viewing angles
  • 3840Hz high refresh rate guarantee that no scan line when taking photos and videos
  • High colour uniformity and fidelity offers vivid audio-visual enjoyment

Silu`s P2.6mm & P2.9mm COB Front Maintenance LED Display Indoor & outdoor HD LED Display is assembled with modular 500mmx500mm die-casting aluminium material LED cabinets, no fans, no noise, quiet when operation, but good heat dissipation. The P2.6mm & P2.9mm COB Front Maintenance LED Display Indoor & outdoor HD LED Display adopts black SMD2121 LEDs (indoor), SMD1921 LEDs (outdoor), MBI or Chipone driving ICs with high contrast (5000:1), high refresh rate (3840 Hz), great grey scale (65536 levels), the P2.6mm & P2.9mm COB Front Maintenance LED Display Indoor & outdoor HD LED Display is becoming more and more popular for indoor and outdoor rental markets or fixed installation projects, and now is widely used in media advertising, transportation, security, real estate and stage show background, advertising, TVstation, applied to monitor the command, television, senior frequency conference, cinema, shopping malls and other venues. The broadcast system has multimedia software, can flexibly input and play different information.

Front maintenance capability makes this P2.6mm & P2.9mm COB Front Maintenance LED Display Indoor & outdoor HD LED Display is quick and simple for assembling or disassembling, saving time and labour costs.
Our P2.6mm & P2.9mm COB Front Maintenance LED Display Indoor & outdoor HD LED Display supports both indoor & outdoor rental and fixed installations, which surely can be a better ideal choice for mounting a large indoor & outdoor high-definition rental or fixed LED screen wall.

For more details, pls. contact us at saga@atsilu.com or +86-1371700700.

P2.6mm & P2.9mm COB Commercial Advertising Led Display Front Maintenance HD LED Display

P2.6mm & P2.9mm COB Commercial Advertising Led Display Front Maintenance HD LED Display

Technical Specification

P2.6mm Front Maintenance LED Display
Pixel Pitch 2.6mm (0.1024") 2.97mm*
LED Brand Nationstar & Customized*
Pixel Configuration 1R1G1B
Pixel Density 147,456 Pixels/m²
LED Module Size: 250mmx250mm (9.45"x9.45")
Resolution: 96*96 Pixels
LED Cabinet* Size: 500mmx500mm (19.685"x19.685")
Resolution: 192x192 pixels
Material: Aluminum
Weight: <6Kg (13.2 Lbs)
Working Voltage AC220V±10%; AC110V±10%
Power Consumption Average 280W/m² / Max 850W/m²
Maximum Brightness >1,000 cd/m²
Refresh Frequency >3,840Hz/S
Change Frame Frequency 50Hz~60Hz
Drive Mode 1/16 Scanning
Total Colors 281 Trillion Colors
Grade Level RGB 65536 Grade
Best Viewing Distance 2m~>100m (6ft~>300ft)
Best Viewing Angle Horizontally 160° / Vertically 140°
Screen Lifetime >100,000 hours
Protection Level IP43 (IP65)
Ambient Temperature -40°C ~ 60°C (-30°F~150°F)
Relative Humidity 10%~90%
Control System* Simple LED Video Control System or Advanced LED Video Processor
Input Signal RF S-Video RGB RGBHV YUVYC etc.
Brightness Adjustment* 256 levels of each colour (RGB) can be adjusted manually and 8 levels of each colour can be adjusted automatically. Optional control system: 256 levels of each colour can be adjusted 100% automatically. (8bit / 16bit / 18bit / 24bit)
Package Method* Wooden Case / Flight Case
Warranty Date* 2 Years (3 Years for Cree and Nichia)
