P12.5mm Outdoor Led Curtain Screen Building Facade Digital Media LED Mesh Wall
P12.5mm Outdoor Led Curtain Screen Building Facade Digital Media LED Mesh Wall
P12.5mm Outdoor Led Curtain Screen Building Facade Digital Media LED Mesh Wall
P12.5mm Outdoor Led Curtain Screen Building Facade Digital Media LED Mesh Wall
P12.5mm Outdoor Led Curtain Screen Building Facade Digital Media LED Mesh Wall
P12.5mm Outdoor Led Curtain Screen Building Facade Digital Media LED Mesh Wall
P12.5mm Outdoor Led Curtain Screen Building Facade Digital Media LED Mesh Wall
P12.5mm Outdoor Led Curtain Screen Building Facade Digital Media LED Mesh Wall
P12.5mm Outdoor Led Curtain Screen Building Facade Digital Media LED Mesh Wall
P12.5mm Outdoor Led Curtain Screen Building Facade Digital Media LED Mesh Wall
P12.5mm Outdoor Led Curtain Screen Building Facade Digital Media LED Mesh Wall
P12.5mm Outdoor Led Curtain Screen Building Facade Digital Media LED Mesh Wall
Specifications
Brand Name :
SILU
Model Number :
P12.5mm
Certification :
CE, CCC, RoHS
Place of Origin :
China
MOQ :
1 pc
Payment Terms :
T/T
Supply Ability :
1000 m² per Month
Delivery Time :
20 Days
Packaging Details :
Wooden case
Price :
USD1180.00-2360.00 per m²
Leds :
SMD3535/DIP346
ICs :
MBI
PCB :
4 layers 1.6mm Class A
Brightness :
>6500 nits
Refresh Rate :
>1920 Hz
IP Grade :
IP65
Lifetime :
100000 Hours
Warranty :
3 Years
Description

P12.5mm Outdoor LED Video Curtain Screen Building Facade Digital Media LED Mesh Wall

12.5mm pixel pitch, 6,000nits+ brightness, outdoor fixed applications

  • Silu`s transparent LED curtain screen series
  • SMD3535/DIP346 LED lamps
  • MBI5153 or CH2053 driving ICs
  • 500mmx250mm Size LED module
  • 1000mmx1000mm or 1000mmx2000mm Size LED cabinet
  • More than 65% transparency rate
  • Slim and lightweight support easy and quick seamless assembling
  • 12m~500m better viewing distance (according to the video wall size)
  • 140° Horizontal and 140° Vertical wide viewing angles
  • 1920~3840Hz high refresh rate guarantee that no scan line when taking photos and videos
  • High colour uniformity and fidelity offers vivid audio-visual enjoyment

Silu`s P12.5mm Outdoor LED Video Curtain Screen Building Facade Digital Media LED Mesh Wall is designed and provided to the customers who want a special pixel pitch outdoor LED curtain display with the conventional markets, so it comes from the past years, with the standard LED module size 500mmx250mm, good quality high brightness Nationstar SMD3535 LED lamps or EPstar DIP346 LED lamps and high refresh rate MBI driving ICs, combining with IP65 grade waterproof design, that guarantees the P12.5mm Outdoor LED Video Curtain Screen Building Facade Digital Media LED Mesh Wall can work very well even in rainy or sunlight days.

Advanced design and well-made fast locks give it advantages to its quick assembly, disassembly and transportation.

Excellent material and workmanship guarantee its quality and dependability.

Accurate CNC technology makes the seamless connection reach to ±0.05mm so as to display perfectly.

None Cooling fan design and noiseless power supply are considered to be silent LED video wall.

The P12.5mm Outdoor Facade Transparent LED Display Digital Advertising Curtain LED Screen Wall`s cabinet size can be customized according to the building glass size. It is mounted behind a glass wall but displays towards outside.

Our P12.5mm Outdoor LED Video Curtain Screen Building Facade Digital Media LED Mesh Wall supports outdoor fixed installations.

For more details, pls. contact us at saga@atsilu.com or +86-1371700700.

P12.5mm Outdoor Led Curtain Screen Building Facade Digital Media LED Mesh Wall

Technical Specification

P12.5mm Transparent LED Curtain Display
Pixel Pitch 12.5mm (0.5") (V.&H.)
LED Brand Nationstar & Customized*
Pixel Configuration 1R1G1B
Pixel Density 6,400 Pixels/m²
LED Module Size: 500mmx250mm (18.9"x9.45")
Resolution: 40*20 Pixels
LED Cabinet* Size: 1000mmx1000mm (39.37"x39.37")
Resolution: 80x80 pixels
Material: Aluminum
Weight: <26Kg (57.2 Lbs)
Working Voltage AC220V±10%; AC110V±10%
Power Consumption Average 320W/m² / Max 900W/m²
Maximum Brightness >6,000 cd/m²
Refresh Frequency >1920~3,840Hz/S
Change Frame Frequency 50Hz~60Hz
Drive Mode 1/4 Scanning
Total Colors 281 Trillion Colors
Grade Level RGB 65536 Grade
Best Viewing Distance 12m~>300m (36ft~>900ft)
Best Viewing Angle Horizontally 140° / Vertically 140°
Screen Lifetime >100,000 hours
Protection Level Front IP65 / Rear IP54
Ambient Temperature -40°C ~ 60°C (-30°F~150°F)
Relative Humidity 10%~90%
Control System* Simple LED Video Control System or Advanced LED Video Processor
Input Signal RF S-Video RGB RGBHV YUVYC etc.
Brightness Adjustment* 256 levels of each colour (RGB) can be adjusted manually and 8 levels of each colour can be adjusted automatically. Optional control system: 256 levels of each colour can be adjusted 100% automatically. (8bit / 16bit / 18bit / 24bit)
Package Method* Wooden Case / Flight Case
Warranty Date* 3 Years (5 Years for Cree and Nichia)
