P10mm Outdoor Front Service Led Display SMD3535 & DIP346 Digital Advertising Screen
P10mm Outdoor Front Service Led Display SMD3535 & DIP346 Digital Advertising Screen
P10mm Outdoor Front Service Led Display SMD3535 & DIP346 Digital Advertising Screen
P10mm Outdoor Front Service Led Display SMD3535 & DIP346 Digital Advertising Screen
P10mm Outdoor Front Service Led Display SMD3535 & DIP346 Digital Advertising Screen
P10mm Outdoor Front Service Led Display SMD3535 & DIP346 Digital Advertising Screen
P10mm Outdoor Front Service Led Display SMD3535 & DIP346 Digital Advertising Screen
P10mm Outdoor Front Service Led Display SMD3535 & DIP346 Digital Advertising Screen
P10mm Outdoor Front Service Led Display SMD3535 & DIP346 Digital Advertising Screen
P10mm Outdoor Front Service Led Display SMD3535 & DIP346 Digital Advertising Screen
P10mm Outdoor Front Service Led Display SMD3535 & DIP346 Digital Advertising Screen
P10mm Outdoor Front Service Led Display SMD3535 & DIP346 Digital Advertising Screen
P10mm Outdoor Front Service Led Display SMD3535 & DIP346 Digital Advertising Screen
P10mm Outdoor Front Service Led Display SMD3535 & DIP346 Digital Advertising Screen
Specifications
Brand Name :
SILU
Model Number :
P10mm
Certification :
CE, CCC, RoHS
Place of Origin :
China
MOQ :
1 pc
Payment Terms :
T/T
Supply Ability :
1000 m² per Month
Delivery Time :
20 Days
Packaging Details :
Wooden case
Price :
USD1380.00-2960.00 per m²
Leds :
DIP346/SMD3535
ICs :
MBI5124
PCB :
SILU Class A
Brightness :
>6500 nits
Refresh Rate :
>1920 Hz
Colors :
RGB full color
Lifetime :
10 Years
Warranty :
3 Years
Description

P10mm Outdoor Front Maintenance LED Display SMD3535 & DIP346 Digital Advertising Screen

10.0mm pixel pitch, 6,500nits+ (max.10,000nits) brightness, IP65 rated outdoor fixed applications

  • Silu`s front maintenance LED screen series
  • SMD3535/DIP346 LED lamps
  • MBI5124 driving ICs
  • 2 Layers 1.6mm Thickness PCB
  • 320mmx320mm Size LED module
  • 960mmx960mm Size LED cabinet
  • IP65~IP67* rating waterproof and dustproof
  • Rugged and lightweight support easy and quick seamless assembling
  • 10m~500m better viewing distance (max. viewing according to the video wall size)
  • 140° Horizontal and 140° Vertical wide viewing angles
  • 1920 Hz high refresh rate guarantee that no scan line when taking photos and videos
  • High colour uniformity and fidelity offers vivid audio-visual enjoyment

Silu`s P10mm Outdoor Front Maintenance LED Display SMD3535 & DIP346 Digital Advertising Screen is combining with the front access 320mmx320mm sized LED module and the 960mmx960mm sized LED cabinet, which features a wide viewing angle of 140° horizontal and 140° in vertical, so the advertising contents can reach a wide range of viewers from different directions. The P10mm Outdoor Front Maintenance LED Display SMD3535 & DIP346 Digital Advertising Screen is a high-performance LED display by using Nationstar SMD3535 or Epstar DIP346 LEDs, which delivers more than 6,500nits (max. 10,000 nits) high brightness, make sure the content on the LED display can be seen clearly even in the sunlight days, and IP65 protection grade make sure the P10mm Outdoor Front Maintenance LED Display SMD3535 & DIP346 Digital Advertising Screen is a real outdoor waterproof and dustproof LEd visualization product.

By using lightweight aluminium material LED cabinet, the P10mm Outdoor Front Maintenance LED Display SMD3535 & DIP346 Digital Advertising Screen can be assembled and disassembled very easy and fast. The lightweight LED cabinet is also easy for workers to mount a large screen, saving labour cost and time, so we can say, it is really a better solution for any of outdoor fixed advertising projects.

Our P10mm Outdoor Front Maintenance LED Display SMD3535 & DIP346 Digital Advertising Screen is manufactured by using the best quality raw material and advanced production technology, it features supreme quality and offers the best outputs to ensure the image and video quality remains seamless.

For more details, pls. contact us at saga@atsilu.com or +86-1371700700.

P10mm Outdoor Front Service Led Display SMD3535 & DIP346 Digital Advertising Screen

P10mm Outdoor Front Service Led Display SMD3535 & DIP346 Digital Advertising Screen

P10mm Outdoor Front Service Led Display SMD3535 & DIP346 Digital Advertising Screen

Technical Specification

P10mm Front Maintenance LED Display
Pixel Pitch 10.0mm (0.3937")
LED Brand Nationstar SMD3535 or Epstar DIP346
Pixel Configuration 1R1G1B
Pixel Density 10,000 Pixels/m²
LED Module Size: 320mmx160mm (12.6"x6.3")
Resolution: 32*16 Pixels
LED Cabinet* Size: 960mmx960mm (37.8"x37.8")
Resolution: 96x96 pixels
Material: Aluminum or Steel
Weight: <36Kg (79.2 Lbs) or 45Kg (99 Lbs)
Working Voltage AC220V±10%; AC110V±10%
Power Consumption Average 360W/m² / Max 960W/m²
Maximum Brightness >6,500 (max.10,000) cd/m²
Refresh Frequency >1920~3,840Hz/S
Change Frame Frequency 50Hz~60Hz
Drive Mode 1/2 or 1/4 Scanning
Total Colors 281 Trillion Colors
Grade Level RGB 65536 Grade
Best Viewing Distance 10m~>300m (30ft~>900ft)
Best Viewing Angle Horizontally 140° / Vertically 140°
Screen Lifetime >100,000 hours
Protection Level Front IP65 / Rear IP54
Ambient Temperature -40°C ~ 60°C (-30°F~150°F)
Relative Humidity 10%~90%
Control System* Simple LED Video Control System or Advanced LED Video Processor
Input Signal RF S-Video RGB RGBHV YUVYC etc.
Brightness Adjustment* 256 levels of each colour (RGB) can be adjusted manually and 8 levels of each colour can be adjusted automatically. Optional control system: 256 levels of each colour can be adjusted 100% automatically. (8bit / 16bit / 18bit / 24bit)
Package Method* Wooden Case / Flight Case
Warranty Date* 3 Years (5 Years for Cree and Nichia)
