Specifications
Brand Name :
SILU
Model Number :
P2.5mm
Certification :
CE, CCC, RoHS
Place of Origin :
China
MOQ :
1 pc
Payment Terms :
T/T
Supply Ability :
500 m² per Month
Delivery Time :
20 Days
Packaging Details :
Wooden case, flight case
Price :
USD1880.00-2860.00 per m²
Pixel Pitch :
2.5mm
Leds :
SMD black
ICs :
MBI
PCB :
SILU Class A
Viewing Distance :
>2m
Viewing Angle :
>160°
Lifetime :
100000 Hours
Warranty :
2 Years
Description

P2.5mm Performance LED Video Wall Indoor High-Resolution Quality Large LED Display

2.5mm pixel pitch, 1,000nits+ brightness, indoor rental or fixed applications

  • Silu`s high-definition indoor series
  • SMD1010 LED lamps
  • MBI5153 or CH2153 driving ICs
  • 2~4 Layers 2.0mm Thickness PCB
  • 240mmx240mm or 160mmx160mm Size LED module
  • 480mmx480mm Size LED cabinet
  • Slim and lightweight support easy and quick seamless assembling
  • 2m~50m better viewing distance
  • 160° Horizontal and 140° Vertical wide viewing angles
  • 3840Hz high refresh rate guarantee that no scan line when taking photos and videos
  • High colour uniformity and fidelity offers vivid audio-visual enjoyment

Silu`s P2.5mm Performance LED Video Wall Indoor High-Resolution Quality Large LED Display is combining with the super lightweight die-casting aluminium LED cabinet sized 480mmx480mm, pixel pitch is 2.5mm, it is the latest new inventions LED display product, which is good for stage concerts, conference, exhibitions, wedding led screen events, advertising, promotional events, etc.

The P2.5mm Performance LED Video Wall Indoor High-Resolution Quality Large LED Display is designed and produced for high-end indoor LED rental markets with high-quality raw material and LED configurations. Wide viewing angle, high contrast (5000: 1), high intensity (16bit gradation processing), high refresh (1920HZ refresh rate), display lifelike images to meet the high-speed motion picture display. Meanwhile, the super light LED panel with smaller space and easy for transportation and assembly.

By using our P2.5mm Performance LED Video Wall Indoor High-Resolution Quality Large LED Display product, the rental events, broadcasting and advertising operators can easily mount a 2K, 4K, and even 8K large resolution indoor large LED screen wall.

For more details, pls. contact us at saga@atsilu.com or +86-1371700700.

P2.5mm Performance Led Video Wall Screen Indoor High - Resolution Quality Large LED Display

P2.5mm Performance Led Video Wall Screen Indoor High - Resolution Quality Large LED Display

Technical Specification

P2.5mm HD LED Video Wall Display
Pixel Pitch 2.5mm (0.1")
LED Brand Nationstar*
Pixel Configuration 1R1G1B
Pixel Density 160,000 Pixels/m²
LED Module Size: 240mmx240mm (9.45"x9.45")
Resolution: 96*96 Pixels
LED Cabinet Size: 480mmx480mm (18.9"x18.9")
Resolution: 192*192 pixels
Material: Aluminum
Weight: <6Kg (13.2 Lbs)
Working Voltage AC220V±10%; AC110V±10%
Power Consumption Average 380W/m² / Max 850W/m²
Maximum Brightness >1,000 cd/m²
Refresh Frequency >3,840Hz/S
Change Frame Frequency 50Hz~60Hz
Drive Mode 1/32 Scanning
Total Colors 281 Trillion Colors
Grade Level RGB 65536 Grade
Best Viewing Distance 2m~>50m (6ft~>150ft)
Best Viewing Angle Horizontally 160° / Vertically 140°
Screen Lifetime >100,000 hours
Protection Level IP43
Ambient Temperature -40°C ~ 60°C (-30°F ~ 150°F)
Relative Humidity 10%~90%
Control System* Simple LED Video Control System or Advanced LED Video Processor
Input Signal RF S-Video RGB RGBHV YUVYC etc.
Brightness Adjustment* 256 levels of each colour (RGB) can be adjusted manually and 8 levels of each colour can be adjusted automatically. Optional control system: 256 levels of each colour can be adjusted 100% automatically. (8bit / 16bit / 18bit / 24bit)
Package Method* Wooden Case / Flight Case
Warranty Date* 2 Years (3 Years for Cree and Nichia)
