Specifications
Brand Name :
SILU
Model Number :
P3mm
Certification :
CE, CCC, RoHS
Place of Origin :
China
MOQ :
1 pc
Payment Terms :
T/T
Supply Ability :
1000 m² per Month
Delivery Time :
20 Days
Packaging Details :
Flight case
Price :
USD2980.00-6860.00 per m²
Pixel Pitch :
3mm
Viewing Distance :
>3m
Viewing Angle :
>160 degree
Leds :
SMD1921 black
Brightness :
>3500 nits
ICs :
MBI5153/CH2053
Refresh Rate :
3840 Hz
Warranty :
3 Years
Description

P3mm Outdoor High-Definition Rental LED Display Stage Hire IP65 LED Screen Wall Display

3.0mm pixel pitch, 3,500 nits+ brightness, outdoor rental applications

  • Silu`s outdoor high-definition rental LED screen series
  • SMD1921 LED lamps
  • MBI5153 or CH2053 16bits driving ICs
  • 2~4 Layers 2.0mm Thickness PCB
  • 192mmx192mm or 240mmx240mm Size LED module
  • 480mmx480mm or 576mmx576mm Size LED cabinet
  • Slim and lightweight support easy and quick seamless assembling
  • 3m~50m better viewing distance
  • 160° Horizontal and 140° Vertical wide viewing angles
  • 3840Hz high refresh rate guarantee that no scan line when taking photos and videos
  • High colour uniformity and fidelity offers vivid audio-visual enjoyment

Silu`s P3mm Outdoor High-Definition Rental LED Display Stage Hire IP65 LED Screen Wall Display is an outdoor high-definition LED display, it is rugged, IP65 rated solutions that deliver high-resolution images with unequalled brightness and contrast levels, it generates the perfect picture at all times, even in direct sunlight. The P3mm Outdoor High-Definition Rental LED Display Stage Hire IP65 LED Screen Wall Display is particularly suited to high definition outdoor applications, may be used for rental and fixed applications.
The P3mm Outdoor High-Definition Rental LED Display Stage Hire IP65 LED Screen Wall Display adopts most advanced COB LED technology, by using high quality from well-known companies, this P3mm Outdoor High-Definition Rental LED Display Stage Hire IP65 LED Screen Wall Display can be easy to mount a 2K, 4K, or even 8K resolution outdoor large LED video wall. Its high brightness (more then 3,500cd/m²) , good contrast raion (5000:1), high grey scale (65536 levels), high refresh rate (3840hz) and IP65 outdoor waterproof and dustproof protection, that guarantee this P3mm Outdoor High-Definition Rental LED Display Stage Hire IP65 LED Screen Wall Display to be a real high-resolution outdoor LED display.
The P3mm Outdoor High-Definition Rental LED Display Stage Hire IP65 LED Screen Wall Display is one of the most mature rentals LED display in stage performance, bar entertainment, ceremonial wedding, conference, exhibition, musical theatre, etc. industry, etc. It came along announced the successful application of Aluminum Die-casting technology in the LED display market. With features of weight, portable, easy to install & dismantle. Fanless design and good heat dissipation make rental events labour-saving, high efficiency and cost-effective.
For more details, pls. contact us at saga@atsilu.com or +86-1371700700.

P3mm Outdoor High-Definition Rental LED Display Stage Hire IP65 LED Screen

P3mm Outdoor High-Definition Rental LED Display Stage Hire IP65 LED Screen

Technical Specification

P3mm HD Outdoor Rental LED Display
Pixel Pitch 3mm (0.12")
LED Brand Nationstar*
Pixel Configuration 1R1G1B
Pixel Density 111,111 Pixels/m²
LED Module Size: 240mmx240mm (9.45"x9.45")
Resolution: 80*80 Pixels
LED Cabinet Size: 480mmx480mm (18.9"x18.9")
Resolution: 160 pixels x 160 pixels
Material: Aluminum
Weight: <6.8Kg (15 Lbs)
Working Voltage AC220V±10%; AC110V±10%
Power Consumption Average 360W/m² / Max 960W/m²
Maximum Brightness >3,500 cd/m²
Refresh Frequency >3,840Hz/S
Change Frame Frequency 50Hz~60Hz
Drive Mode 1/16 Scanning
Total Colors 281 Trillion Colors
Grade Level RGB 65536 Grade
Best Viewing Distance 3m~>100m (9ft~>300ft)
Best Viewing Angle Horizontally 160° / Vertically 140°
Screen Lifetime >100,000 hours
Protection Level IP65
Ambient Temperature -40°C ~ 60°C (-30°F ~ 150°F)
Relative Humidity 10%~90%
Control System* Simple LED Video Control System or Advanced LED Video Processor
Input Signal RF S-Video RGB RGBHV YUVYC etc.
Brightness Adjustment* 256 levels of each colour (RGB) can be adjusted manually and 8 levels of each colour can be adjusted automatically. Optional control system: 256 levels of each colour can be adjusted 100% automatically. (8bit / 16bit / 18bit / 24bit)
Package Method* Wooden Case / Flight Case
Warranty Date* 2 Years (3 Years for Cree and Nichia)
