Specifications
Brand Name :
SILU
Model Number :
P5mm
Certification :
CE, CCC, RoHS
Place of Origin :
China
MOQ :
1 pc
Payment Terms :
T/T
Supply Ability :
1000 m² per Month
Delivery Time :
18 Days
Packaging Details :
Flight case
Price :
USD1680.00-2860.00 per m²
Pixel Pitch :
5mm
Leds :
SMD2727
ICs :
MBI
PCB :
Class A 4 layers
Viewing Distance :
>5m
Viewing Angle :
>140 degree
Brightness :
>5500 nits
Warranty :
3 Years
Description

P5mm Outdoor Rental LED Display 640mm Size LED Screen Panel Rent Large LED Video Display

5.0mm pixel pitch, 5,500nits+ brightness, IP65 rated outdoor rental applications

  • Silu`s outdoor rental LED screen series
  • SMD2727 LED lamps
  • MBI5124 or CH2053/2038s driving ICs
  • 2 Layers 1.6mm Thickness PCB
  • 320mmx160mm Size LED module
  • 640mmx640mm Size LED cabinet
  • IP65~IP67* rating waterproof and dustproof
  • Seamless and lightweight support easy and quick seamless assembling
  • 5m~300m better viewing distance (max. viewing according to the video wall size)
  • 140° Horizontal and 140° Vertical wide viewing angles
  • 1920~3840Hz high refresh rate guarantee that no scan line when taking photos and videos
  • High colour uniformity and fidelity offers vivid audio-visual enjoyment

Silu`s P5mm Outdoor Rental LED Display 640mm Size LED Screen Panel Rent Large LED Video Display is selling to the outdoor rental or fixed installation broadcasting or advertising digital LED wall markets, which offers 65536 levels grey scale and 4500:1 contrast ratio, that makes the P5mm Outdoor Rental LED Display 640mm Size LED Screen Panel Rent Large LED Video Display delivers high-definition image and video quality, IP65 waterproof protection and more than 5,500 nits high brightness that assures the passengers can read the contents clearly on the LED display with good colour fidelity and colour uniformity, up to natural colour, it is a kind of amazing outdoor large video wall screen.

The P5mm Outdoor Rental LED Display 640mm Size LED Screen Panel Rent Large LED Video Display comes with a close viewing distance 5m and large viewing angle 140 degrees, lightweight die-casting aluminium led cabinet make sure it can be installed easily and quickly for any of rental events, IP65 waterproof and dustproof design guarantee it can be used and works normally in rainy days.

Our P5mm Outdoor Rental LED Display 640mm Size LED Screen Panel Rent Large LED Video Display supports outdoor rental or fixed installation occasions, which surely can be one of the better ideal choices for mounting a large outdoor high-definition LED digital screen wall.

For more details, pls. contact us at saga@atsilu.com or +86-1371700700.

P5mm Rental Outdoor Advertising Led Display Screen 640mm Size Waterproof And Dustproof

P5mm Rental Outdoor Advertising Led Display Screen 640mm Size Waterproof And Dustproof

Technical Specification

P5mm Outdoor Rental LED Display
Pixel Pitch 5.0mm (0.197")
LED Brand Nationstar & Customized*
Pixel Configuration 1R1G1B
Pixel Density 40,000 Pixels/m²
LED Module Size: 320mmx160mm (12.6"x6.3")
Resolution: 64*32 Pixels
LED Cabinet* Size: 640mmx640mm (25.2"x25.2")
Resolution: 128x128 pixels
Material: Aluminum
Weight: <13Kg (28.6 Lbs)
Working Voltage AC220V±10%; AC110V±10%
Power Consumption Average 360W/m² / Max 960W/m²
Maximum Brightness >5,500 cd/m²
Refresh Frequency >1920~3,840Hz/S
Change Frame Frequency 50Hz~60Hz
Drive Mode 1/8 Scanning
Total Colors 281 Trillion Colors
Grade Level RGB 65536 Grade
Best Viewing Distance 4m~>100m (9ft~>300ft)
Best Viewing Angle Horizontally 140° / Vertically 140°
Screen Lifetime >100,000 hours
Protection Level Front IP65 / Rear IP54
Ambient Temperature -40°C ~ 60°C (-30°F~150°F)
Relative Humidity 10%~90%
Control System* Simple LED Video Control System or Advanced LED Video Processor
Input Signal RF S-Video RGB RGBHV YUVYC etc.
Brightness Adjustment* 256 levels of each colour (RGB) can be adjusted manually and 8 levels of each colour can be adjusted automatically. Optional control system: 256 levels of each colour can be adjusted 100% automatically. (8bit / 16bit / 18bit / 24bit)
Package Method* Wooden Case / Flight Case
Warranty Date* 3 Years (5 Years for Cree and Nichia)
