P10 Epstar DIP346 Outdoor LED Display Super Quality High Brightness LED Screen Billboard
P10 Epstar DIP346 Outdoor LED Display Super Quality High Brightness LED Screen Billboard
P10 Epstar DIP346 Outdoor LED Display Super Quality High Brightness LED Screen Billboard
P10 Epstar DIP346 Outdoor LED Display Super Quality High Brightness LED Screen Billboard
P10 Epstar DIP346 Outdoor LED Display Super Quality High Brightness LED Screen Billboard
P10 Epstar DIP346 Outdoor LED Display Super Quality High Brightness LED Screen Billboard
P10 Epstar DIP346 Outdoor LED Display Super Quality High Brightness LED Screen Billboard
P10 Epstar DIP346 Outdoor LED Display Super Quality High Brightness LED Screen Billboard
P10 Epstar DIP346 Outdoor LED Display Super Quality High Brightness LED Screen Billboard
P10 Epstar DIP346 Outdoor LED Display Super Quality High Brightness LED Screen Billboard
Specifications
Brand Name :
SILU
Model Number :
P10mm
Certification :
CE, CCC, FCC, RoHS, UL*
Place of Origin :
China
MOQ :
1 m²
Payment Terms :
T/T
Supply Ability :
1000 m² per Month
Delivery Time :
25 Days
Packaging Details :
Wooden case
Price :
USD1380.00-2660.00 per m²
Leds :
DIP346
Led chip :
Epstar & Silan
Pixel configuration :
1R1G1B
Colors :
Full color 281 Trillions
Brightness :
>8,000 nits
Refresh Rate :
>1920 Hz
Lifetime :
100000 Hours
Warranty :
3 Years
Description

P10 Epstar DIP346 Outdoor LED Display Super Quality High Brightness LED Screen Billboard

10.0mm pixel pitch, 8,000nits+ (max.10,000nits) brightness, IP65 rated outdoor fixed applications

  • Silu`s unique and private design
  • Epstar DIP346 LED lamps
  • MBI5124 driving ICs
  • 2 Layers 1.6mm Thickness PCB
  • 160mmx160mm Size LED module
  • 960mmx960mm Size LED cabinet
  • IP65~IP67* rating waterproof and dustproof
  • Rugged and lightweight support easy and quick seamless assembling
  • 10m~500m better viewing distance (max. viewing according to the video wall size)
  • 120° Horizontal and 100° Vertical wide viewing angles
  • 1920Hz high refresh rate guarantee that no scan line when taking photos and videos
  • High colour uniformity and fidelity offers vivid audio-visual enjoyment

Silu`s P10 Epstar DIP346 Outdoor LED Display Super Quality High Brightness LED Screen Billboard is certainly to be the best option for outdoor advertising, this outdoor LED display carries some features that make it highly suitable for any of outdoor environments, thanks to its super quality Epstar DIP346 high brightness and stability LED lamps. The P10 Epstar DIP346 Outdoor LED Display Super Quality High Brightness LED Screen Billboard can work in different brightness level and outdoor circumstances, such as the very hot and very cold outdoor areas.
Our P10 Epstar DIP346 Outdoor LED Display Super Quality High Brightness LED Screen Billboard is manufactured by using the best quality raw material and advanced production technology, it features supreme quality and offers the best outputs to ensure the image and video quality remains seamless on 7*24 hours.

For more details, pls. contact us at saga@atsilu.com or +86-1371700700.

P10 Epstar DIP346 Outdoor LED Display Super Quality High Brightness LED Screen Billboard

P10 Epstar DIP346 Outdoor LED Display Super Quality High Brightness LED Screen Billboard

Technical Specification

P10mm DIP Outdoor LED Display
Pixel Pitch 10.0mm (0.3937")
LED Brand Nationstar & Customized*
Pixel Configuration 1R1G1B
Pixel Density 10,000 Pixels/m²
LED Module Size: 160mmx160mm (6.3"x6.3")
Resolution: 16*16 Pixels
LED Cabinet* Size: 960mmx960mm (37.8"x37.8")
Resolution: 96x96 pixels
Material: Aluminum or Steel
Weight: <36Kg (79.2 Lbs) or 48Kg (105.6 Lbs)
Working Voltage AC220V±10%; AC110V±10%
Power Consumption Average 280W/m² / Max 960W/m²
Maximum Brightness >8,000 (max.10,000) cd/m²
Refresh Frequency >1920Hz/S
Change Frame Frequency 50Hz~60Hz
Drive Mode 1/4 Scanning
Total Colors 281 Trillion Colors
Grade Level RGB 65536 Grade
Best Viewing Distance 10m~>300m (30ft~>900ft)
Best Viewing Angle Horizontally 120° / Vertically 100°
Screen Lifetime >100,000 hours
Protection Level Front IP65 / Rear IP54
Ambient Temperature -40°C ~ 60°C (-30°F~150°F)
Relative Humidity 10%~90%
Control System* Simple LED Video Control System or Advanced LED Video Processor
Input Signal RF S-Video RGB RGBHV YUVYC etc.
Brightness Adjustment* 256 levels of each colour (RGB) can be adjusted manually and 8 levels of each colour can be adjusted automatically. Optional control system: 256 levels of each colour can be adjusted 100% automatically. (8bit / 16bit / 18bit / 24bit)
Package Method* Wooden Case / Flight Case
Warranty Date* 3 Years (5 Years for Cree and Nichia)
