P10mm 90° Flexible Led Screen Display Front Access Fixed Outdoor LED Screen Wall
P10mm 90° Flexible Led Screen Display Front Access Fixed Outdoor LED Screen Wall
P10mm 90° Flexible Led Screen Display Front Access Fixed Outdoor LED Screen Wall
P10mm 90° Flexible Led Screen Display Front Access Fixed Outdoor LED Screen Wall
P10mm 90° Flexible Led Screen Display Front Access Fixed Outdoor LED Screen Wall
P10mm 90° Flexible Led Screen Display Front Access Fixed Outdoor LED Screen Wall
P10mm 90° Flexible Led Screen Display Front Access Fixed Outdoor LED Screen Wall
P10mm 90° Flexible Led Screen Display Front Access Fixed Outdoor LED Screen Wall
P10mm 90° Flexible Led Screen Display Front Access Fixed Outdoor LED Screen Wall
P10mm 90° Flexible Led Screen Display Front Access Fixed Outdoor LED Screen Wall
Specifications
Brand Name :
SILU
Model Number :
P10mm
Certification :
3C,CE,RoHS
Place of Origin :
China
MOQ :
1 m²
Payment Terms :
T/T
Supply Ability :
1100 m² per Month
Delivery Time :
20 Days
Packaging Details :
Wooden Packages
Price :
USD1380.00-2560.00 per m²
Color :
Full Colors
Cabinet Material :
Aluminum/Iron
Leds :
SMD3535/DIP346
Brightness :
>6500 nits
Lifetime :
100000 Hours
Assemble :
Front and Back
Warranty :
3 Years
Description

P10mm 90° flexible Outdoor LED Display Front Access Fixed Outdoor LED Screen Wall

10.0mm pixel pitch, 6,500nits+ (max.8,500nits) brightness, IP65 rated outdoor fixed applications

  • Silu`s unique and private design
  • SMD3535 LED lamps
  • MBI5124 driving ICs
  • 2 Layers 1.6mm Thickness PCB
  • 320mmx320mm Size LED module
  • 960mmx960mm Size LED cabinet
  • IP65~IP67* rating waterproof and dustproof
  • Rugged and lightweight support easy and quick seamless assembling
  • 10m~500m better viewing distance (max. viewing according to the video wall size)
  • 160° Horizontal and 140° Vertical wide viewing angles
  • 1920~3840Hz high refresh rate guarantee that no scan line when taking photos and videos
  • High colour uniformity and fidelity offers vivid audio-visual enjoyment

Silu`s P10mm 90° flexible Outdoor LED Display Front Access Fixed Outdoor LED Screen Wall delivers high-resolution images and videos with unequalled brightness and contrast levels. It is available in various occasions and generates the perfect images and videos quality at all times, even in direct sunlight and rainy days.

Our P10mm 90° flexible Outdoor LED Display Front Access Fixed Outdoor LED Screen Wall is manufactured by using the best quality raw material and advanced production technology, it features supreme quality and offers the best outputs to ensure the image and video quality remains seamless. The P10mm 90° flexible Outdoor LED Display Front Access Fixed Outdoor LED Screen Wall is specifically designed for fixed installations in, performances, branding, DOOH (advertising) and retail applications.

For more details, pls. contact us at saga@atsilu.com or +86-1371700700.

P10mm 90° Flexible Led Screen Display Front Access Fixed Outdoor LED Screen Wall

P10mm 90° Flexible Led Screen Display Front Access Fixed Outdoor LED Screen Wall

Technical Specification

P10mm HD Outdoor LED Display
Pixel Pitch 10.0mm (0.3937")
LED Brand Nationstar & Customized*
Pixel Configuration 1R1G1B
Pixel Density 10,000 Pixels/m²
LED Module Size: 320mmx320mm (12.6"x12.6")
Resolution: 32*32 Pixels
LED Cabinet* Size: 960mmx960mm (37.8"x37.8")
Resolution: 96x96 pixels
Material: Aluminum or Steel
Weight: <36Kg (79.2 Lbs) or 45Kg (99 Lbs)
Working Voltage AC220V±10%; AC110V±10%
Power Consumption Average 360W/m² / Max 960W/m²
Maximum Brightness >6,500 (max.8,500) cd/m²
Refresh Frequency >1920Hz/S
Change Frame Frequency 50Hz~60Hz
Drive Mode 1/4 Scanning
Total Colors 281 Trillion Colors
Grade Level RGB 65536 Grade
Best Viewing Distance 10m~>300m (30ft~>900ft)
Best Viewing Angle Horizontally 160° / Vertically 140°
Screen Lifetime >100,000 hours
Protection Level Front IP65 / Rear IP54
Ambient Temperature -40°C ~ 60°C (-30°F~150°F)
Relative Humidity 10%~90%
Control System* Simple LED Video Control System or Advanced LED Video Processor
Input Signal RF S-Video RGB RGBHV YUVYC etc.
Brightness Adjustment* 256 levels of each colour (RGB) can be adjusted manually and 8 levels of each colour can be adjusted automatically. Optional control system: 256 levels of each colour can be adjusted 100% automatically. (8bit / 16bit / 18bit / 24bit)
Package Method* Wooden Case / Flight Case
Warranty Date* 3 Years (5 Years for Cree and Nichia)
