P16mm DIP346 Outdoor LED Display Waterproof High Brightness Large Digital Billboard
P16mm DIP346 Outdoor LED Display Waterproof High Brightness Large Digital Billboard
P16mm DIP346 Outdoor LED Display Waterproof High Brightness Large Digital Billboard
P16mm DIP346 Outdoor LED Display Waterproof High Brightness Large Digital Billboard
P16mm DIP346 Outdoor LED Display Waterproof High Brightness Large Digital Billboard
P16mm DIP346 Outdoor LED Display Waterproof High Brightness Large Digital Billboard
P16mm DIP346 Outdoor LED Display Waterproof High Brightness Large Digital Billboard
P16mm DIP346 Outdoor LED Display Waterproof High Brightness Large Digital Billboard
P16mm DIP346 Outdoor LED Display Waterproof High Brightness Large Digital Billboard
P16mm DIP346 Outdoor LED Display Waterproof High Brightness Large Digital Billboard
Specifications
Brand Name :
SILU
Model Number :
P16mm
Certification :
CE, CCC, RoHS, UL
Place of Origin :
China
MOQ :
1 m²
Payment Terms :
T/T
Supply Ability :
1300 m² per Month
Delivery Time :
25 Days
Packaging Details :
Wooden case
Price :
USD1080.00-2660.00 per m²
Leds :
DIP346
Led chip :
Epstar & Silan
Pixel :
1R1G1B
Colors :
Full Color
IC processing :
16 bit
Application :
Outdoor
Warranty :
3 Years
Lifetime :
10 Years
Description

P16mm DIP346 Outdoor LED Display Waterproof High Brightness Large Digital Billboard

16.0mm pixel pitch, 7,000nits+ brightness, IP65 rated outdoor fixed applications

  • Silu`s unique and private design
  • DIP346 LED lamps
  • MBI5124 driving ICs
  • 2 Layers 1.6mm Thickness PCB
  • 256mmx256mm Size LED module
  • 1024mmx1024mm Size LED cabinet
  • IP65~IP67* rating waterproof and dustproof
  • Rugged and lightweight support easy and quick seamless assembling
  • 16m~500m better viewing distance (max. viewing according to the video wall size)
  • 120° Horizontal and 110° Vertical wide viewing angles
  • 1920Hz high refresh rate guarantee that no scan line when taking photos and videos
  • High colour uniformity and fidelity offers vivid audio-visual enjoyment

Silu`s P16mm DIP346 Outdoor LED Display Waterproof High Brightness Large Digital Billboard comes at a competitive performance-effective design with super high brightness and longer lifetime for outdoor advertising billboard projects, it also can be installed in the hot and cold areas or countries, thanks to its great heat dissipating capability. IP65 protection led display can make sure it works normally in the rainy days, rugged Iron LED cabinet is anti-corrosion, waterproof and dustproof.

The P16mm DIP346 Outdoor LED Display Waterproof High Brightness Large Digital Billboard is a professional LED product for outdoor advertising applications, and also for the stadium, maybe it is a cost-effective solution.

For more details, pls. contact us at saga@atsilu.com or +86-1371700700.

P16mm DIP346 Outdoor LED Display Waterproof High Brightness Large Digital Billboard

P16mm DIP346 Outdoor LED Display Waterproof High Brightness Large Digital Billboard

Technical Specification

P16mm DIP Outdoor LED Display
Pixel Pitch 16.0mm (0.63")
LED Brand Epstar & Customized*
Pixel Configuration 1R1G1B
Pixel Density 3,906 Pixels/m²
LED Module Size: 256mmx256mm (10"x10")
Resolution: 16*16 Pixels
LED Cabinet* Size: 1024mmx1024mm (40.3"x40.3")
Resolution: 64x64 pixels
Material: Aluminum or Steel
Weight: <36Kg (79.2 Lbs) or 48Kg (105.6 Lbs)
Working Voltage AC220V±10%; AC110V±10%
Power Consumption Average 360W/m² / Max 960W/m²
Maximum Brightness >7,000 cd/m²
Refresh Frequency >1920Hz/S
Change Frame Frequency 50Hz~60Hz
Drive Mode Static Scanning
Total Colors 281 Trillion Colors
Grade Level RGB 65536 Grade
Best Viewing Distance 16m~>500m (48ft~>1500ft)
Best Viewing Angle Horizontally 120° / Vertically 110°
Screen Lifetime >100,000 hours
Protection Level Front IP65 / Rear IP54
Ambient Temperature -40°C ~ 60°C (-30°F~150°F)
Relative Humidity 10%~90%
Control System* Simple LED Video Control System or Advanced LED Video Processor
Input Signal RF S-Video RGB RGBHV YUVYC etc.
Brightness Adjustment* 256 levels of each colour (RGB) can be adjusted manually and 8 levels of each colour can be adjusted automatically. Optional control system: 256 levels of each colour can be adjusted 100% automatically. (8bit / 16bit / 18bit / 24bit)
Package Method* Wooden Case / Flight Case
Warranty Date* 3 Years (5 Years for Cree and Nichia)
