Specifications
Brand Name :
Longsun
Model Number :
AgCu Silver Alloy Wire
Certification :
ISO9001, SGS,ROHS
Place of Origin :
China
MOQ :
5kgs
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
300 Tons Per Year
Delivery Time :
3-10 Days
Packaging Details :
Carton / Or As Required.
Types :
Ag , FkAg, AgNi, AgCu, AgSnO2, AgSnO2In2O3, AgZnO2, AgCdO etc.
Usage :
Contactor, Relay, Starter, Voltage Controller, Automobile etc.
packing :
Inner Package: Vacuum, Outer Package: Carton
Production process: :
Melting method,internal oxidation,powder metallurgy
Supply type :
OEM,ODM
Properties :
Low resistance,good anti-Corrosion ability,long electric life
Description

1. Specification

A. Name: Silver Alloy Wire/Copper Contact Wire/Silver Coil for Electrical Contacts
B. Types: Ag , FkAg, AgNi, AgCu, AgSnO2, AgSnO2In2O3, AgZnO2, AgCdO etc.
C. Usage: Silver Alloy Wire can be used to manufacture Rivet Contacts and Contact Bridges by automatics welding Machine. They are widely applied in low voltage electrical appliances, such as Contactor, Relay, Starter, Voltage Controller, Automobile etc.

ISO9001 Silver Alloy Wire High Electrical Conductivity For Electrical Contacts
ISO9001 Silver Alloy Wire High Electrical Conductivity For Electrical Contacts

2. Characteristics

(A) Silver, Fine-grain Silver Series:

1) High electrical conductivity, thermal conductivity and chemical stability. 2) Easy to produce

and good tensile strength. 3) Low contact resistance and temperature in the installing test.

Using Production Process: melting method.

(2) Silver Nickel Alloy Series:

1) Good performance in arc erosion resistance and high resistance against welding.

2) Good conductivity and thermal conductivity.

Using Production Process: powder metallurgy method.

(3) Silver Oxidation Alloy Series:Including AgCdO, AgSnO2 and AgSnO2In2O3

(4) Silver Cadmium Oxide Series:

A) Good performance in arc erosion and welding resistance. B) Long electric life.

C) In some specific fields, so far, no other material can be replaced.

(5) The Silver Oxide Tin, Silver Oxide Tin Oxide Indium Series:

1) Environmental friendly contact materials without cadmium.

2) Arc Erosion and Welding Resistance.

3) Long electric life.

(6) Silver Copper Alloy Series:

1) Silver copper alloy have better performance in resistance against welding than silver.

2) Silver has a better performance in arc erosion resistance.

Production Process: Melting method

ISO9001 Silver Alloy Wire High Electrical Conductivity For Electrical Contacts
