Simo YB2 3551-2 185KW High Voltage Three Phase Asynchronous Motor 6kV 10kV
Simo YB2 3551-2 185KW High Voltage Three Phase Asynchronous Motor 6kV 10kV
Specifications
Brand Name :
Simo Motor
Model Number :
YB2 Series HV Explosion-proof Three Phase Asynchronous Motor
Certification :
3C, CE, GOST, CNAS, UL, QMS,EMS
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T
Delivery Time :
50-60 Working Days
Packaging Details :
Solid Wood Package
Type :
YB2 3551-2 HV Explosion-proof Three Phase Motor
Frame :
H355-H560
Voltage :
6kV, 10kV
No. of Poles :
2P, 4P, 6P, 8P, 10P
Mark of Explosion-proof :
Exd II B T4 Gb
Power :
185kW-1600kW
Frequency :
50Hz, Variable frequency speed control
Standard :
JB/T, HB
Cooling Type :
IC411, IC416
Mounting Type :
IM B3, IM B35, IM V15, etc
Description

YB2-3551-2-185-IP55-Class F-IM B3-Exd II BT4 Gb Explosion-proof Three Phase Asynchronous Motor

Motor Paramaters

Type: YB2-3551-2-185-IP55-Class F-IM B3-Exd II BT4 Gb Explosion-proof Three Phase Asynchronous Motor
Rated Power 185 Locked Current/Rated Current 7.0
Rated Current 23.0 Max. Torque/Rated Torque 2.0
Speed 2985 Rotational Inertia 3
Efficiency 92.2 Onload Rotational Inertia 12
Power Factor 0.84 Weight 2085
Locked Torque/Rated Torque 0.7

Technical Advantages

YB2-3551-2-185-IP55-Class F-IM B3-Exd II BT4 Gb Explosion-proof Three Phase Asynchronous Motor has characteristics of 185 kW of rated power, 23.0 A of rated current, 2985 r/min of speed and 92.2 % of efficiency, 0.84 Cosφ of power factor. Its max. torque/rated torque is 2.0, locked torque/ rated torque is 0.7, locked current/ rated current is 7.0, the rotational inertia is 3, onload rotational inertia is 12 and the weight is 2085 kg.

This series of motor has advantages, such as excellent flame-proof property, high reliability, compact structure, safe, environment protection, low vibration, low noise, easy to install and maintain. And it can replace YB560~710 series (IC511 tube cooling structure) high voltage flame-proof three phase asynchronous motor.

Product Features

This series of motor has advantages, such as excellent explosion-proof property, high reliability, compact structure, safe, environment protection, low vibration, low noise, easy to install and maintain.

Operation Conditions

Ambient temperature is -15℃~+40℃; Altitude ≤1KM; and monthly average air humidity ≤90% (If temperature is 25℃).

Wide Application

This series of motor can be widely applied to drive different kinds of general machines, such as compressor, water pump, crusher, windlass, centrifuge, cutting machine, conveyors and so on. YB2, YBX2 series high voltage explosion-proof three phase asynchronous motor can always provide excellent driving power and meet well the customer’s need no matter in indoor, outdoor, plateau, damp-heat type or other working conditions.

Profile Display

Simo YB2 3551-2 185KW High Voltage Three Phase Asynchronous Motor 6kV 10kV

Our Advantages

We are a developing and manufacturing enterprise specialized in large and medium, high and low voltage, AC and DC motors, synchronous motors, high efficiency motors and explosion-proof motors; a power system supplier intergrated motor design and manufacturing, mechanical processing, model manufacturing and automatic complete engineering. Our products mainly apply in electric power, coal, petroleum, mining exploring, metallurgy, railways, transportation, chemistry, agriculture, hydraulic power, navigation and high-tech areas, which is the motor supporting manufacturer specially designated by the Ministry of Railways.

Service Expanded

We proposed the service concept of "Customization" in accordance with the actual needs of customers in case of any special requirements. you can put forward special requirements and we will design an exclusive scheme as per your requirements. contact us of specific design and price.

Available Types of YB2

Type

Rated Power

kW

Rated Current

A

Speed

r/min

Efficiency

%

Power Factor

Cosφ

Locked Torque

Rated Torque

Locked

Current

Rated Current

Max. Torque

Rated Torque

Moment of Inertia

kg•m2

Load Moment of Inertia

kg•m2

Weight

Kg
Synchronous speed 3000 r/min
YB2-3551-2 185 23.0 2985 92.2 0.84 0.7 7.0 2.0 3 12 2085
YB2-3552-2 200 24.8 2985 92.4 0.84 0.7 7.0 2.0 3 13 2135
YB2-3553-2 220 27.2 2985 92.5 0.84 0.7 7.0 2.0 3 14 2180
YB2-3554-2 250 30.9 2985 92.6 0.84 0.7 7.0 2.0 4 16 2290
YB2-3555-2 280 33.7 2985 92.9 0.86 0.7 7.0 2.0 4 17 2320
YB2-4001-2 315 37.8 2985 93.2 0.86 0.7 7.0 2.0 5 19 3030
YB2-4002-2 355 42.5 2985 93.4 0.86 0.7 7.0 2.0 6 21 3125
YB2-4003-2 400 47.7 2985 93.9 0.86 0.7 7.0 2.0 6 23 3235
YB2-4004-2 450 53.5 2985 94.1 0.86 0.7 7.0 2.0 6 26 3250
YB2-4501-2 500 58.6 2985 94.4 0.87 0.7 7.0 2.0 8 28 3520
YB2-4502-2 560 65.5 2985 94.5 0.87 0.7 7.0 2.0 9 31 3590
YB2-4503-2 630 73.7 2985 94.6 0.87 0.7 7.0 2.0 10 34 3755
YB2-4504-2 710 82.9 2985 94.7 0.87 0.7 7.0 2.0 11 37 3830
YB2-5001-2 800 92.0 2985 95.1 0.88 0.7 7.0 2.0 15 41 5420
YB2-5002-2 900 103.4 2985 95.2 0.88 0.7 7.0 2.0 16 45 5565
YB2-5003-2 1000 114.7 2985 95.3 0.88 0.7 7.0 2.0 17 48 5725
YB2-5004-2 1120 128.4 2985 95.4 0.88 0.7 7.0 2.0 18 52 5895
YB2-5601-2 1250 141.4 2985 95.6 0.89 0.7 7.0 2.0 28 56 8100
YB2-5602-2 1400 158.2 2985 95.7 0.89 0.7 7.0 2.0 30 61 8180
YB2-5603-2 1600 180.6 2985 95.8 0.89 0.7 7.0 2.0 33 66 8250
Synchronous speed 1500 r/min
YB2-3551-4 185 22.9 1485 92.6 0.84 0.8 6.5 2.0 5 67 2420
YB2-3552-4 200 24.7 1485 92.9 0.84 0.8 6.5 2.0 5 72 2485
YB2-3553-4 220 27.1 1485 93.0 0.84 0.8 6.5 2.0 5 78 2545
YB2-3554-4 250 30.8 1485 93.1 0.84 0.8 6.5 2.0 6 87 2630
YB2-3555-4 280 34.4 1485 93.2 0.84 0.8 6.5 2.0 6 97 2685
YB2-4001-4 315 38.2 1485 93.4 0.85 0.8 6.5 2.0 9 108 3100
YB2-4002-4 355 42.9 1485 93.6 0.85 0.8 6.5 2.0 10 120 3195
YB2-4003-4 400 48.3 1485 93.7 0.85 0.8 6.5 2.0 11 133 3265
YB2-4004-4 450 54.2 1485 94.0 0.85 0.8 6.5 2.0 12 147 3350
YB2-4501-4 500 59.4 1485 94.2 0.86 0.8 6.5 2.0 15 161 3935
YB2-4502-4 560 66.4 1485 94.4 0.86 0.8 6.5 2.0 16 178 3980
YB2-4503-4 630 74.5 1485 94.6 0.86 0.8 6.5 2.0 18 197 4145
YB2-4504-4 710 83.8 1485 94.8 0.86 0.8 6.5 2.0 19 218 4310
YB2-5001-4 800 94.2 1485 95.0 0.86 0.8 6.5 2.0 36 241 5810
YB2-5002-4 900 105.9 1485 95.1 0.86 0.8 6.5 2.0 38 266 5980
YB2-5003-4 1000 117.5 1485 95.2 0.86 0.8 6.5 2.0 40 290 6125
YB2-5004-4 1120 131.5 1485 95.3 0.86 0.8 6.5 2.0 41 318 6220
YB2-5601-4 1250 144.8 1485 95.5 0.87 0.7 6.5 2.0 65 347 8280
YB2-5602-4 1400 162.1 1485 95.5 0.87 0.7 6.5 2.0 70 380 8580
YB2-5603-4 1600 185.1 1485 95.6 0.87 0.7 6.5 2.0 77 421 8920
Synchronous speed 1000 r/min
YB2-3553-6 160 20.9 988 92.2 0.80 0.8 6.0 2.0 7 157 2515
YB2-3554-6 185 24.1 988 92.4 0.80 0.8 6.0 2.0 8 180 2590
YB2-3555-6 200 26.0 988 92.6 0.80 0.8 6.0 2.0 9 193 2680
YB2-4001-6 220 27.8 988 92.8 0.82 0.8 6.0 2.0 13 210 3080
YB2-4002-6 250 31.5 988 93.0 0.82 0.8 6.0 2.0 14 236 3150
YB2-4003-6 280 35.3 988 93.2 0.82 0.8 6.0 2.0 15 262 3210
YB2-4004-6 315 39.5 988 93.5 0.82 0.8 6.0 2.0 16 291 3270
YB2-4501-6 355 43.9 988 93.7 0.83 0.8 6.0 2.0 29 325 3940
YB2-4502-6 400 49.5 988 93.7 0.83 0.8 6.0 2.0 31 361 4075
YB2-4503-6 450 55.5 988 94.0 0.83 0.8 6.0 2.0 33 401 4215
YB2-4504-6 500 61.5 988 94.3 0.83 0.8 6.0 2.0 36 441 4370
YB2-5001-6 560 68.7 988 94.5 0.83 0.8 6.0 2.0 47 487 5860
YB2-5002-6 630 77.2 988 94.6 0.83 0.8 6.0 2.0 50 540 6030
YB2-5003-6 710 86.9 988 94.7 0.83 0.8 6.0 2.0 54 600 6240
YB2-5004-6 800 97.7 988 94.9 0.83 0.8 6.0 2.0 59 666 6465
YB2-5601-6 900 108.4 988 95.1 0.84 0.7 6.0 2.0 100 737 8170
YB2-5602-6 1000 120.3 988 95.2 0.84 0.7 6.0 2.0 110 806 8460
YB2-5603-6 1120 134.6 988 95.3 0.84 0.7 6.0 2.0 115 888 8755
YB2-5604-6 1250 149.9 988 95.5 0.84 0.7 6.0 2.0 120 974 9060
Synchronous speed 750 r/min
YB2-4001-8 160 22.0 743 92.1 0.76 0.8 5.5 2.0 14 317 3130
YB2-4002-8 185 25.4 743 92.3 0.76 0.8 5.5 2.0 15 362 3200
YB2-4003-8 200 27.0 743 92.5 0.77 0.8 5.5 2.0 16 389 3260
YB2-4004-8 220 29.7 743 92.6 0.77 0.8 5.5 2.0 17 424 3320
YB2-4501-8 250 33.2 743 92.8 0.78 0.8 5.5 2.0 26 477 3745
YB2-4502-8 280 37.1 743 93.0 0.78 0.8 5.5 2.0 29 529 3905
YB2-4503-8 315 41.7 743 93.2 0.78 0.8 5.5 2.0 32 589 4060
YB2-4504-8 355 46.9 743 93.3 0.78 0.8 5.5 2.0 36 657 4270
YB2-5001-8 400 52.1 743 93.5 0.79 0.8 5.5 2.0 62 732 5685
YB2-5002-8 450 58.6 743 93.6 0.79 0.8 5.5 2.0 66 814 5815
YB2-5003-8 500 63.8 743 94.2 0.80 0.8 5.5 2.0 69 895 5990
YB2-5004-8 560 71.4 743 94.3 0.80 0.8 5.5 2.0 73 991 6130
YB2-5601-8 630 79.3 743 94.4 0.81 0.7 5.5 2.0 125 1100 7610
YB2-5602-8 710 89.3 743 94.4 0.81 0.7 5.5 2.0 131 1224 7915
YB2-5603-8 800 100.5 743 94.6 0.81 0.7 5.5 2.0 137 1360 8205
YB2-5604-8 900 112.9 743 94.7 0.81 0.7 5.5 2.0 145 1508 8495

Note: The motor efficiency is determined by the method of recommended value for stray loss. The mass of the motor is the theoretical value, which deviates from the actual value.
