Simo YBX4 132S1-2 4 Pole 6 Pole 3 Phase Motor 5.5KW Squirrel Cage Asynchronous Motor
Simo YBX4 132S1-2 4 Pole 6 Pole 3 Phase Motor 5.5KW Squirrel Cage Asynchronous Motor
Specifications
Brand Name :
Simo Motor
Model Number :
YBX4 Series Explosion-proof Super High Efficiency Three Phase Asynchronous Motor
Certification :
3C, CE, GOST, CNAS,UL,QMS,EMS
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T
Delivery Time :
50-60 Working Days
Packaging Details :
Solid Wood Package
Type :
YBX4 132S1-2 Explosion Proof Asynchronous Motor
Frame :
H80-H355
No. of Poles :
2P, 4P, 6P, 8P, 10P
Mark of Explosion-proof :
Exd II BT4 Gb
Mounting Type :
IM B3, IM B35, IM B5, IM V1
Power :
5.5KW
Frequency :
50 Hz
Cooling Type :
IC411
Efficiency Grade :
GB38613-2012 Grade 1 (IE4)
Description

YBX4-132S1-2-5.5-IP55-Class F-IM B3-Exd II BT4 Gb Explosion-proof Super High Efficiency Three Phase Asynchronous Motor

Motor Parameters

Type: YBX4-132S1-2-5.5-IP55-Class F-IM B3-Exd II BT4 Gb Explosion-proof Super High Efficiency Three Phase Asynchronous Motor
Rated Power 5.5 Locked Current/ Rated Current 9.5
Rated Current 10.4 Max. Torque/ Rated Torque 2.3
Speed 2945 Rated Torque 18
Efficiency 90.9 Rotational Inertia 0.02
Power Factor 0.88 No-load Noise 79
Locked Torque/Rated Torque 2.0 Weight 90

Technical Advantages

YBX4-132S1-2-5.5-IP55-Class F-IM B3-Exd II BT4 Gb Explosion-proof Super High Efficiency Three Phase Asynchronous Motor has characteristics of 5.5 kW of rated power, 10.4 A of rated current, 2945 r/min of speed, 90.9% of efficiency, 0.88 Cosφ of power factor. Its locked torque/ rated torque is 2.0 and locked current/rated current is 9.5 A, max. torque/rated torque is 2.3, rated torque is 18, rotational inertia is 0.02, no-load noise is 79 and weight is 90 kg.

The inner diameter of sealing rings for rubber-sheathed cables and armored rubber-sheathed cables have several concentric circles. The inner diameter of sealing ring can be selected according to the diameter of cables to ensure that there is no gap between sealing ring and cable and between sealing ring and terminal box seat after pressing the junction bucket.

Product Features

YBX4-series high efficiency explosion-proof three phase asynchronous motor has advantages such as excellent explosion-proof property, high efficiency, energy saving, large temperature rise margin, long operation life, good property, low vibration, advanced explosion-proof structure, good starting performance, good-looking appearance, high reliability and no sparking while operating.

Operation Conditions

Ambient temperature is -15℃~+40℃; Altitude ≤1KM; and monthly average air humidity ≤90% (If temperature is 25℃).

Wide Application

This series of motor is mainly applied in areas with mixed dangerous and explosive gases, such as underground coal mine (non- excavation working faces), petroleum, chemical engineering, mining industry, metallurgical industry, power and natural gas areas which contains gases like methane.

Profile Display

Simo YBX4 132S1-2 4 Pole 6 Pole 3 Phase Motor 5.5KW Squirrel Cage Asynchronous Motor

Our Advantages

We are a developing and manufacturing enterprise specialized in large and medium, high and low voltage, AC and DC motors, synchronous motors, high efficiency motors and explosion-proof motors; a power system supplier intergrated motor design and manufacturing, mechanical processing, model manufacturing and automatic complete engineering. Our products mainly apply in electric power, coal, petroleum, mining exploring, metallurgy, railways, transportation, chemistry, agriculture, hydraulic power, navigation and high-tech areas, which is the motor supporting manufacturer specially designated by the Ministry of Railways.

Service Expanded

We proposed the service concept of "Customization" in accordance with the actual needs of customers in case of any special requirements. you can put forward special requirements and we will design an exclusive scheme as per your requirements. contact us of specific design and price.

Available Types of YBX4

Type

Rated Power

kW

Rated Current

A

Speed

r/min

Efficiency

%

Power Factor

Cosφ

Locked Torque

Locked

Current

Max. Torque

Rated torque

N•m

Moment of Inertia

kg•m2

No-load Noise

dB(A)

Weight

Kg

Rated

Torque

Rated

Current

Rated Torque
Synchronous Speed 3000(r/min)
YBX4-132S1-2 5.5 10.4 2945 90.9 0.88 2.0 9.5 2.3 18 0.02 79 90
YBX4-132S2-2 7.5 14.0 2945 91.7 0.89 2.0 9.5 2.3 24 0.03 79 95
YBX4-160M1-2 11 20.3 2950 92.6 0.89 2.0 9.5 2.3 35 0.06 81 185
YBX4-160M2-2 15 27.4 2950 93.3 0.89 2.0 9.5 2.3 48 0.08 81 195
YBX4-160L-2 18.5 33.7 2950 93.7 0.89 2.0 9.5 2.3 59 0.09 81 210
YBX4-180M-2 22 40.0 2960 94.0 0.89 2.0 9.5 2.3 70 0.13 83 236
YBX4-200L1-2 30 54.2 2970 94.5 0.89 2.0 9.0 2.3 96 0.22 84 330
YBX4-200L2-2 37 66.6 2975 94.8 0.89 2.0 9.0 2.3 118 0.26 84 350
YBX4-225M-2 45 80.9 2980 95.0 0.89 2.0 9.0 2.3 143 0.34 86 425
YBX4-250M-2 55 98.5 2980 95.3 0.89 2.0 9.0 2.3 175 0.76 89 575
YBX4-280S-2 75 133.9 2980 95.6 0.89 1.8 8.5 2.3 239 0.92 91 660
YBX4-280M-2 90 160.4 2980 95.8 0.89 1.8 8.5 2.3 287 1.11 91 700
YBX4-315S-2 110 195.6 2980 96.0 0.89 1.8 8.5 2.3 350 1.58 92 1090
YBX4-315M-2 132 234.2 2980 96.2 0.89 1.8 8.5 2.3 420 1.78 92 1145
YBX4-315L1-2 160 283.6 2980 96.3 0.89 1.8 8.5 2.2 509 2.04 92 1230
YBX4-315L2-2 200 353.8 2980 96.5 0.89 1.8 8.5 2.2 637 2.33 92 1285
YBX4-355M1-2 220 389.2 2980 96.5 0.89 1.6 8.5 2.2 700 2.87 100 1824
YBX4-355M2-2 250 432.5 2980 96.5 0.91 1.6 8.5 2.2 796 3.27 100 1925
YBX4-355L1-2 280 484.4 2980 96.5 0.91 1.6 8.5 2.2 891 3.83 100 2068
YBX4-355L2-2 315 545.0 2980 96.5 0.91 1.6 8.5 2.2 1003 4.04 100 2088
Synchronous Speed 1500(r/min)
YBX4-132S-4 5.5 11.4 1470 91.9 0.80 2.0 9.5 2.3 35 0.06 71 105
YBX4-132M-4 7.5 15.2 1470 92.6 0.81 2.0 9.5 2.3 48 0.07 71 115
YBX4-160M-4 11 21.6 1475 93.3 0.83 2.0 9.5 2.3 70 0.13 73 185
YBX4-160L-4 15 28.9 1475 93.9 0.84 2.0 9.5 2.3 96 0.17 73 210
YBX4-180M-4 18.5 35.1 1480 94.2 0.85 2.0 9.5 2.3 118 0.23 76 242
YBX4-180L-4 22 41.6 1480 94.5 0.85 2.0 9.5 2.3 140 0.25 76 250
YBX4-200L-4 30 56.5 1485 94.9 0.85 2.0 9.0 2.3 191 0.45 76 325
YBX4-225S-4 37 69.5 1490 95.2 0.85 2.0 9.0 2.3 236 0.64 78 420
YBX4-225M-4 45 84.3 1490 95.4 0.85 2.0 9.0 2.3 287 0.74 78 450
YBX4-250M-4 55 101.5 1490 95.7 0.86 2.0 9.0 2.3 350 1.05 79 585
YBX4-280S-4 75 136.4 1490 96.0 0.87 2.0 8.5 2.3 478 1.75 80 510
YBX4-280M-4 90 161.7 1490 96.1 0.88 2.0 8.5 2.3 573 2.08 80 550
YBX4-315S-4 110 195.0 1490 96.3 0.89 1.8 8.5 2.2 700 3.33 88 1065
YBX4-315M-4 132 233.8 1490 96.4 0.89 1.8 8.5 2.2 840 3.71 88 1185
YBX4-315L1-4 160 279.6 1490 96.6 0.90 1.8 8.5 2.2 1019 4.31 88 1290
YBX4-315L2-4 200 349.2 1490 96.7 0.90 1.8 8.5 2.2 1273 5.12 88 1365
YBX4-355M1-4 220 384.1 1490 96.7 0.90 1.8 8.5 2.2 1410 9.28 95 1953
YBX4-355M2-4 250 436.4 1490 96.7 0.90 1.8 8.5 2.2 1592 10.02 95 2017
YBX4-355L1-4 280 488.8 1490 96.7 0.90 1.8 8.5 2.2 1783 10.67 95 2128
YBX4-355L2-4 315 549.9 1490 96.7 0.90 1.8 8.5 2.2 2006 10.95 95 2154
Synchronous Speed 1000(r/min)
YBX4-132S-6 3 7.2 970 88.6 0.71 2.0 7.5 2.1 29 0.04 69 85
YBX4-132M1-6 4 9.4 970 89.5 0.72 2.0 8.0 2.1 38 0.05 69 95
YBX4-132M2-6 5.5 12.8 970 90.5 0.72 2.0 8.0 2.1 53 0.07 69 105
YBX4-160M-6 7.5 16.4 980 91.3 0.76 2.0 8.0 2.1 72 0.14 73 175
YBX4-160L-6 11 23.5 980 92.3 0.77 2.0 8.5 2.1 105 0.19 73 205
YBX4-180L-6 15 30.7 980 92.9 0.80 2.0 8.5 2.1 143 0.31 73 225
YBX4-200L1-6 18.5 37.6 985 93.4 0.80 2.0 8.5 2.1 177 0.44 73 305
YBX4-200L2-6 22 44.0 985 93.7 0.81 2.0 8.5 2.1 210 0.55 73 325
YBX4-225M-6 30 59.0 990 94.2 0.82 2.0 8.3 2.1 287 0.82 74 390
YBX4-250M-6 37 71.7 990 94.5 0.83 2.0 8.3 2.1 353 1.43 76 525
YBX4-280S-6 45 86.9 990 94.8 0.83 2.0 8.5 2.0 430 2.22 78 715
YBX4-280M-6 55 104.6 990 95.1 0.84 2.0 8.5 2.0 525 2.68 78 820
YBX4-315S-6 75 142.2 990 95.4 0.84 1.6 8.0 2.0 716 3.91 83 1015
YBX4-315M-6 90 168.3 990 95.6 0.85 1.6 8.0 2.0 860 4.42 83 1115
YBX4-315L1-6 110 205.2 990 95.8 0.85 1.6 8.0 2.0 1051 5.50 83 1210
YBX4-315L2-6 132 242.9 990 96.0 0.86 1.6 8.0 2.0 1261 6.81 83 1325
YBX4-355M1-6 160 293.8 990 96.2 0.86 1.6 8.0 2.0 1528 10.63 85 1821
YBX4-355M2-6 200 366.9 990 96.3 0.86 1.6 8.0 2.0 1910 12.15 85 1950
YBX4-355L1-6 220 403.6 990 96.3 0.86 1.6 8.0 2.0 2101 14.25 85 2109
YBX4-355L2-6 250 457.7 990 96.5 0.86 1.6 8.0 2.0 2388 15.65 85 2182
Synchronous Speed 750(r/min)
YBX4-132S-8 2.2 5.7 710 84.5 0.70 1.8 7.5 2.0 28 0.04 64 76
YBX4-132M-8 3 7.6 710 85.9 0.70 1.8 7.8 2.0 38 0.05 64 89
YBX4-160M1-8 4 9.8 730 87.1 0.71 1.8 7.9 2.0 51 0.09 68 170
YBX4-160M2-8 5.5 13.1 730 88.3 0.72 1.8 8.1 2.0 70 0.12 68 185
YBX4-160L-8 7.5 17.2 730 89.3 0.74 1.8 7.8 2.0 96 0.17 68 200
YBX4-180L-8 11 25.0 730 90.4 0.74 1.8 7.9 2.0 140 0.26 70 232
YBX4-200L-8 15 33.3 730 91.2 0.75 1.8 8.0 2.0 191 0.36 70 350
YBX4-225S-8 18.5 40.9 730 91.7 0.75 1.8 8.1 2.0 236 0.54 73 360
YBX4-225M-8 22 47.8 730 92.1 0.76 1.8 8.3 2.0 280 0.64 73 620
YBX4-250M-8 30 63.9 740 92.7 0.77 1.8 7.9 2.0 382 0.97 75 745
YBX4-280S-8 37 77.4 740 93.1 0.78 1.8 7.9 2.0 471 1.61 76 651
YBX4-280M-8 45 93.8 740 93.4 0.78 1.8 7.9 2.0 573 1.85 76 729
YBX4-315S-8 55 111.5 740 93.7 0.80 1.6 8.2 2.0 700 3.93 82 940
YBX4-315M-8 75 151.2 740 94.2 0.80 1.6 7.6 2.0 955 5.38 82 1150
YBX4-315L1-8 90 178.8 740 94.4 0.81 1.6 7.7 2.0 1146 6.40 82 1225
YBX4-315L2-8 110 217.9 740 94.7 0.81 1.6 7.7 2.0 1401 7.51 82 1305
YBX4-355M1-8 132 260.9 740 94.9 0.81 1.6 7.7 2.0 1681 11.82 89 1742
YBX4-355M2-8 160 311.7 740 95.1 0.82 1.6 7.7 2.0 2037 14.42 89 1882
YBX4-355L1-8 185 360.4 740 95.1 0.82 1.6 7.7 2.0 2355 16.58 89 1985
YBX4-355L2-8 200 388.4 740 95.4 0.82 1.6 7.8 2.0 2547 18.74 89 2119
Synchronous Speed 600(r/min)
YBX4-315S-10 45 98.0 590 93.0 0.75 1.5 6.2 2.0 716 3.93 82 955
YBX4-315M-10 55 119.8 590 93.0 0.75 1.5 5.8 2.0 875 4.78 82 1090
YBX4-315L1-10 75 159.8 590 93.8 0.76 1.5 5.9 2.0 1194 6.40 82 1210
YBX4-315L2-10 90 189.3 590 93.8 0.77 1.5 6.0 2.0 1433 7.51 82 1285
YBX4-355M1-10 110 227.5 590 94.2 0.78 1.45 6.0 2.0 1751 11.84 90 1726
YBX4-355M2-10 132 272.1 590 94.5 0.78 1.45 6.0 2.0 2101 14.44 90 1871
YBX4-355L1-10 160 329.8 590 94.5 0.78 1.45 6.0 2.0 2547 17.91 90 2060

Note: The motor quality in the table is calculated theoretically and deviates from the actual value. It is for reference only. The actual weight of the motor is taken as the criterion.
