Micro scale VOC emission chamber for material VOC formaldehyde test
Micro scale VOC emission chamber for material VOC formaldehyde test
Micro scale VOC emission chamber for material VOC formaldehyde test
Micro scale VOC emission chamber for material VOC formaldehyde test
Specifications
Brand Name :
Simplewell
Model Number :
V-MV
Certification :
CE
Place of Origin :
China
MOQ :
1set
Price :
20000~50000
Supply Ability :
30 sets per month
Delivery Time :
30 working days
Packaging Details :
Micro chamber, small-scale VOC emissions chamberwill be packaged well by wooden box
Product Model :
V-MV
Cabin numbers :
4,6,8 small cabin
Humidity range :
5%R.H.(65℃)
Chamber Volume :
116ml/cabin
Weight :
150KG
Description

Micro-scale VOC emission chamber (4,6,8 cabins)

Micro scale VOC emission chamber for material VOC formaldehyde test

Micro scale VOC emission chamber for material VOC formaldehyde test

Application

Simplewell's micro-scall VOC emission chamber is especial for material and small worepiece test.

Chamber with 4, 6, 8 cabin, each cabin can regards as a independent chamber, can test several different samples in one time.

Technical parameters of Micro scale VOC emission Chamber

Product model MV-6, MV-4, MV-8
Environment temperature 5℃～35℃
Environment temperature ≤90%RH
Environmental cleansing requirements no pollution source surrounding TVOC≤500µg/m³
Climatic chamber volume Φ64x34mm＝116ml (single cabin size)
Cabin quantity 4 , 6 or 8 pieces , Bottom ring air supply, top exhaust and sampling
Temperature adjustable range 20-70℃,High temperature 260℃ above
Humidity adjustable range 5%R.H.(65℃)
Pressure 10±5pa
Temperature fluctuation ±0.3℃
Temperature deviation ±0.5℃
Humidity fluctuation ±2.5%R.H.
Humidity deviation ±3%
Air exchange rate 0.2-2times/h±5% Optional
Air flow range 1ml/min -- 2ml/min(range)
Power supply AC 220V/50Hz
Start power 10kw
Operation power 2.5Kw
Climatic chamber external dimensions W580xD890xH1050mm
Formaldehyde background concentration <15µg/m³, the lowest 6µg/m³
VOC background concentration Single VOC concentration < 2µg/m³, TVOC concentration < 20µg/m³
Recovery rate Formaldehyde, octanol, 4 phenyl cyclohexene, dodecane and tetradecane recovery > 80%
Air purifier system

Drying clean air (air, nitrogen, argon and other non-combustible, non-toxic and harmful gases)

Pressure> 1.0mpa
Cooling method Wind
Controller Color touch screen man-machine interface; Mitsubishi PLC controller

Standard

ISO 12219-3 Indoor air of road vehicles. Part 3:Screening method for the determination of the emissions of volatile organic compounds from vehicle interior parts and materials. Micro-chamber method

Laws and regulations

All work is in accordance with the laws and regulations of China and also can in accordance rules and regulations that specified by the buyer.
