Specifications
Brand Name :
SANTO
Model Number :
CD/MD/BCD/BMD/HC
Certification :
ISO, CE
Place of Origin :
CHINA
MOQ :
1set
Price :
699USD~5999USD
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
9999set/year
Delivery Time :
7-15 working days
Packaging Details :
Packed by high quality plywood crate
Name :
Electric Hoist
Main electrical parts :
Chint, or as requirments Siemens, Schneider
HS Code :
84251100
Application :
warehouse and so on,Factory
Sling type :
Wire Rope
Usage :
Construction Hoist,bridge crane
Lifting speed :
8m/min (as customised)
Power source :
3 phase 380V 50Hz or other standards
Warranty :
12 Months
Type :
Movable
Maximum lifting weight :
20t
Description

5 Ton CD Model Electric Wire Rope Hoist Provided Wire Rope Hoists Steel Cable Electric 35m Hight Construction Hoist

Description:

Model CD1, MD1 electric wire rope hoist is small-sized lifting equipment, which can be mounted on single beam, overhead, gantry and jib cranes, with slight modification. it can also be used as a winch. It is widely used in factories, warehoused, cargo store areas and shops. It is essential equipment in raising working efficiency and improving working conditions.

Model CD1 electric hoist has only normal speed, which can satisfy normal application. Model MD1 electric hoist provides two speed. At a low speed, it can do precise loading and unloading, mounding of sand box, maintenance of machine tools, etc

Standard Technical Specification of Wire Rope Electric Hoist:

SPECIFICATIONS FOR ELECTRIC WIRE ROPE HOIST
TYPE
0.25TON
0.5TON
1TON
2TON
3TON
5TON
10TON
Lifting capacity(T)
0.25
0.5
1
2
3
5
10
Lifting height(m)
3-9
6-12
6-30
6-30
6-30
6-30
6-30
Lifting Speed (m/min)
8(8/0.8)
8(8/0.8)
8(8/0.8)
8(8/0.8)
8(8/0.8)
8(8/0.8)
7(7/0.7)
Running Speed (m/min)
20(30)
Wire rope type
6×19-3.6
6×37-4.8-180
6×37-7.4-180
6×37-11-155
6×37-13-170
6×37-15-200
6×37-15-200
I-beam track model
16-22b
16-28b
16-28b
20a-32c
20a-32c
25a-63c
28a-63c
Voltage(V)
220-440
220-440
220-440
220-440
220-440
220-440
220-440
Frequency(Hz)
50/60
50/60
50/60
50/60
50/60
50/60
50/60
Phase
3
3
3
3
3
3
3

NOTE: According to your needs, we can also provide electric hoist to custom.
