Specifications
Brand Name :
SANTO
Model Number :
LD, LDE, LT, LDP, LX
Certification :
ISO, CE
Place of Origin :
CHINA
MOQ :
1set
Price :
USD2000-10000/set
Payment Terms :
L/C, T/T
Supply Ability :
5000set/year
Delivery Time :
15-30 working days
Packaging Details :
Electrical and other parts packed by high quality plywood crate, steel beams packed by plastic films or plastic woven cloth
Main electrical parts :
Chint, or as requirments Siemens, Schneider
Type :
Hoist Single Girder Bridge Crane,Single girder overhead crane,10 ton overhead crane
Max. lifting height :
6m~30m
Application :
workshop,Warehouse,plants,factory,warehouse and so on
Power supply :
220V~480V 50/60Hz
Crane feature :
Easy Operated Girder Bridge Crane,Single Girder Overhead Crane,EOT crane,7.5tons overhead crane
Lifting mechanism :
Electric Hoist
Lifting speed :
0~8m/min
Description

Top Running Lifting Machine Single Girder Overhead Crane 10 Ton

Description:

The LD type single girder overhead crane is the most popular crane for all type of workshops. It can be characterized by advanced metal structure and higher steel strength, used together with CD1 or MD1 electric hoist as a complete set.

These cranes are more efficient and require less maintenance.working class A3-A5, working temperature is between -25C to 40C.

This crane model recommended by the WTO and match China standard JB/T1306-94.

LD crane has two operational methods- pendant or cabin (open or closed type).

Application:

Electric Hoist Single Girder Beam Overhead Crane is widely used in plants, warehouses, material stocks to lift goods. It is prohibited to use the equipment in the combustible, explosive or corrosives environment.This product has two operational methods, ground or operational room which is open or closed model and can be installed on left or right side according to the practical situation. And the direction of entering the gate has two forms, sideway and ends in order to satisfy the users' choice under different conditions.

Specification:

Lifting capacity t 1, 2, 3, 5, 10 16, 20
Span m 7.5-31.5
Lifting height m 6, 9, 12, 18, 24, 30 9, 12, 18, 24, 30
Traveling mechanism Traveling speed m/min 20 30 45 60 75 20 30 45 60 75
Reducer ratio 58.78 39.38 26.36 19.37 15.88 58.78 39.38 26.36 19.37 15.88
Motor model ZDY21-4 ZDY122-4 ZDY131S-4
Motor power kw 0.8*2 1.5*2 1.5*2 2.2*2
Motor rotation m/min 1380 1380
Lifting mechanism Electric hoist model CD1/MD1 CD1/MD1/HC
Lifting speed m/min 8, 8/0.8, 7, 7/0.7 3.5, 3.5/0.35
Traveling speed m/min 20(30) 20(30)
Motor Taper Squirrel-cage type Taper Squirrel-cage type
Working duty A3-A5
Power supply 380V-50HZ, 3Phase or as your demand

Advantage:

1). Compact design, optimal use of the work areas
2). Heavier loads, wider spans and higher working frequency
3). Control the load easily, position the load exactly
4). Superior safety and reliability
5). “One-Stop Shop” for your crane and hoist needs

Company Information:


Santo crane mainly dealing in researching, developing and producing the lifting machinery, port machinery, construction-use tower crane, reducer, etc.
The leading products of Santo widely used in Machinery, Metallurgy, Electric Power, Railway, Aerospace , Port, Petroleum, Petrochemical, etc, our products are serving the national key projects such as: the South-to-North Water Transfer Project, the West-East National Gas Transmission, the Three Gorges Hydropower Station, Jiuquan Satellite Lunching Center, Qinshan Nuclear Power Station, Hangzhou Bay Bridge, Beijing Olympic Games and so on, accelerate successfully the launch of Spacecraft Shenzhou-10 and Chang’e-3,our products have been exported to more than 69 countries like America, Japan, Russia, Korea, etc. In 2013 the annual sales revenue reached 6.669 billion, and the Overhead Traveling Crane and the Gantry Crane continue to hold the first position around the whole country

Crane Photos:
