CATV FTTH Fiber Optic Pigtail Cables SC/APC For Measurement Sensors
CATV FTTH Fiber Optic Pigtail Cables SC/APC For Measurement Sensors
Specifications
Brand Name :
Geehe or OEM
Model Number :
Fiber Optical Pigtail MPO
Certification :
ROHS, REACH, UL, ISO
Place of Origin :
Wuhan, China
MOQ :
100 PCS
Price :
Price Negotiable
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
10,000 pcs per month
Delivery Time :
3-5 days
Packaging Details :
plastic zip bag and carton
Material :
Single Mode
Diameter :
0.9/2.0/3.0mm
Connector :
SC
Interface Polish :
APC
Core :
Simplex
Length :
Customized
Description

CATV FTTH Fiber Optic Pigtail Cables SC/APC For Measurement Sensors

Features:

RoHS, Telcordia GR-326-4 core compliant

Ultra low insertion loss and back reflection

UL94 V-0 rated plastic housing or metal housings available

Standard and telcordia style high spec boots in various colors

Application:

Fiber optic gyroscope

Laser doppler velocimeter

Measurement sensors

Testing and instrument systems

FTTH, CATV, telecommunication network etc.

Specifications:

Parameter Unit Index
End-face type PC UPC APC
IL dB SM: ≤0.3; MM≤0.1
Repeatability dB ≤0.1
Interchangeability dB ≤0.2
RL SM dB ≥50 ≥50 ≥50
MM dB ≥36 (without APC connector)
Mating times ＞1000
Operating temperature ℃ -40~ +80

Ordering Information:

OFC -X -XX -XX -XX -XX -XX

S: simplex

D:duplex

FA:FC/APC

FC:FC/UPC

FP:FC/PC

FA:FC/APC

FC:FC/UPC

FP:FC/PC

09:0.9mm

20:2.0mm

30:3.0mm

0:G652D

1:G657A

2:50/125

3:62.5/125

4:others

0.5:0.5m

1.0:1.5m

10:10.0m
Fiber mode Connector Type Connector Type Cable Diameter Fiber Type Fiber Length

EX: OFC-S-FA-FC-09-1-0.5

​

CATV FTTH Fiber Optic Pigtail Cables SC/APC For Measurement Sensors

Description:

Fiber Optic Pigtail have only one connector, the other end is a piece of broken ends of optical fiber core, which through welding linked other optical fiber core. Often appeared in optical fiber terminal box, used to connect optical cable and optical fiber transciever(also used in coupler, jump line, etc.) between.

The other end of Fiber Optical Pigtail can be made into other connectors, such as MPO Male, MPO Female, SC/UPC, SC/APC, LC/UPC, LC/APC, FC/UPC, FC/APC, MU.
