SM SC/APC Variable Optical Attenuator , Fiber Optic Splicing APC Polish
SM SC/APC Variable Optical Attenuator , Fiber Optic Splicing APC Polish
Specifications
Brand Name :
Geehe or OEM
Model Number :
Optical Pad Attenuator, Bulkhead Attenuator
Certification :
ROHS, REACH, UL, ISO
Place of Origin :
Wuhan, China
MOQ :
50 PCS
Price :
Price Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
1,000pcs per day
Delivery Time :
5-7 working day
Packaging Details :
plastic zip bag and carton
Type :
Male to Female
Connector Type :
SC
Interface Polish :
APC
Attenuation Value :
01dB
Features :
High return loss
Description

Optical Pad Attenuator SM SC/APC 01dB Male-Female High return loss type

Warranty:

Responsible for after-sales service 12 monthes


Key Features

Low back refection, insertion loss

Available attenuation from 1dB to 30 dB

Low PDL

100% tested in factory

Environmentally stable

Manufactured with metal-ion doped

Contaminant and scratch free ferrule upon request

Multimode attenuators available

Product Description

Optical pad attenuators are built with metal-ion doped optical fiber and are designed to provide consistent attenuation levels as well as maintaining polarization characteristics. Typical application for an optical pad attenuator is to reduce the amount of optical power by a specific amount as to not saturate a receiver which can limit a system's performance. They also can be used to test the linearity and dynamic range of photo sensors and photo detectors in test and measurement applications.

SM SC/APC Variable Optical Attenuator , Fiber Optic Splicing APC Polish

Applications

Receiver padding

CATV, LAN, telecommunications

WDM and DWDM systems channel balancing

Optical power equalization

Test and instrument

Optical transmission systems

1-30dB Fixed SC/ST/FC/LC/MU Optical Pad Attenuator

SM SC/APC Variable Optical Attenuator , Fiber Optic Splicing APC Polish

Package & Specifications

Packaging

Description

Clear Ziploc bag, 1 unit per bag

Physical Characteristics

Parameter

Value

Plastic material

UL 94V-0 ABS high-impact thermoplastic

Fiber material

Metal-ion doped optical fiber

Mechanical Characteristics

Parameter

Value

Operating temperature (℃)

-40 ~ +85

Storage temperature (℃)

-40 ~ +85

Optical Performance

Parameter

Value

Operating bandwidth

1250nm~1625nm

Center wavelength

1310nm and 1550nm

Attenuation tolerance

1 to 10 dB:±0.5dB 11 to 30 dB:±0.5%dB

Return loss UPC(dB)

≥45

Return loss APC(dB)

≥55

PDL

≤0.1

Ordering information

OAT- HF- XX- X A- XX-
HF: High return loss type LC: LC 1: APC 01: 01DB
SC: SC 2:UPC 02: 02DB
FC: FC 03: 03DB
04: 04DB
Attenuator Type Connector Type Interface polish Attenuation Value

EX: OAT-HF-LC-2A-02
