Optical WDM Filter 1310/1490/1550NM Plc Fiber Splitter For FTTH Network
Optical WDM Filter 1310/1490/1550NM Plc Fiber Splitter For FTTH Network
Optical WDM Filter 1310/1490/1550NM Plc Fiber Splitter For FTTH Network
Optical WDM Filter 1310/1490/1550NM Plc Fiber Splitter For FTTH Network
Specifications
Brand Name :
Geehe ,Optocrest, OEM
Model Number :
PLC - 1✖2,1✖4,1×8，1✖16,1✖32
Certification :
ISO9001:2015, ISO1401
Place of Origin :
Wuhan,China
MOQ :
30 pcs
Price :
Negotiated
Payment Terms :
T/T, L/C, D/A, D/P, Cash
Supply Ability :
5,000 pcs per day
Delivery Time :
With 5-7 working days,Negotiated
Packaging Details :
PE bags with thick outer cartons,follow customer's requirements,OEN service
Model Name :
Fiber Optic Coupler Splitter
Fiber Type :
G652D/G657/G657A1
Mode :
Singlemode/multimode
Fiber Length :
1Meter, 1.5Meter as requested
Wavelength :
1260-1650nm
Grinding Method :
PC.UPC.APC
Connector Type: :
SC , FC, LC, ST
Ratio: :
10:90 20:80 30:70 40:60 50:50
Application :
Telcomumication
Cable Diameter :
0.9/2.0/3.0mm
MOQ :
20 PCS
Warranty :
12 Months
Description

Optical WDM Filter 1310/1490/1550NM PLC Fiber Optic Splitter For FTTH Network

Product description:

Geehe PLC Gold series 1x2N splitters are available with split ratios from 1x2 up to 1x64. Fibrain FPLC splitters ensure very high stability of operation within the whole 1260-1650 nm band.

The splitters have perfect thermal stability, guaranteeing operation in -40/+85 °C thermal range. An important advantage from the point of view of link design and maintenance is the uniformity of attenuation. Geehe PLC G0 splitters are available both without connector terminations (prepared for splicing) and with any kind of connectors.

Features:

  • Low insertion loss
  • Low channel uniformity
  • Wide operating range
  • Low PDL
  • Compact housings
  • Delivered with test reports
  • Wide range of available connectors

Application:


Telecommunication networks

CATV networks

FTTH networks

Specification:

FIber Optical PLC Splitter
Parameter 1x4 1x8 1x16 1x32 1x64 2x4 2x8 2x16 2x32
Operating Wavelength(nm) 1260~1650
Port Wavelength Range (nm) 1310 ±20,1490 ±10 and 1550 ±20
Insertion Loss @1310nm/1550nm 7.1 10.5 13.6 16.8 20.5 7.4 10.8 14.5 17.5
Uniformity (dB) 0.5 0.8 1 1.2 1.8 1.2 1.5 1.8 2
PDL @ 1310/1550 nm (dB) ≤0.3
Return Loss@ 1310/1551 nm (dB) ≤-55
Input Power (mW) 250max
Operating Temperature (℃) -40~+85℃
Storage Temperature (℃) -40~+85℃
Fiber Type Corning G657A1

Package Dimensions

WxHxL(mm) PORT
60x7x4 1x4 1x8 2x4 2x8
60x12x4 1x16 2x16
80x12x6 1x32 2x32
100x40x6 1x64

Product Pictures

Optical WDM Filter 1310/1490/1550NM Plc Fiber Splitter For FTTH Network

Product tags

fiber optic 1x32 plc splitter

,

plc fiber optic splitter

,

fiber optic plc splitter
