Specifications
Brand Name :
SINOTRUK HOWO
Model Number :
ZZ3317N4267
Certification :
ISO/3C/BV/IFA/SGS
Place of Origin :
China
MOQ :
1unit
Price :
US$38000-USD48000/unit
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
2000 units per month
Delivery Time :
20-30 working days after deposit or LC
Packaging Details :
Nude, Waxing in RORO or bulk ship
Manufacturer :
SINOTRUK (CNHTC)
Series: :
HOWO
Product Name: :
Dump Truck (Tipper)
Model: :
ZZ3317N4267
Drive Type: :
8X4, LHD
Engine: :
WD615.47, 371HP, Euro II
Cargo Body: :
7800×2300×1500mm
Loading Capacity: :
40-60tons
Cabin: :
HW76,1 Beth
Transmission: :
HW19710
Description

SINO TRUCK 12 Wheeler 30 Cubic Meters HOWO 40tons 8x4 Dump Tipper Truck With HYVA

SINOTRUK HOWO Tipper Truck, the best choice for you!

HYVA 8x4 12 Wheeler 30 Cubic Meters 40 Tons SINOTRUK Tipper Truck

SINOTRUK (CNHTC) HOWO heavy duty trucks--the most advanced and most superior new generation of heavy duty trucks in China, with proprietary brand and intellectual property right, was developed by SINOTRUK (CNHTC) by applying the world advanced heavy duty truck key technology aiming at the market of the world.

HOWO heavy duty truck adopts the advanced key assemblies which are reasonably connected by advanced technology. The arrangement of the complete vehicle is perfect; the main assemblies are harmonious, unified and reliable, which makes the complete vehicle have better performance on power, economical efficiency, reliability and environmental protection.

HOWO heavy duty truck is with luxury and great appearance; it is a combination of fortitude and streamline, sturdiness and elegance. It aims at world heavy duty truck level on the ergonomic design like comfortability, safety and accessibility.

HYVA 8x4 12 Wheeler 30 Cubic Meters 40 Tons SINOTRUK Tipper Truck

Specifications
Model
ZZ3317N4267
Brand
SINOTRUK HOWO
Drive
8x4
Wheel Base
1800+4200+1400mm
Overall Dimensions
10065*2496*3450mm
Tread(front/rear)
2041+1830/1830mm
Approaching Angle
19°
Departure Angle
22°
Curb Weight
15,100.00kg
Loading Capacity
50tons
Max Speed
75km/h
Overhang(front/rea)
1500/1870mm
Engine
Model
WD615.476 cylinders in line, water cooling, 4 strokes, Common Rail System
DIsplacement
9.726L
Feul Consumption
41.7L/100km
Emission Standard
EURO2
Horse Power
371hp
Rear Axle Ratio
5.45
Rated Speed
2200rpm
Torque
1500N.m/1100-1600rpm
Gearbox
Model
HW19710
Transmission Type
Manual
Forward
10 speed
Reverse
2 speed
Chassis and Tyre
Front Axle Loading
9000kgs
Rear Axle Loading
HC16 16000kgs
Tyre
12.00R20 16PR
Tyre No.
12pcs
Dump Box
Box Dimension
7600*2300*1100mm
Hydraulic System
front/middle lift
Bottom Thickness
8mm
Side Thickness
6mm

HYVA 8x4 12 Wheeler 30 Cubic Meters 40 Tons SINOTRUK Tipper Truck

1, mining industry, like copper mine, iron mine, nickel mine, coal mine, etc.

2, construction sites, transport the sand, small stone, etc.

3, farm, to transport cereals

4, others

HYVA 8x4 12 Wheeler 30 Cubic Meters 40 Tons SINOTRUK Tipper Truck

HYVA 8x4 12 Wheeler 30 Cubic Meters 40 Tons SINOTRUK Tipper Truck

SINOTRUK (CNHTC) HOWO series 6x4 dump trucks (tipper trucks) are designed by SINOTRUK comprehensive with the world’s most advanced automotive technology and mature, reliable assembly parts.

Chassis:

1, Engine: HOWO series dump truck equipped with the SINOTRUK mature WD615 Euro II turbocharged water-cooled diesel engine, horse power covering 266-420Ps, fuel consumption lower.

2, Cab: Cab passive-safety performance reaches the world advanced level, the cab installation uses a four-point suspension to make the drivers more high driving comfort;

3, Clutch: Diaphragm spring clutch, diameter 430mm;

4, Brake: WABCO brake system and VOSS connectors, more safe and reliable;

5, Steering: ZF steering system, hydraulic power assistance;

6, VDO electrical instrumentation to improve the reliability of the electrical system

7, Maximum loading capacity can be 40-50tons.

HYVA 8x4 12 Wheeler 30 Cubic Meters 40 Tons SINOTRUK Tipper Truck

Cargo Box:

HYVA 8x4 12 Wheeler 30 Cubic Meters 40 Tons SINOTRUK Tipper Truck

HYVA 8x4 12 Wheeler 30 Cubic Meters 40 Tons SINOTRUK Tipper Truck

HYVA 8x4 12 Wheeler 30 Cubic Meters 40 Tons SINOTRUK Tipper Truck

HYVA 8x4 12 Wheeler 30 Cubic Meters 40 Tons SINOTRUK Tipper Truck

HYVA 8x4 12 Wheeler 30 Cubic Meters 40 Tons SINOTRUK Tipper Truck

By Roro or Bulk or Flat Rack Container according to your specific requests.

HYVA 8x4 12 Wheeler 30 Cubic Meters 40 Tons SINOTRUK Tipper Truck

HYVA 8x4 12 Wheeler 30 Cubic Meters 40 Tons SINOTRUK Tipper Truck

1, the whole truck warrenty is 1 year or 50000km, base on whichever comes first.

2, professional sevice team, enough spare parts to make you away from future worries.

3, professional trainning teachers for your drivers or engineers on repair and maintenance

HYVA 8x4 12 Wheeler 30 Cubic Meters 40 Tons SINOTRUK Tipper Truck

Q1: Qualification
We are authorized sales agent of Sinotruk Howo in China.

Q2: Whats the warranty?
2 years after delivery.

Q3: What's your MOQ?
A3: One unit vehicle.

Q4:About logistics.
A4: Roro, Framework, or Bulk Cargo Vessel. We possess long -term cooperation with ship agency which charge lowest shipping fee.

HYVA 8x4 12 Wheeler 30 Cubic Meters 40 Tons SINOTRUK Tipper Truck
