371hp 6x4 HW76 Cab 20 30 Tons 3.8m SINOTRUK Tipper Truck
371hp 6x4 HW76 Cab 20 30 Tons 3.8m SINOTRUK Tipper Truck
371hp 6x4 HW76 Cab 20 30 Tons 3.8m SINOTRUK Tipper Truck
371hp 6x4 HW76 Cab 20 30 Tons 3.8m SINOTRUK Tipper Truck
371hp 6x4 HW76 Cab 20 30 Tons 3.8m SINOTRUK Tipper Truck
371hp 6x4 HW76 Cab 20 30 Tons 3.8m SINOTRUK Tipper Truck
371hp 6x4 HW76 Cab 20 30 Tons 3.8m SINOTRUK Tipper Truck
371hp 6x4 HW76 Cab 20 30 Tons 3.8m SINOTRUK Tipper Truck
371hp 6x4 HW76 Cab 20 30 Tons 3.8m SINOTRUK Tipper Truck
371hp 6x4 HW76 Cab 20 30 Tons 3.8m SINOTRUK Tipper Truck
371hp 6x4 HW76 Cab 20 30 Tons 3.8m SINOTRUK Tipper Truck
371hp 6x4 HW76 Cab 20 30 Tons 3.8m SINOTRUK Tipper Truck
Specifications
Brand Name :
SINOTRUK HOWO
Model Number :
ZZ3257N3647
Certification :
ISO/3C/BV/IFA/SGS
Place of Origin :
China
MOQ :
1unit
Price :
US$30000-USD40000/unit
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
2000 units per month
Delivery Time :
20-30 working days after deposit or LC
Packaging Details :
Nude, Waxing in RORO or bulk ship
Manufacturer :
SINOTRUK (CNHTC)
Series: :
HOWO
Product Name: :
Tipper
Drive Type: :
6X4, LHD or RHD
Loading Capacity: :
25-40tons
Engine :
371hp
GearBox :
HW19710 HW19712
Front Axle :
HF9
Rear axle :
HC16
Color :
According customer request
Description

SINOTRUK Tipper Truck 371hp 3.8m Wheelbase 6x4 HW76 Cab 20-30tons Sinotruk HOWO Dump Truck

371hp 6x4 HW76 Cab 20 30 Tons 3.8m SINOTRUK Tipper Truck

Sinotruk Howo
Chassis Model		 ZZ3257N3647
Sinotruk Howo
Driving Type		 6X4
Sinotruk Howo
Cabin		 HW76—HOWO Extended cabin. Basic configuration is with single sleeper; new type seat; adjustable steering wheel from up and down, front and rear ; new type integral warm air heater with European style; the German VDO instrument which synchronized with the world high level heavy duty truck; road vehicles is with four point floating suspension (front spiral spring, rear air spring) with shock absorbers, off road vehicles is with four point floating spring suspension + shock absorbers, each type of cabin is with transverse stabilizing device, double lock safety belt; external sunshade; fourth generation air conditioning, air conditioning control board is liquid crystal display with LED lighting; with cruise; with sound warning system for abnormal generator voltage (to prevent damage of electronic devices); electric windows.
Sinotruk Howo
Engine		 Make: SINOTRUK
Diesel 4-stroke direct injection diesel engine
Engine model: WD615.47, 371HP ;
Emission :Euro 2
6-cylinder in-line with water cooling, turbo-charging and intercooling
Displacement: 9.726 L
Transmission HW19710, 10F & 2R,HW50
Steering ZF power steering, modol ZF8118, hydraulic steering with power assitance
Front Axle

HF9,1x9000 KGS

Steering with doubleT-cross section beam
Rear Axle HC16, 2x16000 KGS
Pressed axle housing, central single reduction with hub reduction,with differential locks between wheels and axles.
Ratio:5.73
Propeller Shaft Double universal joint propeller shaft with gear-shaped coupling flange
Chassis Frame: Uprofile parallel ladder frame with section of 300x80x8mm,reinforced subframe all cold riveted cross members
Front suspension:10 semi elliptic leaf spring, hydraulic telescopic double-action shock absorbers and stabilizer
Rear suspension:12 leaf semi elliptic springs, bogie spring and stabilizer
Brake Service brake: dual circuit compressed air brake
Parking brake (emergency brake): spring energy, compressed air operating on front shaft and rear wheels
Auxiliary brake: engine exhaust brake
Electrics Operating voltage: 24 V, negative grounded
Starter: 24 V, 5.4 Kw
Alternator: 3-phase, 28 V, 1500 W
Batteries: 2 x 12 V, 135 Ah
Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light
Tyres 12.00R20, radial tyres with one spare tyre
Fuel Tank 300L
Cargo Body Length:5.6-5.8M;Width:2.3M;Height:1.2-2M
Vehicle Size 8545x2496*3170mm

371hp 6x4 HW76 Cab 20 30 Tons 3.8m SINOTRUK Tipper Truck

371hp 6x4 HW76 Cab 20 30 Tons 3.8m SINOTRUK Tipper Truck

371hp 6x4 HW76 Cab 20 30 Tons 3.8m SINOTRUK Tipper Truck

371hp 6x4 HW76 Cab 20 30 Tons 3.8m SINOTRUK Tipper Truck371hp 6x4 HW76 Cab 20 30 Tons 3.8m SINOTRUK Tipper Truck

371hp 6x4 HW76 Cab 20 30 Tons 3.8m SINOTRUK Tipper Truck


371hp 6x4 HW76 Cab 20 30 Tons 3.8m SINOTRUK Tipper Truck

371hp 6x4 HW76 Cab 20 30 Tons 3.8m SINOTRUK Tipper Truck

Cargo Box:

371hp 6x4 HW76 Cab 20 30 Tons 3.8m SINOTRUK Tipper Truck

371hp 6x4 HW76 Cab 20 30 Tons 3.8m SINOTRUK Tipper Truck

371hp 6x4 HW76 Cab 20 30 Tons 3.8m SINOTRUK Tipper Truck

371hp 6x4 HW76 Cab 20 30 Tons 3.8m SINOTRUK Tipper Truck

371hp 6x4 HW76 Cab 20 30 Tons 3.8m SINOTRUK Tipper Truck

371hp 6x4 HW76 Cab 20 30 Tons 3.8m SINOTRUK Tipper Truck

Sinotruk Howo Products Advantages:

1. Rich Experience in sale of the Sinotruk’s heavy equipment & truck.

2. Expert in kinds of sinotruk heavy trucks and spare parts.

3. Personalized customization to meet your working requirements.

4. High quality of Original parts & OEM services.

5. Engineers and experts on call for pre/after sale support.

6. One-stop service with sinotruk heavy trucks, parts as well as stand-by advice & support.

371hp 6x4 HW76 Cab 20 30 Tons 3.8m SINOTRUK Tipper Truck

371hp 6x4 HW76 Cab 20 30 Tons 3.8m SINOTRUK Tipper Truck

371hp 6x4 HW76 Cab 20 30 Tons 3.8m SINOTRUK Tipper Truck
