40 Tons 336hp 371hp 6x4 SINOTRUK 10 Wheeler Dump Tipper Truck
40 Tons 336hp 371hp 6x4 SINOTRUK 10 Wheeler Dump Tipper Truck
40 Tons 336hp 371hp 6x4 SINOTRUK 10 Wheeler Dump Tipper Truck
40 Tons 336hp 371hp 6x4 SINOTRUK 10 Wheeler Dump Tipper Truck
40 Tons 336hp 371hp 6x4 SINOTRUK 10 Wheeler Dump Tipper Truck
40 Tons 336hp 371hp 6x4 SINOTRUK 10 Wheeler Dump Tipper Truck
40 Tons 336hp 371hp 6x4 SINOTRUK 10 Wheeler Dump Tipper Truck
40 Tons 336hp 371hp 6x4 SINOTRUK 10 Wheeler Dump Tipper Truck
40 Tons 336hp 371hp 6x4 SINOTRUK 10 Wheeler Dump Tipper Truck
40 Tons 336hp 371hp 6x4 SINOTRUK 10 Wheeler Dump Tipper Truck
40 Tons 336hp 371hp 6x4 SINOTRUK 10 Wheeler Dump Tipper Truck
40 Tons 336hp 371hp 6x4 SINOTRUK 10 Wheeler Dump Tipper Truck
Specifications
Brand Name :
SINOTRUK HOWO
Model Number :
ZZ3257N3647
Certification :
ISO/3C/BV/IFA/SGS
Place of Origin :
China
MOQ :
1unit
Price :
US$30000-USD40000/unit
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
2000 units per month
Delivery Time :
20-30 working days after deposit or LC
Packaging Details :
Nude, Waxing in RORO or bulk ship
Manufacturer :
SINOTRUK (CNHTC)
Series: :
HOWO
Product Name: :
Tipper
Drive Type: :
6X4, LHD or RHD
Loading Capacity: :
25-40tons
Engine :
371hp
GearBox :
HW19710 HW19712
Front Axle :
HF9
Rear axle :
HC16
Color :
According customer request
Description

SINOTRUK Tipper Truck Sinotruk HOWO 6x4 336hp 371hp 40tons Dumper Tipping 10 Wheeler Dump Tipper Truck

40 Tons 336hp 371hp 6x4 SINOTRUK 10 Wheeler Dump Tipper Truck

Chassis parameters
Chassis model ZZ3257N3647 Chassis brand SINOTRUK
Overall dimensions 7865x2496x3025mm Wheel base 3625+1350mm
Front/rear wheel track 2022, 1830/1830mm Front/rear suspension 1500/890mm
Approach/departure angle 19/50° Maximum speed 75km/h
Chassis Manufacturer China National Heavy Duty Truck Group Co.,Ltd
Cab Configuration

HW76 cab,a row and a half deluxe cab(with sleeping berth),allowable 3 passengers

Air conditioner
Color white,other color is optional
Engine Model WD615.47
Emission Euro 2
Type 6 cylinders,in-line,4-stroke,water-cooled,turbo inter-cooling ,diesel engine
Rated power 371hp,rated power speed 2000rpm
Displacement 9726ml
Max.torque 1500N.m
Bore x stroke 126x130mm
Manufacturer China National Heavy Duty Truck Group Co.,Ltd
Tire Size 12.00R20 Steel wire tire.
Number 10+1 nos
Clutch 430 diaphragm clutch
Front axle HF9
Rear axle HC16
Steering ZF8118 Power assisted steering.
Drive form 6X4
Rated voltage 24V,DC
Transmissions HW19710 gearbox ,10 speed forward 2 reverse
Steering wheel Left hand drive
Selective configuration
If there is a slight change in the chassis parameters above,please take the actual product as the standard

Dump truck structure parameters
Van body dimensions 5600X2300X1000mm Side wall 6mm
Bottom plate 8mm Van body material Common steel
Lifting position Middle Dumping direction Rear
Oil Cylinder Domestic 220 Color and Logo Optional
Standard configuration chassis,sub frame,van body side 6mm bottom 8mm,domestic middle lifting hydraulic cylinder 220,common steel,four longitudinal beams,rectangular van body,single door
Selective configuration

40 Tons 336hp 371hp 6x4 SINOTRUK 10 Wheeler Dump Tipper Truck

40 Tons 336hp 371hp 6x4 SINOTRUK 10 Wheeler Dump Tipper Truck

40 Tons 336hp 371hp 6x4 SINOTRUK 10 Wheeler Dump Tipper Truck

40 Tons 336hp 371hp 6x4 SINOTRUK 10 Wheeler Dump Tipper Truck40 Tons 336hp 371hp 6x4 SINOTRUK 10 Wheeler Dump Tipper Truck

40 Tons 336hp 371hp 6x4 SINOTRUK 10 Wheeler Dump Tipper Truck



40 Tons 336hp 371hp 6x4 SINOTRUK 10 Wheeler Dump Tipper Truck

40 Tons 336hp 371hp 6x4 SINOTRUK 10 Wheeler Dump Tipper Truck

Cargo Box:

40 Tons 336hp 371hp 6x4 SINOTRUK 10 Wheeler Dump Tipper Truck

40 Tons 336hp 371hp 6x4 SINOTRUK 10 Wheeler Dump Tipper Truck

40 Tons 336hp 371hp 6x4 SINOTRUK 10 Wheeler Dump Tipper Truck

40 Tons 336hp 371hp 6x4 SINOTRUK 10 Wheeler Dump Tipper Truck

40 Tons 336hp 371hp 6x4 SINOTRUK 10 Wheeler Dump Tipper Truck

40 Tons 336hp 371hp 6x4 SINOTRUK 10 Wheeler Dump Tipper Truck

40 Tons 336hp 371hp 6x4 SINOTRUK 10 Wheeler Dump Tipper Truck

40 Tons 336hp 371hp 6x4 SINOTRUK 10 Wheeler Dump Tipper Truck

40 Tons 336hp 371hp 6x4 SINOTRUK 10 Wheeler Dump Tipper Truck
