HF7+ST16 Axle SINOTRUK 2 Sleepers 371hp Euro 2 Semi Trailer Truck
HF7+ST16 Axle SINOTRUK 2 Sleepers 371hp Euro 2 Semi Trailer Truck
HF7+ST16 Axle SINOTRUK 2 Sleepers 371hp Euro 2 Semi Trailer Truck
HF7+ST16 Axle SINOTRUK 2 Sleepers 371hp Euro 2 Semi Trailer Truck
HF7+ST16 Axle SINOTRUK 2 Sleepers 371hp Euro 2 Semi Trailer Truck
HF7+ST16 Axle SINOTRUK 2 Sleepers 371hp Euro 2 Semi Trailer Truck
HF7+ST16 Axle SINOTRUK 2 Sleepers 371hp Euro 2 Semi Trailer Truck
HF7+ST16 Axle SINOTRUK 2 Sleepers 371hp Euro 2 Semi Trailer Truck
HF7+ST16 Axle SINOTRUK 2 Sleepers 371hp Euro 2 Semi Trailer Truck
HF7+ST16 Axle SINOTRUK 2 Sleepers 371hp Euro 2 Semi Trailer Truck
HF7+ST16 Axle SINOTRUK 2 Sleepers 371hp Euro 2 Semi Trailer Truck
HF7+ST16 Axle SINOTRUK 2 Sleepers 371hp Euro 2 Semi Trailer Truck
Specifications
Brand Name :
SINOTRUK, HOWO, CNHTC
Model Number :
ZZ4257N3241V
Certification :
ISO/3C/BV/IFA/SGS
Place of Origin :
China
MOQ :
1unit
Price :
US$32000-USD45000/unit
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
2000 units per month
Delivery Time :
20-30 working days after deposit or LC
Packaging Details :
Nude, Waxing in RORO or bulk ship
Manufacturer :
SINOTRUK (CNHTC)
Series: :
HOWO
Product Name: :
semi trailer truck, container towing truck
Model: :
ZZ4257N3241V
Drive Type: :
6X4, LHD
Engine: :
WD615.47, 371HP, Euro II
Loading Capacity: :
25-40tons
Cabin: :
HW79, 2 Beths
Transmission: :
HW19710
Fifth Wheel :
2.0''/3.5''
Description

SINOTRUK HOWO 6x4 semi trailer truck, 371hp, Euro 2, 2 Sleepers, HF7+ST16 axle

SINOTRUK HOWO Tractor Truck, the best choice for you!

HF7+ST16 Axle SINOTRUK 2 Sleepers 371hp Euro 2 Semi Trailer Truck

  1. Lower Fuel Consumption
  2. Powerful Engine
  3. Stable Quality
  4. Enough Spare Parts for Service and Maintence

HF7+ST16 Axle SINOTRUK 2 Sleepers 371hp Euro 2 Semi Trailer Truck

Model: ZZ4257N3241V
Engine Make: CNHTC
Diesel: 4-stroke direct injection diesel engine
Engine model: WD615.47, Euro II emission standard
6-cylinder in-line with water cooling, turbo-charging and intercooling, 4 strokes
Maximum output: 371hp (273Kw) at 2200rpm
Maximum torque: 1470Nm at 1300-1600rpm
Number of cylinder: 6
Displacement: 9.726L
Bore/Stroke: 126/130mm
Ignition Sequence: 1-5-3-6-2-4
Fuel: diesel
Transmission Model: HW19710, 10F/2R, Manual Gearbox
Ratio Reverse: 14.28, 10.62, 7.87, 5.88, 4.38, 3.27, 2.43, 1.8, 1.34, 1, 13.91®
Max.Input Torque:1900NM
Cab HW79 model cab
with air conditioner, 2 bunks, MP3 radio
German VDO electrical control system.
Driver's chair: air bag chair
Driving Axle Model:ST16(Tandem axle)
Type:Central single reduction + hub reduction, welded axle housing.
Rated load(kg):2×16000
Ratio:4.42
Spring gage(mm):1020
Wheel tread(mm):1850
Input flange:Ф180
Differential device:Inter-wheel and inter-axle
Brake: Drum Ф420×185
Weight(Without lubricants)(kg):Middle:860/Rear axle:800
Wheel bolt(mm):Ф335-10×M22×1.5
Min rim size(inch):20
Lubricants(L):GL5 85W-90
Front Axle Model: HF7
Rated load(kg):7000
Maximum steering angle of inner wheel(°):45
Kingpin inclination(°):3
Camber angle(°): 1
Spring gage(mm): 850～900
Brake: Air drum brake
Min rim size(inch): 20
Steering ZF power steering, model ZF8098,
hydraulic steering with power assistance
Ratio: 26.2
Electrics Operating voltage: 24V, negative grounded
Starter: 24V, 5.4kw
Alternator: 3-phrase, 28V, 1000W
Batteries: 2x12V, 165Ah
Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light
Tyre Rims: 8.5-20, 10 hole-steel
Tyres: 315/80R22.5 Tubeless Tyres, 10+1Pcs
Brakes Service brake: dual circuit compressed air brake
Parking brake (emergency brake): spring energy, compressed air operating on rear wheels
Auxiliary brake: engine exhaust brake
Dimensions
(mm)		 Wheel base:3225+1350
Front wheel track:2022
Rear wheel track:1830
Front/Rear overhang: 1500/700
Approach/Departure angle (°):16/70
Overall Diamention: 6820×2520×3668 (L×W×H)
Weight
(Kg)		 Permissible loading capacity:32000-50000
Chassis dead weight:9260
Front axles loading capacity:9000
Rear axles loading capacity:2×16000
Performance Maximum driving speed (km/h):101
Maximum gradeability (%):29
Minimum turning circle (m):18.5
Fuel consumption (1/100 km):40
Others Fifth wheel: 2'' (#50)/3.5''(#90)
Color opition: red, yellow, blue, green, white
With ABS

HF7+ST16 Axle SINOTRUK 2 Sleepers 371hp Euro 2 Semi Trailer Truck

1, Containers transport from factories to the port

2, Logistics transport

3, Long distance heavy duty goods transport, like steel, coal, etc.

4, others

HF7+ST16 Axle SINOTRUK 2 Sleepers 371hp Euro 2 Semi Trailer Truck

HF7+ST16 Axle SINOTRUK 2 Sleepers 371hp Euro 2 Semi Trailer Truck

SINOTRUK (CNHTC) HOWO series 6x4 dump trucks (tipper trucks) are designed by SINOTRUK comprehensive with the world’s most advanced automotive technology and mature, reliable assembly parts.

1, Edition 1st tractor: Man chassis frame, aluminum housing transmission, single reduction driving axle, lightweight configuration, suitable for road transport.

2, Edition 5th tractor: reinforced double-layer chassis frame, 16 tons two-stage reduction driving axle, suitable for complicated road conditions and heavy haul conditions

3, WABCO four-channel ABS system and brake system

4, German VDO instrument and electrical control module, large LCD screen, intelligent control, to grasp the state of the vehicle

5, USA HUV rubber chassis suspension, light weight, toughness and over loading,

6, German ZF8098 steering system, portable, flexible, reliable and easy to repair

7, Engine with WABCO two-cylinder air compressor and BORGWARNER turbocharger, to improve the reliability and security of the brake valves.

8, MANN HUMEL diesel filters and air filters guarantee the air clean, improve fuel economy greatly, reduce the noise, and put an end to the abnormal wear of the engine.

9, MAN EVB exhaust valve brake system, to improve braking safety, reducing brake wear, and greatly reduce drivers’ fatigue. Convenient maintenance, and low cost.

10, German VOSS pipe joints, easy installation, good sealing, stable air pressure

HF7+ST16 Axle SINOTRUK 2 Sleepers 371hp Euro 2 Semi Trailer Truck

HF7+ST16 Axle SINOTRUK 2 Sleepers 371hp Euro 2 Semi Trailer Truck

By Roro or Bulk or Flat Rack Container according to your specific requests.

HF7+ST16 Axle SINOTRUK 2 Sleepers 371hp Euro 2 Semi Trailer Truck

HF7+ST16 Axle SINOTRUK 2 Sleepers 371hp Euro 2 Semi Trailer Truck

1, the whole truck warrenty is half year or 100000km, base on whichever comes first.

2, professional sevice team, enough spare parts to make you away from future worries.

3, professional trainning teachers for your drivers or engineers on repair and maintenance

HF7+ST16 Axle SINOTRUK 2 Sleepers 371hp Euro 2 Semi Trailer Truck
