500um Copper Powder Filter Nickel Ss Mesh EDI System In Water Treatment
500um Copper Powder Filter Nickel Ss Mesh EDI System In Water Treatment
500um Copper Powder Filter Nickel Ss Mesh EDI System In Water Treatment
500um Copper Powder Filter Nickel Ss Mesh EDI System In Water Treatment
500um Copper Powder Filter Nickel Ss Mesh EDI System In Water Treatment
500um Copper Powder Filter Nickel Ss Mesh EDI System In Water Treatment
500um Copper Powder Filter Nickel Ss Mesh EDI System In Water Treatment
500um Copper Powder Filter Nickel Ss Mesh EDI System In Water Treatment
Specifications
Brand Name :
KUNYA
Model Number :
KYF-210110A
Place of Origin :
CHINA
MOQ :
1 Piece
Price :
USD$1.95-USD$35.65
Payment Terms :
T/T, Western Union
Supply Ability :
165200 Pieces per month
Delivery Time :
25 days
Packaging Details :
wooden case
Product name :
Copper Powder Sintered Filter
Filter rating :
0.2um-500um
Shape :
Customers' Request
Thickness :
1-5mm
Color :
stainless steel, bronze
Application :
Kinds Filtration Industry
Working temperture :
-200℃-600℃
Material :
Stainless steel, Titanium,Bronze
Advantage :
Easy to be cleaned & long life
Length :
5-1000mm
Feature :
Corrosion Resistance
Porosity :
28-50%
Description

Stainless Steel / Copper / Nickel Sintered Powder Filter

Copper Powder Sintered Filter Introductions

Stainless Steel Powder sintered filter is made of stainless steel powder by mould pressing, high-temperature sintered and forming. With high mechanical strength, high temperature, good corrosion resistance, uniform aperture distribution, good permeability, can be cleaned and recycled, welding machine, such as mechanical processing. Widely used in the recovery of catalysts, chemical, pharmaceutical, beverage, food, metallurgy, petroleum, environmental protection and other fields of gas and liquid filtration and separation; all kinds of gas, steam dust removal, bacteria removal, oil mist, silencing, flame resistance, gas buffer, etc.

Porosity: 28%-50%

Aperture: 4um-160um

Filtration accuracy: 0.2um-100um

Copper Powder Sintered Filter can be made into tube type and plate type. Because of the good permeability, filter fitness and high stock utilization, they are widely used in medical industry, chemical industry, metallurgical industry and field of gas purification.

Copper Powder Sintered Filter Features

Applications for sintered stainless steel powder filter element:

· Dust, bacteria and oil fog removal of gas and steam.

· Noise reduction, gas buffer.

· The recycle of catalysts.

· Decarburization filtration.

· Viscous liquid filtration.

· Strong polar solvent filtration.

· Retention of particles from off-gas of fluidized beds.

· The filtration and separation of pharmaceutical, beverage, food, metallurgy, petroleum and other fields.
Features:

· High filtration efficiency.

· High mechanical strength.

· High permeability and porosity.

· Anti-corrosion and anti-pressure.

· Even distribution of pores catalysis recycling accurate filtering.

· Can be used at high and low temperature.

· Easy to clean and can be used for many times.

· Long service life.
Specifications:

· Item: sintered stainless steel powder filter element.

· Material: stainless steel powder.

· Thickness of wall: 1.0 mm, 2.0 mm, 3.0 mm, 4.0 mm, 5.0 mm, etc.

· Length: 10", 20", 30", 40".

· Working Temperature: -200 °C to 1000 °C.
Copper Powder Sintered Filter Applications
  • Titanium filter with its unique properties can be widely used in the pharmaceutical industry, water treatment industry, food industry, biotechnology, chemical industry, petrochemical industry, metallurgical industry and gas purification, is a new filter with broad development prospects.Typical functions include:​
  • 1. pharmaceutical industry, such as infusion, small injections, eye drops before the end.
  • 2. impurity filter, decarbonization filter and precision filter during the productuon of medicine.
  • 3. Security filter for UF system, RO system and EDI system in water treatment.
  • 4. Food and beverage industry such as drinks, juice, wine, beer, vegetable oil, mineral water, etc.
  • 5. Chemical industry: liquid products, liquid raw materialfiltration, clay filtration in dye industry.
  • 6. Gas filtration:steam, compressed air, catalyst filtration.

Sintered Bronze Copper Powder Filter Types

Name
Filter rating 5-70um sintered powder porosity tube metal filter
Production
Diameter (Width)
Thickness
Customized
Sintered porous round discs
φ5-φ400mm
φ5-φ400mm
1-20mm
Yes
Sintered porous sheets
5-600mm
5-400mm
1-20mm
Yes
Sintered porous tubes
100-1200mm
φ20-φ200mm
1-10mm
Yes
Sintered porous cartridge
100-1200mm
φ20-φ200mm
1-10mm
Yes

Copper Powder Sintered Filter Characteristics:

1. Shape stability, shock resistance and alternating load capacity superior to other metal materials;

2. Air permeability, stability of separation effect;

3. Excellent unloading strength, suitable for use in high temperature, high pressure and strong corrosive environment;

4. Especially suitable for high-temperature gas filtration;

5. Can be customized according to user requirements of various shapes and precision products, can also be welded to use a variety of interfaces.
