Food Medical Bronze Sintered Metal Powder Filter 0.2um Porous
Food Medical Bronze Sintered Metal Powder Filter 0.2um Porous
Food Medical Bronze Sintered Metal Powder Filter 0.2um Porous
Food Medical Bronze Sintered Metal Powder Filter 0.2um Porous
Food Medical Bronze Sintered Metal Powder Filter 0.2um Porous
Food Medical Bronze Sintered Metal Powder Filter 0.2um Porous
Food Medical Bronze Sintered Metal Powder Filter 0.2um Porous
Food Medical Bronze Sintered Metal Powder Filter 0.2um Porous
Specifications
Brand Name :
KUNYA
Model Number :
KYF212182
Place of Origin :
CHINA
MOQ :
1 Piece
Price :
USD$1.95-USD$35.65
Payment Terms :
T/T, Western Union
Supply Ability :
165200 Pieces per month
Delivery Time :
25 days
Packaging Details :
wooden case
Product name :
Sintered Porous Stainless Steel Filters
Filter rating :
0.2um-500um
Shape :
customized
Thickness :
1-5mm
Color :
stainless steel, bronze
Application :
Chemical Industry
Working temperture :
-200℃-600℃
Material :
Stainless steel, Titanium,Bronze
Advantage :
long life span
Length :
5-1000mm
Description

Plate Tube Disc Types Food Medical Grade 316L Metal Powder Sintered Porous Stainless Steel Filters 0.2 Um To 100 Micron

Sintered Porous Stainless Steel Filters Introductions

1.1-100 microns
2.Stainless steel,Copper, brass,titanium
3.OEM,Non-standard
4.Mesh sintered

Material: stainless steel,brass,bronze

Category: stainless steel powder sintering, stainless steel nets sintering, bronze powder sintering, mesh sintering

Filtration precision: 2-150 micron

Structure: flake, Cartridge, tube, tubular shape, the goblet, bowl, plate, tapered, T shape, Cap shape, cylindrical clavite, Housing

sintered disc filters consist of highly uniform, interconnected networks of pores with tortuous paths that trap solid particles in gas or liquid. Excellent depth filters with superior mechanical strength. Stainless Steel Type 316L withstands temperatures up to -100°C in oxidizing and 600°C in reducing environments. These filters can be cleaned by other methods, such as ultrasonic baths or reverse flow flushing. If your application requires even greater resistance to corrosion, temperature, wear, and vibration, other nickel-based alloys are available.

Sintered stainless steel powder filter elements can be made into tube type and plate type. Because of the good permeability, filter fitness and high stock utilization, they are widely used in medical industry, chemical industry, metallurgical industry and field of gas purification.

Food Medical Grade 316L Metal Powder Sintered Porous Stainless Steel Filters Features

Applications for sintered stainless steel powder filter element:

· Dust, bacteria and oil fog removal of gas and steam.

· Noise reduction, gas buffer.

· The recycle of catalysts.

· Decarburization filtration.

· Viscous liquid filtration.

· Strong polar solvent filtration.

· Retention of particles from off-gas of fluidized beds.

· The filtration and separation of pharmaceutical, beverage, food, metallurgy, petroleum and other fields.
Features:

· High filtration efficiency.

· High mechanical strength.

· High permeability and porosity.

· Anti-corrosion and anti-pressure.

· Even distribution of pores catalysis recycling accurate filtering.

· Can be used at high and low temperature.

· Easy to clean and can be used for many times.

· Long service life.
Specifications:

· Item: sintered stainless steel powder filter element.

· Material: stainless steel powder.

· Thickness of wall: 1.0 mm, 2.0 mm, 3.0 mm, 4.0 mm, 5.0 mm, etc.

· Length: 10", 20", 30", 40".

· Working Temperature: -200 °C to 1000 °C.

Food Medical Grade 316L Metal Powder Sintered Porous Stainless Steel Filters Uses
Material
Pure titanium/316L powder
Filter Rating
0.5um-50um
Porosity
30-45%
Penetrability
3-800M³/M²hKPa
Working pressure
2.0MPa
Operating temperature
300℃
Shape
Disc,sheet,tube,round bar,cap
Specific surface area
10-40cm²/cm³

Food Medical Grade 316L Metal Powder Sintered Porous Stainless Steel Filters Types

Name
Filter rating 5-70um sintered powder porosity tube metal filter
Production
Diameter (Width)
Thickness
Customized
Sintered porous round discs
φ5-φ400mm
φ5-φ400mm
1-20mm
Yes
Sintered porous sheets
5-600mm
5-400mm
1-20mm
Yes
Sintered porous tubes
100-1200mm
φ20-φ200mm
1-10mm
Yes
Sintered porous cartridge
100-1200mm
φ20-φ200mm
1-10mm
Yes
