Specifications
Brand Name :
KUNYA
Model Number :
KYF-2101109
Place of Origin :
CHINA
MOQ :
1 Piece
Price :
USD$1.95-USD$35.65
Payment Terms :
T/T, Western Union
Supply Ability :
165200 Pieces per month
Delivery Time :
25 days
Packaging Details :
wooden case
Product name :
Sintering Glass Media Strainer
Filter rating :
0.2um-500um
Shape :
Customers' Request
Thickness :
1-5mm
Color :
stainless steel, bronze
Application :
Liquid Filter
Working temperture :
-200℃-600℃
Material :
Stainless steel, Titanium,Bronze
Advantage :
long life span
Length :
5-1000mm
Description

Wholesale Polymer Melt Filter Cartridge Stainless Steel Sintering Glass Media Strainer

Sintering Glass Media Strainer Introductions

The sintered filter is made of stainless steel power ,through the sub-screen, forming, sintering to micro-filter components. According to user requirements can produce a variety of shapes, structure, different size, porosity of porous components, such as: hood, cap, sheet, tube, rod-like filter element.

Sintering Glass Media Strainers can be made into tube type and plate type. Because of the good permeability, filter fitness and high stock utilization, they are widely used in medical industry, chemical industry, metallurgical industry and field of gas purification.

Sintering Glass Media Strainer Features and Benefits:

1) Uniform structure, narrow pore size distribution and high separation efficiency.

2) High porosity, low filtration resistance and high permeation efficiency.
3) High temperature, generally about 280 degrees in normal use.
4) Chemical stability, acid corrosion, with antioxidant properties.
5) No particles off, do not make the liquid form a secondary pollution, in line with food hygiene and pharmaceutical GHP
requirements.
6) Mechanical properties, and can be filter press filter, simple operation.
7) Low pressure, small footprint, large flow.
8) Strong anti-microbial capacity, does not work with micro-organisms.
9) Forming process is good, the whole no welding length of up to 1000 mm.
10) Can be online regeneration, easy to clean, long life (usually several times the membrane filter).

Sintering Glass Media Strainer Uses
Material
Pure titanium/316L powder
Filter Rating
0.5um-50um
Porosity
30-45%
Penetrability
3-800M³/M²hKPa
Working pressure
2.0MPa
Operating temperature
300℃
Shape
Disc,sheet,tube,round bar,cap
Specific surface area
10-40cm²/cm³

Sintering Glass Media Strainer Types

Name
Filter rating 5-70um sintered powder porosity tube metal filter
Production
Diameter (Width)
Thickness
Customized
Sintered porous round discs
φ5-φ400mm
φ5-φ400mm
1-20mm
Yes
Sintered porous sheets
5-600mm
5-400mm
1-20mm
Yes
Sintered porous tubes
100-1200mm
φ20-φ200mm
1-10mm
Yes
Sintered porous cartridge
100-1200mm
φ20-φ200mm
1-10mm
Yes

Sintering Glass Media Strainer Characteristics:

1. Shape stability, shock resistance and alternating load capacity superior to other metal materials;

2. Air permeability, stability of separation effect;

3. Excellent unloading strength, suitable for use in high temperature, high pressure and strong corrosive environment;

4. Especially suitable for high-temperature gas filtration;

5. Can be customized according to user requirements of various shapes and precision products, can also be welded to use a variety of interfaces.

Melt 0.2um 2.0 MPa Sintered Metal Powder Filter Glass Media StrainerMelt 0.2um 2.0 MPa Sintered Metal Powder Filter Glass Media Strainer

Melt 0.2um 2.0 MPa Sintered Metal Powder Filter Glass Media Strainer

Melt 0.2um 2.0 MPa Sintered Metal Powder Filter Glass Media Strainer
