100 Mesh 300 Mesh 0.1mm Cr20ni80 Nichrome Wire Mesh
100 Mesh 300 Mesh 0.1mm Cr20ni80 Nichrome Wire Mesh
100 Mesh 300 Mesh 0.1mm Cr20ni80 Nichrome Wire Mesh
100 Mesh 300 Mesh 0.1mm Cr20ni80 Nichrome Wire Mesh
100 Mesh 300 Mesh 0.1mm Cr20ni80 Nichrome Wire Mesh
100 Mesh 300 Mesh 0.1mm Cr20ni80 Nichrome Wire Mesh
100 Mesh 300 Mesh 0.1mm Cr20ni80 Nichrome Wire Mesh
100 Mesh 300 Mesh 0.1mm Cr20ni80 Nichrome Wire Mesh
100 Mesh 300 Mesh 0.1mm Cr20ni80 Nichrome Wire Mesh
100 Mesh 300 Mesh 0.1mm Cr20ni80 Nichrome Wire Mesh
Specifications
Brand Name :
KUNYA
Model Number :
KYF2181
Place of Origin :
China
MOQ :
1 piece
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
158741000 pieces per month
Delivery Time :
15-20 days
Packaging Details :
wooden case
Product name :
NiChrome Mesh
Usage :
Industry
Wire Diameter :
0.01-2.0mm
Application :
Woven Wire Mesh
Weave style :
plain weave, twill weave, dutch weave
Material :
Nichrome wire (Cr20Ni80, Cr20Ni35,Cr15Ni60)
Mesh count :
1-8000mesh
Length :
1-30m common, or customized
Type :
Weave Wire Mesh
Feature :
High temperature corrosion resistance
Description
Cr20Ni80 Nichrome wire mesh supplier
Product Description
Material:Ni-Cr alloy
Specifications:10Mesh—300Mesh
Characteristics:Good ductility,High tensile strength,Oxidation resistance,Sulfur resistance,Permeability resistance,Superior elongation,Non-magnetic,resistance and temperature coefficient are stable,Long-term use will not cause brittle fracture.
Applications:Nichrome woven wire mesh is widely used in the aerospace, shipbuilding, war industry, chemical machinery, electric power,desalination, medical apparatus and instruments.
Specification
Brand performance
Cr15Ni60
Cr20Ni80
Cr20Ni35
Main chemical composition%
C
≤
0.08
0.08
0.10
P
0.02
0.02
0.03
S
0.015
0.015
0.025
Mn
0.60
0.60
1.00
Si
0.75～1.60
0.75～1.60
1.00～3.00
Cr
15.00～18.00
20.00～23.00
18.00～21.00
Ni
55.00～61.00
Surplus
34.00～37.00
Al
≤0.50
≤0.50
≤0.50
Mo
/
/
/
Fe
Surplus
≤1.00
Surplus
Nb
/
/
/
Maximum operating temperature℃
1150℃
1200℃
1100℃
Melting point ℃
1350℃
1400℃
1350℃
Density g/cm³
8.2g/cm³
8.4g/cm³
8.0g/cm³
Resistivity 20℃ Ω·mm²/m
1.12±0.06
1.14±0.05
1.05±0.05
Elongation δ%
>20
>20
>25
Rapid life test ℃/h
1120/100
1175/100
1120/100
Magnetism
Non-magnetic

100 Mesh 300 Mesh 0.1mm Cr20ni80 Nichrome Wire Mesh100 Mesh 300 Mesh 0.1mm Cr20ni80 Nichrome Wire Mesh100 Mesh 300 Mesh 0.1mm Cr20ni80 Nichrome Wire Mesh100 Mesh 300 Mesh 0.1mm Cr20ni80 Nichrome Wire Mesh

100 Mesh 300 Mesh 0.1mm Cr20ni80 Nichrome Wire Mesh100 Mesh 300 Mesh 0.1mm Cr20ni80 Nichrome Wire Mesh100 Mesh 300 Mesh 0.1mm Cr20ni80 Nichrome Wire Mesh100 Mesh 300 Mesh 0.1mm Cr20ni80 Nichrome Wire Mesh

100 Mesh 300 Mesh 0.1mm Cr20ni80 Nichrome Wire Mesh

100 Mesh 300 Mesh 0.1mm Cr20ni80 Nichrome Wire Mesh

100 Mesh 300 Mesh 0.1mm Cr20ni80 Nichrome Wire Mesh

100 Mesh 300 Mesh 0.1mm Cr20ni80 Nichrome Wire Mesh

100 Mesh 300 Mesh 0.1mm Cr20ni80 Nichrome Wire Mesh

100 Mesh 300 Mesh 0.1mm Cr20ni80 Nichrome Wire Mesh

100 Mesh 300 Mesh 0.1mm Cr20ni80 Nichrome Wire Mesh
