316L Sintered Metal Filter Disc , Wire Mesh Filter Disc 0.5 -100 Micron Size
316L Sintered Metal Filter Disc , Wire Mesh Filter Disc 0.5 -100 Micron Size
316L Sintered Metal Filter Disc , Wire Mesh Filter Disc 0.5 -100 Micron Size
316L Sintered Metal Filter Disc , Wire Mesh Filter Disc 0.5 -100 Micron Size
Specifications
Brand Name :
JUMAO
Model Number :
JM-SFD9643
Certification :
ISO
Place of Origin :
CHINA
MOQ :
1 PCS-1000 PCS
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
500-10000 pcs as different size
Delivery Time :
8-40days
Packaging Details :
Wooden Boxes
Material :
SS304, SS316, SS316L
Mesh count :
40-200mesh
Filter Rating :
12 to 1000 microns
Working Temperature :
-40 - 600°C
Shape :
Filter Disc
Wire diameter :
0.016-2.5mm
Description

Stainless Steel 316 L Sintered Filter Disc For BDO And TDI Applications

Our sintered filter discs are manufactured in sheets in standard sizes of 2’x4′, or 4’x4′. These sintered filter discs laminates can be custom made to meet a thickness requirement, a filtration rating, and/or a certain number of layers. If you have your own custom design, we can sinter just about any combinaton of wire mesh layers together to form a sintered mesh part.

In general, we use 316L stainless steel wire mesh for the woven wire mesh layers, and 304 stainless steel for the perforated plate. Other special alloys can be incorporated as well.

The woven wire mesh layers can be customized to meet a filtration rating, and the thickness of the perforated plate as well as the type of perforations can be customized as well.

Our standard size is 2’x4′, or 4’x4′, but different size sheets and discs can be made as well. This type of sintered mesh laminate is often used in tube form. These sintered filter tubes can be custom made with a variety of diameters and lengths.

Apllication of sintered wire mesh

Centrifugal filter
Sintered wire mesh processed into can be rotated dynamically filter allows media to be effective filtration and separation. Mainly used in chemical, pharmaceutical and food industry.

Cone filter
Mainly used in chemical, pharmaceutical and beverage industries. According to the characteristics of the filter shape, make the media better diversion, separation and filtration.

Introduction of sintered filter discs

Items Micron stainless steel sintered filter disc
Material Stainless Steel wire 304 316 316L and FeCrAl, 310S, Monel, Hastelloy,Inconel, nickel, titanium or as per request.
Micron size 0.5 -100micron
Thickness 0.5mm 1.7mm(standard thickness) 3.5mm or as customized
Layers 1 2 3 4 5 6 layers or customized.
Screen Sizes 500x1000mm, 600x1200mm, 1000x1000mm, 1200x1200mm 1200x1500mm ...
Deep processed Cylinder tubes, sintered disc&packs&baskets or others.
Customized OEM and customized can be acceptable
