Specifications
Brand Name :
JUMAO
Model Number :
JM-SFD9634
Certification :
ISO
Place of Origin :
CHINA
MOQ :
1 PCS-1000 PCS
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
500-10000 pcs as different size
Delivery Time :
8-40days
Packaging Details :
Wooden Boxes
Material :
Monel
Diameter :
200mm
Thickness :
Customized
Structure :
7 Layers
Application :
Pharmaceutical
Heat Resistance :
Up to 600C
Description

Special Allloy Steel Hastelloy Sintered Filter Disc Made by Woven Wire Mesh

Sintered mesh filter disc is single or multiple layers of diffusion-bonded woven wire mesh laminates. Through precision sintering and calendaring, filter disc is equipped with several important properties for better filtration. The prominent features will be mechanical strength, stable mesh aperture and low-pressure drop. Sintered filter disc is designed to provide economical filtration media to critical areas such as hydraulic, valve, pump, servo and other applications.

Our JUMAO team has been always developing new filtration media model to the market to better solve customers' filtration troubles. Apart from common flat filter discs, pleated filter discs are getting popular.

Features for Sintered Filter Discs

High rigidity and stability for long service life.
Excellent resistance to corrosion, acid, alkali and abrasion.
High heat resistance, it can be used under the temperature ranging from -200 °C to 600 °C.
Various filter ratings to choose and great filter precision for different uses.
Good dirt holding capacity.
Easy to clean and reusable, therefore reduce downtime.
According to various demands, sintered metal filter discs can be shaped into round, square, rectangular, oval, ring and others. Single layer or multi-layer can be choosed.

Stainless steel sintered filter discs' specification
Item Mesh counts Wire Diameter (mm) Aperture (mm)
SSSFD01 8 - 28 0.3 - 1 0.8 - 2.66
SSSFD02 35 0.17 0.56
SSSFD03 40 0.23 0.40
SSSFD04 50 0.20 0.31
SSSFD05 60 0.15 0.27
SSSFD06 70 0.12 0.24
SSSFD07 80 0.13 0.19
SSSFD08 90 0.12 0.16
SSSFD09 100 0.10 0.15
SSSFD10 120 0.09 0.12
SSSFD11 150 0.063 0.11
SSSFD12 180 0.053 0.09
SSSFD13 200 0.053 0.07
SSSFD14 220 0.05 0.065
SSSFD15 250 0.04 0.062

Application Of sintered filter disc:

Solid gas separation Muffler, silencer
Air purification Filtering oil
Dedusting, Isolation dust, dust proof Gas-oil dissociation
Gas liquid separation Moisture proof
Heat insulation Cooling
Uniform gas,well-distributed, diffuse gas or oil or heat Breathable protection
Pharmaceutical, medicine Chemical
Chemical fiber Filtration for high temperature environment
High pressure reverse wash filtering Acid and alkali corrosion environment filtering
