Duplex Steel 2207 Sintered Filter Disc Applied In Pharmaceutical

Stainless Steel Wire Mesh Sintered Filter Discs is a process that improves the characteristics of woven wire mesh by bonding the contact points of all the wires together to form a mesh whose wires are securely fused in place. This is achieved through a combination of heat and pressure,and the result is a single layer sintered wire mesh.

Sintered wire mesh is a specifical wire mesh, which let the 5-7 layers wire mesh in the high tempreture melt together.

Specification of sintered filter disc

· Material: Common material is stainless steel 316 L or 304. Other materials are also available like alloys, stainless steel 316, stainless steel 304 L, etc.

· Filtering rate: 0.22 to 300 micron.

· Thickness: Ranging from 1 mm to 10 mm, or make to order.

· Diameter: 10 mm to 3000 mm (with a hole in center - inner diameter: 4 mm, 5 mm, 6 mm or above, outer diameter can reach 3000 mm).

· Heat resistance: -200 °C - 600 °C continuous filtration.

Applications for Sintered wire mesh Filter Discs

1.Chemical products
2.Foodstuffs and spices (milk powder, coffee, tea, rice, grains)
3.Stones and powders (minerals,diamond sizing, ores, alumina)
4.Pharmaceutical products
5.Boards and fixing plates (dividing shavings and wadding)
6.Paper (sieving wood shavings, preparation of coatings)
7.Metal powders (Precision sieving of metal powders)
8.Rubber
9.Animal feedstuffs (dedusting pellets, sieving crumbs, molasses based foodstuffs) 10.Fertilisers (phosphates, potash, urea, mixed fertilisers)
11.Sugar and salt (sizing)
12.plastic Recycling

Features of sintered filter disc

• Good permeability and high dirt-holding capacity.
• High temperature and pressure resistance.
• Excellent corrosion resistance: acid and alkali resistance.
• Excellent mechanical properties: easy cutting, easy welding.
• Accurate and steady filtration rate.
• Cleanable and reusable.
• Long service life.
