G99 High Efficiency 70 kW AC DC Converter RS485 Wall Mounted 460*190*800mm
G99 High Efficiency 70 kW AC DC Converter RS485 Wall Mounted 460*190*800mm
Specifications
Brand Name :
SINY
Model Number :
MASI-70KW1
Certification :
G99/CE/CQC
Place of Origin :
CHINA
MOQ :
1
Price :
Exwork: 5,000~9,000 USD
Payment Terms :
T/T,
Supply Ability :
200 Per month
Delivery Time :
45 Work days
Packaging Details :
Carton
power :
70kW
Efficiency :
≥98.2%
Standby power consumption :
<120W
Installation :
Wall mounting
Operating temperature :
-25℃ ~ +55℃(Power derating above +45℃)
Protection level :
IP20
Size (W*H*D) :
460*190*800mm
Relative humidity :
0~95%，No condensation
Communication mode :
RS485、CAN、LAN、REPO
Noise :
＜68dB
Weight :
45kg
Display :
Yes
Description

70kW AC DC Bidirectional Converter Grid-connected Type for Micro Grid Energy Storage System

Features

  • Wiith its own monitoring system, touch screen can be external, can be convenient to build a small energy storage system.
  • DC voltage design:600V~900V
  • Adaptable to a variety of grid voltages: AC380V/400V/415V.
  • Three-level design,low harmonics.
  • Small volume, less occupied space and convenient installation.
  • Charge/discharge conversion less than 20ms.
  • Convenient multi-device parallel network: Multi-branch high-power energy storage system can be formed by multiple PCS in parallel.
  • The 3U standard rack design can be perfectly combined with the lithium battery cabinet to form a distributed energy storage cabinet.
  • High power density, small size, two people can carry the installation by hand.
  • Three level design, low harmonics, good power quality.
  • Perfect matching of power battery echelon utilization application scenarios

Product specification

Model

MASI-70KW1-1P

MASI-70KW1-2P
DC side parametersVoltage rangeDC600V～DC900V
Rated power

70kW
Maximum current

116A
Number of DC channels

1

2
AC grid-connection parametersGrid type

3L+PE
Rated power

70kW
Rated voltage

AC380V/400V
Rated current

106A
Voltage range-15%～+15%
Rated frequency

50Hz/60Hz
Frequency rangeRated frequency±3Hz
Power factor

-1~+1
Output harmonic≤3%
EnvironmentWorking temperature-25℃～55℃(Derating when temperature is above 45 °C)
Storage temperature-40℃～70℃(No battery)
Relative humidity0％RH～95％RH,No condensation
Working altitudeWhen the temperature is 45 °C, derating is not required for 2000m. Derating ranges from 2000m to 4000m
Noise＜68dB

Communications and Management

Communication interfaceRS485,CAN,LAN
Communication protocolCAN,ModBus TCP,ModBus RTU
Installation Wall type
Display Yes
Highest efficiency

98.2%

EMC

Class A
CertificationG99,CQC,CE

-
Isolation methodNo isolation
Protection grade

IP20

Cooling wayAir cooling, intelligent fan speed control
Size(W*H*D)

460*190*800mm

Weight

45kg



All performance and parameters shall be subject to the latest confirmation of our technical department
About Us:
SINY NEW ENERGY CO., LTD is an innovative company focused on PCS product development, production and sales in the field of energy storage and energy Internet technology, and is committed to providing advanced energy storage technology application solutions for the power industry, industrial and commercial enterprises and new energy industry, helping users solve the core pain points of the industry and improving economic benefits for enterprises. XI'AN SINY ENERGY POWER CO., LTD was founded in 2015, as the R&D center of the company, located in Xi'an High-tech Industrial Development Zone.
