Specifications
Model Number :
SMD 1610 7K 32.768kHz
Type :
Tuning Fork crystal
Place of Origin :
China
Brand Name :
SJK
Operating Temperature Range (°C) :
-20~+70℃,-40~+85℃
Dimension :
1610
Package Type :
SMD
Frequency Tolerance :
±20ppm,or specify
Load Capacitance :
12.5pF,other spec
Frequency Range :
32.768kHz
Frequency :
32.768kHz
Frequency Stability :
±20ppm
Mounting Type :
Surface Mount
Application level :
Industrial & Consumer
Description :
SJK
MOQ :
3000 pieces
Price :
$0.25 - $0.32/pieces
Description

SMD 1610 xtal Tuning Fork crystal-Series 7K Frequency Tolerance or specify Best Choice

7K 32.768 kHz SMD Crystal

Frequency Range: 32.768 kHz

Overtone: Fundamental Size: 1.6×1.0×0.5 mm

Application: Small communication device, Clock and more.

Specifications and Dimensions

Features:

· 2 pads surface mount package

· 1610 size miniature and lightweight SMD tuning fork crystal resonator with a low profile of 0.5mm.

· High reliable environmental performance.

· Automatic mounting and reflow soldering.

· Application for small communication device, Clock, Wireless communication, Telecommunication, Wave clock, RFID products and more.

· RoHS Compliant /Pb-Free

· Electrical Specifications:

Item /Type

7K (1610 SMD 32.768kHz Crystal Unit)

Frequency Range

32.768kHz

Frequency Tolerance

±20ppm, or specify

Load Capacitance

12.5pF, or specify

Operating Temperature

-20~+70℃, -40~+85℃

Storage Temperature

-55~+125℃

Turnover Temperature

±25℃±5℃

Parabolic Coeffcient

(0.03±0.01)*10-6/℃2

Drive Level

0.5μW Max.

Shunt Capacitance

1.3pF Typ.

Aging (at 25℃)

±3ppm at first year

Series Resistance

90KΩ Max.

Packing Unit

3000pcs. /Reel

Dimensions [Units: mm]

SMD 1610 xtal Tuning Fork crystal-Series 7K Frequency Tolerance or specify Best Choice

REMARK:SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE. PLEASE CONFIRM WITH OUR SALES ENGINEER FOR PDF FILE.
