6MH Series DIP8 Crystal Oscillator With Symmetry Of 40-60% High Frequency
6MH Series DIP8 Crystal Oscillator With Symmetry Of 40-60% High Frequency
6MH Series DIP8 Crystal Oscillator With Symmetry Of 40-60% High Frequency
6MH Series DIP8 Crystal Oscillator With Symmetry Of 40-60% High Frequency
Specifications
Brand Name :
SJK
Model Number :
6MF Series DIP14 Crystal Oscillator
Certification :
SGS, RoHS, REACH
Place of Origin :
China
MOQ :
500 pcs
Price :
Negotiate
Payment Terms :
T/T
Supply Ability :
30K pcs per Month
Delivery Time :
2~4weeks
Packaging Details :
1000pcs /Box
Type :
6MH DIP-8 Half-Size Crystal Oscillator
Frequency Range :
0.25~180MHz
Size :
12.7*12.7*5.3mm
Output :
CMOS
Supply Voltage :
3.3V / 5.0V
Function :
Tri-state
Description

6MH Series DIP8 Crystal Oscillator with Symmetry of 40-60% for High Frequency and Stability Applications

Features:

  • All metal welded half-size (DIP-8) package, size with 12.7*12.7*5.3mm.
  • Tri-state function
  • Supply voltage: 3.3V /5.0V
  • Available frequency range: 0.25MHz To 180MHz
  • Low phase noise and jitter
  • Application for test equipments, Electronic instruments, Telecommunications, Avionics, Smart grid, etc
  • RoHS Compliant /Pb Free

Electronic Specifications:

Item 6MH Series DIP8 Crystal Oscillator
Output Type CMOS
Output Load 15pF, or specify
Frequency Range 0.25MHz to 180MHz
Supply Voltage 3.3V / 5V
Frequency Stability (All Condition) ±20ppm, ±25ppm, ±30ppm, ±50ppm, or specify
Current Consumption 45mA max.
Stand-by Current 20µA max.
Symmetry 40~60%
0 Level Output Voltage (VOL) 0.1 Vcc max.
1 Level Output Voltage (VOH) 0.9 Vcc min.
Rise Time /Fall Time 5.0ns max.
OE 0 Level Output Voltage (VIL) 0.2 Vcc max.
OE 1 Level Output Voltage (VIH) 0.8 Vcc min.
Start-up Time 5.0ms max.
Operating Temperature -40°C To +85°C, or specify
Storage Temperature -55°C To +125°C, or specify
Phase Jitter 1pS max.
Package Size 12.7*12.7*5.3mm

Dimensions:

6MH Series DIP8 Crystal Oscillator With Symmetry Of 40-60% High Frequency
