SMD 3225 TCXO With Clipped Sinewave Output 32.000MHz 1.8-3.3V
SMD 3225 TCXO With Clipped Sinewave Output 32.000MHz 1.8-3.3V
SMD 3225 TCXO With Clipped Sinewave Output 32.000MHz 1.8-3.3V
SMD 3225 TCXO With Clipped Sinewave Output 32.000MHz 1.8-3.3V
Specifications
Brand Name :
SJK
Certification :
SGS, RoHS, REACH
Place of Origin :
China
MOQ :
3000pcs
Price :
negotiable
Payment Terms :
T/T
Supply Ability :
70KKpcs/M
Delivery Time :
4-6 wks
Packaging Details :
3Kpcs/Reel
Model :
7T Series SMD TCXO / VC-TCXO
Frequency range :
10~52MHz
Supply voltage :
1.8V~3.3V
Frequency stability :
±0.5ppm~±2.0ppm
Size :
3.2*2.5*0.9mm
Applications :
Mobile Phone, GPS, Wireless Communications, IoT, etc
Description

SMD 3225 TCXO With Clipped Sinewave Output 32.000MHz 1.8-3.3V

Features

Output frequency range from 10MHz to 52MHz

3225 size, 0.90mm high SMD TCXO /VC-TCXO

Low voltage operation and low phase noise

Temperature stability: ±0.5ppm~±2.5ppm

VCTCXO available

Automatic mounting and reflow soldering

Applications: Smartphones, Wearables, IoT, GPS, WLAN and more

RoHS Compliant & Pb-Free

Specifications

Type 7T Series SMD TCXO / VC-TCXO
Output Type Clipped Sine wave
Output Load 10KΩ//10pF
Supply Voltage 1.8~3.3V
Frequency Range 10~52MHz
Supply Current 2.0mA Max.
Output Level 0.8Vp-p Min.
Frequency Stability Tolerance ±2.0ppm Max. (after 2 reflows )
vs Temperature ±0.5ppm~±2.5ppm
vs Supply Voltage ±0.2ppm Max. (Vcc±5%) ±0.2ppm Max. (Vcc±5%)
vs Load ±0.2ppm Max. (Load varies±10%)
vs Aging ±1.0ppm Max./Year
Auto Frequency Control (AFC) Range ±5ppm~±10ppm (1.4±1V)
Start-up Time 2ms Max.
Operating Temperature -40~+85℃
Phase Noise @ 19.2MHz 100Hz -115dBc/Hz
1KHz -135dBc/Hz
10KHz -148dBc/Hz
Packing Unit 3000pcs./Reel

Dimensions [mm]
