SMD 7050 HCSL Oscillator Support 25~200MHz 3.3V For Communication Application
SMD 7050 HCSL Oscillator Support 25~200MHz 3.3V For Communication Application
SMD 7050 HCSL Oscillator Support 25~200MHz 3.3V For Communication Application
SMD 7050 HCSL Oscillator Support 25~200MHz 3.3V For Communication Application
Specifications
Brand Name :
SJK
Model Number :
SJK-7H
Certification :
SGS, RoHS, REACH
Place of Origin :
China
MOQ :
1000pcs
Price :
negotiable
Payment Terms :
T/T
Supply Ability :
70KKpcs/M
Delivery Time :
4-6 wks
Packaging Details :
1Kpcs/Reel
Model :
7H Series HCSL Output SMD Oscillator
Output frequency :
25~200MHz
Supply voltage :
2.5V/3.3V
Output type :
HCSL
Frequency stability :
±25ppm, or specify
Size :
7.0*5.0*1.3mm
Applications :
Server, Gigabit Ethernet, Smart Grid, FPGA, etc
Description

SMD 7050 HCSL Oscillator Support 25~200MHz 3.3V For Communication Application

Features

Differential Output Crystal Oscillator (HCSL Output)

Typical 7.0×5.0×1.45mm, HCSL output crystal oscillator

Output frequency range from 25MHz to 200MHz

Low supply voltage operation: 2.5V/3.3V

Excellent low phase noise and jitter

3-state function available

Automatic mounting and reflow soldering

Applications: Server, SAN, Broadband Access, Smart Grid, Gigabit Ethernet, Fibre channel, etc

RoHS Compliant / Pb-Free

Specifications

Type 7H Series HCSL Output SMD Oscillator
Output Type HCSL
Output Load 50Ω
Supply Voltage 2.5V/3.3V
Frequency Range 25~200MHz
Supply Current 30mA Max.
Overall Frequency Stability* ±25ppm, ±50ppm, or specify
Operating Temperature -40~+85℃, or specify
Storage Temperature -55~+125℃
Voltage Vol (Max.) /Voh (Min.) 0mV /740mV
Rise (Tr) /Fall (Tf) Time 0.5ns Max.
Duty Cycle 45~55%
Start-up Time 10ms Max.
Phase Noise (156.25MHz) at 1KHz -120dBc/Hz
Phase Jitter (12KHz~20MHz) 1pS Max.
Aging (at 25℃) ±3ppm/Year Max.
Packing Unit 1000pcs./Reel

*Including frequency tolerance at 25℃, variation over temperature, supply voltage variation, aging and vibration

Dimensions [mm]

SMD 7050 HCSL Oscillator Support 25~200MHz 3.3V For Communication Application

SMD 7050 HCSL Oscillator Support 25~200MHz 3.3V For Communication Application+86-755-88352869

SMD 7050 HCSL Oscillator Support 25~200MHz 3.3V For Communication Applicationrita@q-crystal.com
