Versatility Metal Wide Belt Sander Double Head For Deburring / Grinding / Finishing
Versatility Metal Wide Belt Sander Double Head For Deburring / Grinding / Finishing
Versatility Metal Wide Belt Sander Double Head For Deburring / Grinding / Finishing
Versatility Metal Wide Belt Sander Double Head For Deburring / Grinding / Finishing
Versatility Metal Wide Belt Sander Double Head For Deburring / Grinding / Finishing
Versatility Metal Wide Belt Sander Double Head For Deburring / Grinding / Finishing
Specifications
Brand Name :
SKD
Model Number :
MS13RR
Place of Origin :
China
Name :
Metal Wide Belt Sander
Type :
Sanding
Model :
MS13RR
Function :
Deburring, Grinding, Slag Removal, Finishing
Max Working Width :
1350mm
Power :
380v 50Hz or customized
MOQ :
1 set
Price :
USD10000-350000
Packaging Details :
Shrink Wrapped or Woodcase
Delivery Time :
20-60 days
Payment Terms :
TT
Supply Ability :
70-100set per year
Description

Metal Wide Belt Sander

General Description

This is a metalworking wideband sander for deburring, sanding, polishing, finishing, slag removal and texturing. Equipped with two powerful sanding drums and a vacuum suction table, it can efficiently handle wide metal sheets, metal plates, small and medium-sized metal workpieces for deburring, grinding and finishing. With quick belt changes, this metal wide belt sander removes slag and oxides from metal parts created by plasma or flame cutting.

Belt sanders typically have adjustable settings that control the speed of the belt, the pressure applied to the workpiece, and the type of abrasive used. This enables operators to achieve the desired surface finish and remove material to precise specifications. Some advanced models may also include additional features such as automatic feeding systems, digital controls, and multiple sanding heads to increase the machine's versatility and productivity.

SPECIFICATIONS
  1. Abrasive Belt Size 2500x1380mm
  2. Motor : 22kw +22kwwith frequency control
  3. Table Lifting Motor: 1.5kw
  4. Number of Heads :2
  5. Sanding Drum Diameter: 240mm
  6. Work piece fix :Vacuum
  7. Vacuum Area:1250×200mm
  8. Speed setting of sanding drum: Frequency converter control
  9. Sanding Drum RPM: 1720
  10. Power supply: 380v 50Hz or on request
  11. Dust port size: drum 150mm x 6, space 100mm x 4
  12. Floor to Table Height 900-990mm
  13. Conveyor Drive Motor 5.5kw
  14. Feed Speed 5-25 meter per minute variable
  15. Dimension 2200x2500x2300mm WxDxH
  16. Weight 3.9 ton
  17. Work piece Max Width 1350mm
  18. Work piece Max Thickness 60mm
  19. Work piece Min. Length 100mm
