QLSC-H1 PEM Electrolyzer Cell Stack For Hydrogen Production At 1Nm3/Hour Flow Rate
QLSC-H1 PEM Electrolyzer Cell Stack For Hydrogen Production At 1Nm3/Hour Flow Rate
QLSC-H1 PEM Electrolyzer Cell Stack For Hydrogen Production At 1Nm3/Hour Flow Rate
QLSC-H1 PEM Electrolyzer Cell Stack For Hydrogen Production At 1Nm3/Hour Flow Rate
QLSC-H1 PEM Electrolyzer Cell Stack For Hydrogen Production At 1Nm3/Hour Flow Rate
QLSC-H1 PEM Electrolyzer Cell Stack For Hydrogen Production At 1Nm3/Hour Flow Rate
Specifications
Place of Origin :
Shandong, China
Brand Name :
Saikesaisi
Price :
$30,000.00/sets 1-2 sets
Production Rate :
0-1000L/hour
Weight :
44KG
Dimension(L*W*H) :
350*240*343mm
Warranty of core components :
1 year
Model :
QLSC-H1
Technology :
PEM
Hydrogen purity :
99.999%-99.9999%
Hydrogen pressure :
0-15bar
Marketing Type :
Long time service life
Applicable Industries :
Manufacturing Plant, Energy & Mining
Video outgoing-inspection :
Provided
Core Components :
Dupont Membrane
Certificate :
CE
Condition :
New
Description

PEM Electrolyzer for Hydrogen Production at 1Nm3/hour Flow Rate and 0-15bar Pressure

Product DescriptionQLSC-H1 PEM Electrolyzer Cell Stack For Hydrogen Production At 1Nm3/Hour Flow Rate
QLSC-H1 PEM Electrolyzer Cell Stack For Hydrogen Production At 1Nm3/Hour Flow Rate
QLSC-H1 PEM Electrolyzer Cell Stack For Hydrogen Production At 1Nm3/Hour Flow Rate
QLSC-H1 PEM Electrolyzer Cell Stack For Hydrogen Production At 1Nm3/Hour Flow Rate
QLSC-H1 PEM Electrolyzer Cell Stack For Hydrogen Production At 1Nm3/Hour Flow Rate
Hydrogen and Oxygen Electrolyzer of water
-PEM titanum electroliser

Product Introduction
QLC titanum electroliser is an advanced patented product, which are light , highly effective, energy-saving and of environmental protection , producing hydrogen and oxygen through the electrolysis of pure water (without adding alkali). That's PEM technology.The PEM/SPE electrodes, as the core of titanum electroliser cell , are highly active catalytic electrode with nearly zero distance between the electrodes , which is formed by integrating composite catalyst with and ion membrane with high electrolytic efficiency.

Working Principle
Electrolytic water meeting the requirements (with electrical resistivity >1MΩ/ cm) , after being put into the anode chamber ofelectrolytic cell, when power is switched on ,will be decomposed at once at the anode : 2H2O = 4H+ + 2O-2. The decomposed negative oxyanion (O-2) will immediately release electron to form oxygen (O2) gas.The hydrogen proton, in the form of aqua ion (H+.XH2O),and under the action of electric field force, through SPE ion membrane, will arrive in the cathode to absorb electron to formhydrogen gas.
Specification
item
value
Place of Origin
China
Shandong
Brand Name
Saikesaisi
Production Rate
0-1000L/hour
Weight
44KG
Dimension(L*W*H)
350×240×343mm
Warranty of core components
1 year
Model
QLSC-H1
Technology
PEM
Hydrogen purity
99.999%-99.9999%
Hydrogen pressure
0-15bar
Marketing Type
Long time service life
Applicable Industries
Manufacturing Plant, Energy & Mining
Video outgoing-inspection
Provided
Core Components
Dupont Membrane
Certificate
CE
Condition
New
