Specifications
Brand Name :
SKYMEN
Model Number :
JP-11368ST
Certification :
CE, RoHs, FCC
Place of Origin :
China
MOQ :
1
Supply Ability :
100 pcs per month
Delivery Time :
In Stock
Packaging Details :
wooden case
Cleaning Way :
Automatic
Chamber dimension :
800*120*120cm
Frequency :
28KHz
Lift for Tower :
Available
Tower diameter :
Below 1.1m
Heating power :
69000W
Ultrasonic power :
68400W
Tank capacity :
11520L
Price :
Negotiation
Description

10000L Ultrasonic Cleaning Machine For Ceramic Filter Membrane 40KHz

More Related Applications:
1. Removal of the rust-proof grease; Cleaning of measuring tools; Oil removal and rust removal of mechanical parts; Cleaning of engines, carburetors and automobile parts; Filter, filter mesh dredge cleaning.

2. Medical equipment cleaning/ disinfection/ sterilization; test utensils cleaning.

3. Remove oil and rust before plating; Cleaning before ion plating;Phosphating; Removal of carbon deposits; Removing oxide skins;Remove polishing paste; Metal workpiece surface activation treatment.

4. Industrial ultrasonic cleaner machine for cleaning electronic parts: ultrasonic PCB cleaner for cleaning circuit board.

Detailed Specification of this machine:

1
Model
JP-11224ST
2
Parameter
Function
Ultrasonic cleaning
Ultrasonic Frequency
28/40kHz (other frequency can be customized)
Tank Material
SUS 304 (SUS 316 can be customized)
Thickness of tank 3mm
Inner tank dimension
3200*2000*1500mm
Tank Capacity
9600L
Transducer
1224pcs
Ultrasonic Power
61200W
Heating Power
69000W
Time setting of Ultrasonic
0~99 hours
Temperature setting
Room temperature ~ 95°C adjustable
Drain value
Available
Water inlet/outlet
Available
Generator
34 sets
Generator power control 1800W
Generator shelf Available
Basket Available
Basket load
4000KG
3
Packing
Overall size
370*270*230cm
Packing size
380*280*250cm
Packing detail By wooden case(No logs, free of fumigation)
N.W/G.W
4000KG/4300KG
4 Power supply 380V 3 phase; 220V 3 pahse; 415V; 600V
5
Warranty
1 year warranty for spare parts, all life technical support
6
Certificate
CE, RoHS; FCC, REACH
7
Lead time
20~30 working days after deposit
7 Optional functions Filtration cycle system Available; capture dirty water, recycle clean water
Lifting system for basket Available; take the basket up and down
Dunking system Available; Speed up cleaning
Bubbling Available; need to connect air compressor
Electrolysis Available; For cleaning more complex structure mold
Cooling system Available; To cool down inflammable and explosive
Constant temperature Available;
Roller barrel Available; for clean coins and big quantity parts
Anti-explosion electric box Available;
Deionized(DI) water Available
Double/Multi frequency Available; 28/40/20/68/80/132KHz
Other funtions Negotiate via email

28KHz 70000W Industrial Ultrasonic Bath 11520L For Towers

Other size and capacity for reference:

28KHz 70000W Industrial Ultrasonic Bath 11520L For Towers

28KHz 70000W Industrial Ultrasonic Bath 11520L For Towers

28KHz 70000W Industrial Ultrasonic Bath 11520L For Towers

28KHz 70000W Industrial Ultrasonic Bath 11520L For Towers

28KHz 70000W Industrial Ultrasonic Bath 11520L For Towers

28KHz 70000W Industrial Ultrasonic Bath 11520L For Towers

28KHz 70000W Industrial Ultrasonic Bath 11520L For Towers

28KHz 70000W Industrial Ultrasonic Bath 11520L For Towers

28KHz 70000W Industrial Ultrasonic Bath 11520L For Towers

28KHz 70000W Industrial Ultrasonic Bath 11520L For Towers

28KHz 70000W Industrial Ultrasonic Bath 11520L For Towers

28KHz 70000W Industrial Ultrasonic Bath 11520L For Towers

Product show:

28KHz 70000W Industrial Ultrasonic Bath 11520L For Towers28KHz 70000W Industrial Ultrasonic Bath 11520L For Towers28KHz 70000W Industrial Ultrasonic Bath 11520L For Towers28KHz 70000W Industrial Ultrasonic Bath 11520L For Towers28KHz 70000W Industrial Ultrasonic Bath 11520L For Towers28KHz 70000W Industrial Ultrasonic Bath 11520L For Towers28KHz 70000W Industrial Ultrasonic Bath 11520L For Towers

Cleaning effect show:

28KHz 70000W Industrial Ultrasonic Bath 11520L For Towers

28KHz 70000W Industrial Ultrasonic Bath 11520L For Towers

Skymen Cleaning Equipment Shenzhen CO., Ltd.

28KHz 70000W Industrial Ultrasonic Bath 11520L For Towers

28KHz 70000W Industrial Ultrasonic Bath 11520L For Towers28KHz 70000W Industrial Ultrasonic Bath 11520L For Towers

FAQ:
Q: What are the advantages of Skymen ultrasonic cleaner over traditional cleaning methods?
A:

1. Minimize the use of manual labor
2. Make cleaning and degreasing without the use of organic solvents
3. Clean hard to reach areas of products and remove all types of dirt
4. Shorten the processes such as extraction, dispersion, purification, chemical reactions
5. Eliminates costly mechanical and chemical cleaning of heat exchangers


Q: What frequency is better for my parts?
A: Frequency is suggested based on pollutants in the objects.
28kHz frequency is stronger, better for car/motor/truck/vessel parts clean (remove oils, grease, pastes, etc. )
40kHz is better for pcb boards, electronic parts, etc.
Higher precision goods, higher frequency.

Q: Can ultrasonic cleaning damage parts?
A: Although the effect of thousands of implosions per second is very powerful, the cleaning process is safe. No damage to your daily objects.

Q: What cleaning solution should I use?
A: A large variety of different formulas designed for specific applications. Proper selection is crucial for acceptable cleaning activity and to prevent unwanted reactions with the workpiece.

Q: Is rinsing after cleaning cycles?
A: Rinsing is recommended to remove any chemical residue that could be harmful to the part. Details can be rinsed right in your ultrasonic cleaner or in a clean water bath or in a separate sink tap, distilled or deionized water.
