3mm Thickness 8500L Ultrasonic Cleaning Machine SUS304 For Plate

Specifications

Brand Name :

SKYMEN

Model Number :

JP-11152ST

Certification :

CE, RoHs, FCC

Place of Origin :

China

MOQ :

Supply Ability :

100 pcs per month

Delivery Time :

In Stock

Packaging Details :

wooden case

Transducer :

1152pcs

Ultrasonic power :

57600W

Heating power :

69000W

Chamber Capacity :

8500L

Power supply :

380V 3 phase

Generator :

32pcs

Price :

Negotiation

Description

8500L Ultrasonic Cleaning Machine For Plate Heat Exchanger SUS304 Material

Ultrasonic cleaning of metal heat exchanger
It is well known that after the metal bar is extruded into a wire, the outer part of the wire often has a layer of carbonized film and oil. It is difficult to remove the dirt (especially the whole wire) by acid cleaning or other cleaning methods. The ultrasonic wire washing machine is According to the actual production needs, a continuous wire-cutting and high-efficiency cleaning equipment is used. The rough washing part is composed of a cleaning liquid storage tank, a transducer, a circulation pump, a filter and a matching piping system. After the wire is ultrasonically washed and washed, And then blow dry to complete the entire cleaning process. The integrated control of the whole set of equipment is simple, convenient and effective. It is widely used in other wires such as silk, tungsten wire, molybdenum wire, silk wire and copper wire (before the coating of insulating paint).

Detailed Specification of this machine:

1	Model	JP-11152ST
2	Parameter	Function	Ultrasonic cleaning
		Ultrasonic Frequency	28/40kHz (other frequency can be customized)
		Tank Material	SUS 304 (SUS 316 can be customized)
		Thickness of tank	3mm
		Inner tank dimension	250020001700mm
		Tank Capacity	8500L
		Transducer	1152pcs
		Ultrasonic Power	57600W
		Heating Power	69000W
		Time setting of Ultrasonic	0~99 hours
		Temperature setting	Room temperature ~ 95°C adjustable
		Drain value	Available
		Water inlet/outlet	Available
		Generator	32 sets
		Generator power control	1800W
		Generator shelf	Available
		Basket	Available
		Basket load	2000KG
3	Packing	Overall size	300250240cm
		Packing size	310260250cm
		Packing detail	By wooden case(No logs, free of fumigation)
		N.W/G.W	5000KG/5300KG
4	Power supply	380V 3 phase; 220V 3 pahse; 415V; 600V
5	Warranty	1 year warranty for spare parts, all life technical support
6	Certificate	CE, RoHS; FCC, REACH
7	Lead time	20~30 working days after deposit

7	Optional functions	Filtration cycle system	Available; capture dirty water, recycle clean water
		Lifting system for basket	Available; take the basket up and down
		Dunking system	Available; Speed up cleaning
		Bubbling	Available; need to connect air compressor
		Electrolysis	Available; For cleaning more complex structure mold
		Cooling system	Available; To cool down inflammable and explosive
		Constant temperature	Available;
		Roller barrel	Available; for clean coins and big quantity parts
		Anti-explosion electric box	Available;
		Deionized(DI) water	Available
		Double/Multi frequency	Available; 28/40/20/68/80/132KHz
		Other funtions	Negotiate via email
