Flexibly Assembled Column Formwork with H20 Wooden Beam and Steel Walers
Flexibly Assembled Column Formwork with H20 Wooden Beam and Steel Walers
Flexibly Assembled Column Formwork with H20 Wooden Beam and Steel Walers
Flexibly Assembled Column Formwork with H20 Wooden Beam and Steel Walers
Specifications
Brand Name :
HORIZON
Model Number :
COLUMN FORMWORKS
Place of Origin :
CHINA
MOQ :
500 sqm
Price :
pls ask HORIZON
Payment Terms :
L/C, T/T
Supply Ability :
200 tons per week
Delivery Time :
20-25 days
Packaging Details :
pallets, bundles, bulk
Material :
H20 wooden beam, steel waler, plywood
OEM :
Yes
Colour :
yellow & blue
Type :
column formworks
Supporting :
By strut
Column size :
200 x 200mm and above
Description

Flexibly Assembled Column Formwork with H20 Wooden Beam and Steel Walers

With same components as wall formwork, the column formwork mainly consists of: timber beam H20, steel walers, plywood and beam clamp.

There are two options of forming columns:

1). by right-angle waling connector & tie yoke system;

2). by tie yoke only.

Components Specification / description
Wall formwork panel For all vertical formworks
H20 Timber beam

Water proof treated
Height: 200mm
Width: 80mm
Length: as per table size
Steel waling

Painted, powder coated
[12 steel channel
Flange clamp

Galvanized
To connect steel waling and H20 beams
Panel strut

Painted
help formwork panel erection
Waling connector 80

Painted
Used for formwork panels alignment
Corner connector 60x60

Painted
Used for forming inner corner formwork with wedge pins
Top scaffold bracket

Painted,
severs as safety working platform

Taking examples as following:

Column size: 700 x 700mm
Flexibly Assembled Column Formwork with H20 Wooden Beam and Steel Walers

Column size: 1000 x 500mm
Flexibly Assembled Column Formwork with H20 Wooden Beam and Steel Walers

Column size: 1000 x 800mm
Flexibly Assembled Column Formwork with H20 Wooden Beam and Steel Walers

Column size: 600 x 500mm
Flexibly Assembled Column Formwork with H20 Wooden Beam and Steel Walers

Delivery:
1. Production: For full container, normally we need 20-30 days after receive customer's down payment.
2. Transportation: It depends on the destination charge port.
3. Negotiation is needed for special requirements.

Flexibly Assembled Column Formwork with H20 Wooden Beam and Steel Walers
