P2.5 P3 P4 P5 Indoor RGB LED Display Panel Video Wall Screen Stage Background LED Screen
Featrue:
High Definition Image
Small physical pitch and 1500-2500 nits brightness make high definition and vivid image;
Fashionable Die Casting Aluminum Body
Slim and light design for the cabinet body, with the newest lock for convenient fixation;
High Uniformity & Contrast
High quality led lamp and mask for super bright display and high contrast image;
High Refresh Rate
High refresh rate and constant current ensure the colorful and stable playing effect;
Reliable
Over 100000 working hours for longtime use;
Multi-Control Systems
Synchronous and asynchronous systems for option.
Application
1.stage performance, bar entertainment, ceremonial wedding, conference, exhibition, musical theater and other event rental application
2.TV studio;Monitor room;Control room;Dispatch center;Conference room;Show room etc
Technical Specification:
Items | P2.5mm | P3mm | P4mm | P5mm |
Pixel | 1R1G1B | 1R1G1B | 1R1G1B | 1R1G1B |
Configuration | SMD 3-in-1 | SMD 3-in-1 | SMD 3-in-1 | SMD 3-in-1 |
Pixel Pitch | 2.5mm | 3mm | 4mm | 5mm |
Pixel Density | 160,000 | 111,111 | 62,500 | 40,000 |
Module Size(mm) | 160x160 | 192x192or 192x96 | 256x128 | 160x160or 320x160 |
Pixels/Module | 64x64 | 64x64or 64x32 | 64x32 | 32x32or 64x32 |
Cabinet Size(mm) | 960x960 | 960x960 | 1024x1024 | 960x960 |
Pixels/Cabinet | 384x384 | 320x320 | 256x256 | 192x192 |
Cabinet Weight | 37KG | 37KG | 42KG | 37KG |
Brightness | 1300cd/ | 1300cd/ | 1300cd/ | 1300cd/ |
Viewing Distance | >2.5m | >3m | >4m | >5m |
Power Consumption | Max: 800 | Max: 800 | Max: 650 | Max: 400 |
(W/) | Ave: 240 | Ave: 240 | Ave: 195 | Ave: 120 |
Driver Mode | 1/32 scan | 1/16 scan | 1/16 scan | 1/16 scan |
Cabinet Material | Cold Rolled Steel | |||
Refresh Rate | 300-3000HZ adjustable | |||
LED Life | 100,000 hours | |||
Supply Voltage | AC220V/50HZ; AC110V/60HZ | |||
Operating Temperature | -20ºC ~ +40ºC | |||
Operating Humidity | 10% - 90% | |||
Viewing Angle | H: 120°; V: 120° | |||
Gray Scale | Red, Green and Blue each 16K | |||
Display Color | 4096 Billion | |||
IP Rating | IP20 | |||
Display Capability | Text, Graph and Video |
Supply Ability
Supply Ability: 1100+pieces/pcs per Month.
Packaging & Delivery
Indoor LED screen display proejcts
Warranty Terms
ANWELL team could provide dependable pre-sales services, post-sales supports and complete project solutions assistance for every customers.
1. All the products purchased from ANWELL company carries one year free replacements and product life supports.
A: Two years warranty period, including one year free replacement warranty period..
B: Product life supports and free project design.
2. Faulty products includes LED module, power supply, system cards and accessories will be returned to ANWELL factory for maintenance if necessary.
3. Complete project solutions services ranges from project design, installation, operation to future maintenance. Fast response capability to customers' request.
4. 24 hours aging test for every finished products before delivery, no tolerance in faulty products. Top quality will be well guaranteed.
5. Special offers available for preferred clients.
